MADE IN THE USA CONTROL VALVES

2 Customer Service 1-704-841-6000 PRODUCT PAGE A65 Series 3 A127 Series 3 A127LF Series 3 A108 Series 4 A115 Series 4 A22/88 Series 4 A120 Series 5 A110 Series 5 A8000 Series 5 A94 Series 6 Specifications & Dimensions 6-7 TABLE OF CONTENTS Conbraco Industries, Inc. American Lubricator and Brass Co. and Sterling & Skinner Manufacturing Col, two established Detroit based manufacturers of brass valves and fittings, merged in 1928. They adopted a new name, Consolidated Brass Company, and Conbraco Industries was born. After 75 years, Conbraco is an American success story that’s still being...

Open the catalog to page 2

Customer Service 1-704-841-6000 3 Control Valves Basic Valve A65 SERIES The Apollo Pressure Reducing Valve is used in many applications worldwide. The primary function of the 127 series is to reduce a greater upstream pressure to a lesser, more manageable downstream pressure, operating without regard to either upstream supply or downstream demand. Features: • Reduces higher inlet pressure to a constant lower outlet pressure. • Outlet pressure is accurate over wide range of flow - pilot operated main valve is not subject to pressure falloff characteristic of direct-acting PRV’s. • Outlet...

Open the catalog to page 3

Control Valves 4 Customer Service 1-704-841-6000 The Apollo Series A115 Solenoid Control Valve is designed to provide on/off or open/close control of fluids in response to an electrical signal. The valve consists of the basic Apollo model A65 with solenoid-operated pilot. With the appropriate solenoid, the valve may be normally closed (energize to open) or normally open (energize to close). Features: • The A115 Series provides responsive control in answer to such triggering devices as clocks, timers, relays, probes, pressure or temperature sensors. • Available for AC or DC voltages. • Wider...

Open the catalog to page 4

Customer Service 1-704-841-6000 5 Control Valves The Apollo Series A120 Rate of Flow control valve is designed to control or limit flow to a predetermined rate, regardless of fluctuations in downstream or upstream pressure. Features: • Self contained, including the differential sensing orifice plate and pilot • Flow rate is field adjustable (within orifice bore range). • Extra sensitive differential pilot specifically designed for rate of flow application. • Works equally well on all types of clean, nonabrasive liquids. The Apollo A110 Series Differential Control Valve is designed to...

Open the catalog to page 5

Control Valves 6 Customer Service 1-704-841-6000 A94 SERIES The Apollo Series A94 check valve is a simple on-off valve that opens to allow forward flow when inlet pressure exceeds outlet and closes tightly to prevent backflow when outlet pressure exceed inlet pressure. Features: • Non-surge opening and/or closing when equipped with adjustable opening and/or closing speed controls. • Equipped with valve position indicator on all models. Diaphragm Check SPECIFICATIONS

Open the catalog to page 6

Customer Service 1-704-841-6000 7 Control Valves DIMENSIONS For maximum efficiency, the control valve should be mounted in a piping system so that the valve bonnet (cover) is in the top position. Other positions are acceptable but may not allow the valve to function to its fullest and safest potential. In particular please consult the factory before installing 8” and larger valves, or any valves with a limit switch, in positions other than described. Space should be taken into consideration when mounting valves and their pilot systems. A routine inspection & maintenance program should be...

Open the catalog to page 7

For Representatives And Distributors In Your International Area Please Contact The Closest Conbraco Industries International Office. SALES AND SERVICE DEPARTMENT PO Box 247 • Matthews, NC 28106 Phone: 704-841-6000 • Fax: 704-841-6020 E-Mail Address Phone Fax B. Lynch & Associates Florida sales@ blynchandassociates. com 813- 901- 0992 813- 901- 8403 Spotswood Associates Georgia/ Alabama dlewis@ spotswoodassociates. com 770- 447- 1227 770- 263- 6899 Pro Marketing, Inc. North Carolina/South Carolina/Tennessee- East sales@ promarketinginc. net 864- 578- 4334 864- 578- 4889 Mid South Marketing,...
