CONTINENTAL HYDRAULICS
Low Profile Hydraulic Power Units

Low Profile Hydraulic Power Units

Product catalog summary

General Specifications
Low Profile Power Units are designed for compact spaces, offering the power of NFPA/JIC-style units in a smaller, cost-effective package. They are suitable for industrial applications with moderate fluid volume and flow rate, such as test benches, machine tools, clamping, and drilling equipment. These units are ideal where heat buildup is unlikely.

Specifications

Reservoir Capacities: 10 Gal (37.8 liters), 20 Gal (75.7 liters), 30 Gal (112.7 liters)
Flow Range: Up to 11 gpm (41.6 lpm)
Pressure Range: Up to 3000 psi (207 bar)
Power Range: Up to 10 Hp (7.5 kW)

Features

Electric Motor with Junction Box
Pressure Compensated, Variable Volume Vane Pump or Fixed Displacement Gear Pump
Economical, non-JIC Style Reservoir
Optional Pressure Gauge & Snubber/Shut-off

Dimension Drawings
Includes detailed dimensions for power units with gear and vane pumps, highlighting key components like sight level/temperature gauge, return filter, and optional manifold configurations.

Basic Schematics
Illustrates configurations with gear and vane pumps, including optional components like relief valves and manifolds.

Ordering Information
Guidelines for selecting pumps and motors, with standard combinations listed. Special combinations require consultation with a distributor.

Manifold Options

Single to Four Station Manifolds with optional built-in relief

Note
Specifications and appearance are subject to change as Continental Hydraulics continually improves its products.

Catalog excerpts

CatalogLow ProleHydraulic Power Units >

Open the catalog to page 1

Electric MotorJunction Box Strainer Sized To Pass2-3 Times The Pump'sMaximum Flow @ MinimumPressure Drop Inlet Plumbing Floor MountingHoles, Qty 4 Pressure Compensated,Variable Volume ContinentalVane Pump, or A FixedDisplacement Gear Pump 10 Ga. HRPO 1020 Steel Inlet Flange Sized ForEasy Removal Of StrainerFor Routine Cleaning Flexible Drive CouplingsAnd Pump/Motor Adapter Rotation Arrow 3/4" NPT MagneticDrain Plug Baffle Sized For 2 Ft/Sec.Fluid Velocity Or Less TEFC Or ODP C-faceElectric Motors Economical, Non-JIC StyleReservoir To Minimize AssemblyAnd Material Cost Sight Level/Temperature...

Open the catalog to page 3

OPTIONALPRESSURE GAUGE& SNUBBER/SHUT-OFF VALVE > OPTIONALD03 MANIFOLDWITH -8 SAEA & B PORTS > 2.00 (50.80)TYP. RETURN FILTER(REMOVE COVERAND ELEMENT TOFILL RESERVOIR) >

Open the catalog to page 4

OPTIONALD03 MANIFOLDW/-8 SAEA & B PORTSOPTIONALPRESSURE GAUGE& SNUBBER/SHUT-OFF VALVE 2.00 (50.80)TYP. > I H RETURN FILTER(REMOVE COVERAND ELEMENT TOFILL RESERVOIR) 0.75 (19.05) 4.50 (114.35) 2.55 (64.72) B 0.96 (24.33) W20SHOWN 0.44 (ؘ11.13)4 PLACES7.44 (188.93)3.00 (76.20) SIGHT LEVEL/TEMPERATURE GAUGE E 3/4" NPTDRAIN QTY 1 MAX FRAME SIZE254TC/256TC(SHOWN) 1.00 (25.40) 0.75 (19.05) > C F > D G >

Open the catalog to page 5

OptionalD03 Manifold1-4 Stations ReturnFilter D03 PatternD03 PatternAB Relief Valve100-3000 PSIAdjustable 1/2" OptionalSnubberAB Gauge & 3/4" NPTDrain -8 SAE"A" & "B" Ports 3/4" Adjustable100-3000 PSIRelief Valve D03 Pattern D03 PatternOptionalAB 1/2"BA OptionalD03 Manifold1-4 Stations Gauge & 3/4" NPT "A" & "B" Ports Snubber-8 SAE 3/4" ReturnFilter Drain >

Open the catalog to page 6

OptionalPressure Gauge& Snubber/Shut-Off Valve -8 FSAE"P" & "T" Ports A I > H Return Filter(Remove Coverand Element toFill Reservoir) 7.44 (188.93)ј0.44 (11.13)4 Places3.00 (76.20) 0.75(19.05) Max Frame Size254TC/256TC(Shown) 3/4" NPTDrain Qty 1 3.50 (88.98) 2.55 (64.72) B W20Shown Sight Level/Temperature Gauge E 1.00 (25.40) CD FG0.75 (19.05) >

Open the catalog to page 7

1.47 (37.3) 0.81 (20.6) -8 FSAE"P" & "T" PortsOptionalPressure Gauge& Snubber/Shut-Off Valve > A I H Return Filter(Remove CoverAnd Element toFill Reservoir)0.75 (19.05) 3.00 (76.20) ј0.44 (11.13)4 Places7.44 (188.93) Max Frame Size254TC/256TC(Shown) 4.50 (114.35) 3.20 (81.3) B W20Shown Sight Level/Temperature Gauge E 3/4" NPTDrain Qty 1 1.00 (25.40) 0.75 (19.05) C D GF >

Open the catalog to page 8

Adjustable100-3000 PSIRelief Valve "P" & "T" Ports PT-8 SAE Gauge &SnubberOptional3/4" FilterReturn 3/4" NPTDrain 1/2" Optional"PR" Block Adjustable100-3000 PSIRelief Valve PPTT 1/2"PT Optional"PR" Block Optional ReturnFilterGauge & 3/4" NPT "P" & "T" Ports Snubber-8 SAE 3/4" Drain >

Open the catalog to page 9

Adjustable100-3000 PSIRelief Valve D03 Pattern D03 PatternOptionalAB Optional Case DrainHeat Exchanger4-Pass, No By-Pass 1/2"BA OptionalD03 Manifold1-4 Sstations ReturnFilterGauge & 3/4" NPT "A" & "B" Ports Snubber-8 SAE 3/4" Drain > 15.20(386.2)

Open the catalog to page 10

W Low Profile Series 1T 1 208/230/460/60/3 143TC Omit No Manifold Options Pressure Block Omit HEA44C No Cooler Options Air-to-Oil Case Drain Cooler, SAE-8 Ports 1S 1 115/208/230/60/1 143TC (Vane Pump Only) 1.5T 1.5 208/230/460/60/3 145TC PR With Built-In Relief SAE-8 PӔ & TӔ Female Ports Single Station Manifold 1.5S 1.5 115/208/230/60/1 145TC 2T 2 208/230/460/60/3 145TC 2S 2 115/208/230/60/1 145TC 3T 3 208/230/460/60/3 182TC V3M1S D03, SAE-8 AӔ & BӔ Female Ports Single Station Manifold 3S 3 115/208/230/60/1 182TC 5T 5 208/230/460/60/3 184TC 7.5T 7.5 208/230/460/60/3 213TC D03 With Built-In 10T...

Open the catalog to page 11

Continental Hydraulics Division 5505 West 123rd StreetSavage, MN 55378 U.S.A.Phone: (952) 895-6400 Fax: (952) 895-6444www.continentalhydraulics.com > Because Continental Hydraulics is continually improving its products, specifications and appearance are subject to change without notice. Form No. 266289 2/09 2009 Continental Hydraulics Printed in U.S.A. size="-2">
