MIXING VALVES

MIXING VALVES
16Pages

Catalog excerpts

MADE IN THE USA MIXING VALVES NOW! 5-Year Warranty on all “Made in the USA” products

Introduction 2 Hydronic Tempering Valves 34-100 Series 3 Point of Source Radiant Heat Mixing Valves 34C High Temperature 6 34H Series 4-5 Point of Source ASSE 1017 Mixing Valves 34A Series 4-5 34C Series 6 Point of Use ASSE 1070 Mixing Valves 34B Series 7 34D “Mini” Series 8 Automatic Temperature Controller (ATC) 34HL Series 9-10 Emergency Eye Wash/Face Wash Mixing Valve 34E 11-12 Mixing Valves Application Chart 13-14 Table Of Contents Apollo Mixing Valves ... Your Best Choice For Value And Protection No matter how big or small your job, you can trust Apollo® temperature activated mixing...

Open the catalog to page 2

Hydronic Tempering Valves Designed to provide non-ASSE extension of water heater capacity and hot water temperature control in hydronic heating applications. Numbered indicator control allows easy setup and fingertip control. Available in low or high temperature options depending on floor or baseboard application. FEATURES • Low temperature range (100°-130°F) • High temperature range (120°-150°F) • Stainless steel spring and rings • Corrosion resistant bronze body • Thermoplastic shuttle assembly • Thread or solder connections • In-line repairable • Low flow restriction • Fingertip...

Open the catalog to page 3

ASSE 1017 Point of Source Commercial Mixing Valves The Apollo MVA thermostatic master mixing valves are designed for ASSE 1017 “point of source” applications. They provide reliable hot water temperature control of potable and hydronic hot water distribution systems. FEATURES • Superior thermostatic element technology for optimal performance, reliability and accuracy • Integral inlet strainers and check valves are standard to protect against cross-flow and foreign particles in the piping system • Thermostat over-temperature control • Maximum temperature limit option • Fingertip temperature...

Open the catalog to page 4

Commercial High Capacity Mixing Valves The Apollo® Model MVC (34C Series) ASSE 1017 listed, highcapacity mixing valves are thermostatically controlled regulating valves designed for use in large commercial and institutional potable “point of source” and non-potable hot water systems or applications. Simple adjustment of water temperature from 90°- 140°F or 130°-180°F. FEATURES • Sizes 3/4”, 1”, 1-1/4”, 1-1/2”, 2” • Standard temp range 90°-140°F • High temp range 130°-180°F (use suffix “H1”) for hydronic/ radiant heating systems • Highest flow in its class • Threaded connections • Installs...

Open the catalog to page 6

www.apollovalves.com 7 Mixing Valves The Apollo® Model “MVB” (34B Series) thermostatic mixing valves are designed to control and limit the volumes of cold and hot water required to deliver mixed water at a predetermined temperature either from the “point of sourc” or “point of use” application for single or multiple fixtures. FEATURES • Highest capacity that meets ASSE 1070 • Superior thermostatic element technology for optimum reliability, dependability and accuracy • Integral strainers and check valves provide protection against cross-flow and foreign particles • Thermostat...

Open the catalog to page 7

Customer Service 1-704-841-6000 The new Apollo® MCVD (34D Series) Mini Thermostatic mixing valves are designed for ASSE 1070 “Point of Use” temperature control applications with a single fixture using proven ASTM grade materials. These valves will hold a desired temperature within ± 2°F and will shut off in the event of hot or cold water failure. They come equipped with a tamper-resistant high temperature limit stop to prevent the valve from being stet above 120°F. FEATURES • 100% Made in the USA • New tamper resistant locking control knob • Adjustable maximum temperature limit stop • Crush...

Open the catalog to page 8

www.apollovalves.com 9 Mixing Valves NEW FROM APOLLO®...THE FIRST MULTIPLE-FIXTURE HI-LO MIXING VALVE THAT MEETS ASSE 1017 AND THE NEW ASSE 1069 STANDARD Only Apollo® offers fast delivery on the first water temperature mixing assembly to meet ASSE 1017 and the strict performance levels required by the new ASSE 1069 Standard. The new 34HL Automatic Temperature Control Mixing Valve uses proven Apollo thermostatic control to produce a consistent mix of water from low through high flow range. This single assembly controls mixed water temperatures to multiple-outlet shower and sink...

Open the catalog to page 9

Figure 1: Typical Valve Dimensions with Stainless Steel Recessed Cabinet Option Automatic Temperature Controller (ATC) UNITED STATES PATENT US 6,929,188 B2 Standard Approvals ASSE 1069-Automatic Temperature Control Mixing Valves This device will control outlet water temperature to individual or multiple fixtures within 3.6°F to reduce the risk of scalding or thermal shock. This device is intended to be installed where the bather has no access to the temperature adjustment, and where no further mixing occurs downstream of the device. The Apollo 34HL ATC will meet the performance requirements...

Open the catalog to page 10

34E Series Emergency Eye Wash/Face Wash Mixing Valve www.apollovalves.com 11 Mixing Valves Pending The Apollo® Model “MVE” (34E Series) emergency mixing valves are designed to ccontrol the cold and hot water temperature to deliver tepid water at a predetermined temperature to emergency eyewash/facewash fixtures. The device provides a precise temperature and flow control in the event of cold water, hot water and themostatic element failures. FEATURES •Hot and cold water supply failure protection patented design (US Patent 6,926,20 B2) •Tepid water temperature limit control and adjustment...

Open the catalog to page 11

Customer Service 1-704-841-6000 Mixing Valves Emergency Eye Wash/Face Wash Mixing Valve 34E Typical Installations Note: Piping and installation of the device must be in accordance to federal, state, and local plumbing codes. Note: If the valve is some distance from the hot water source, recirculation is required to keep the hot water supply temperature within the required operational limits Model No. MVE-12 MVES-12 MVE-34 MVES-34 Series No. 34E103T 34E103S 34E104T 34E104S Connection 1/2” FPT 1/2” Solder 3/4” FPT 3/4” Solder A (in.) 3.09 3.22 3.09 3.10 B (in.) 8.90 9.15 8.90 8.90 C (in.)...

Open the catalog to page 12
