High Voltage Reed Relays

High Voltage Reed Relays
2Pages

Catalog excerpts

"X'COMUS Relays Part Number: Custom Design High Voltage Reed Relays Product Data Sheet "X'COMUS Relays m FEATURES • INDUSTRY STANDARD PACKAGES • UP TO 10,000 VDC SWITCHING VOLTAGE • UP TO 14,000 VDC DIELECTRIC STRENGTH • UP TO 200 WATTS / 5 AMP CARRY CURRENT • MULTI-POLE, FORM A AND FORM B CONTACTS • CUSTOM DESIGNS WELCOME As part of the company policy of continued product improvement, specifications may change without notice. Our sales office will be pleased to help you with the latest information on this product range and the details of our full design and manufacturing service. All products are supplied to our standard conditions of sale unless otherwise agreed in writing. 3390 series COIL VOLTAGE CONTACT FORM 1275 = Normally Open / 1A 4275 = Normally Closed / 1B Part Number Example: 339X.XXXX.XX6 3390.1272.126 = 500V, 2 Normally Open, 12V coil CONTACT FORM 1270 = Normally Open / 1A 4270 = 1 Normally Closed / 1B 1272 = 2 Normally Open / 2A

Open the catalog to page 1

"X-COMUS Relays Part Number: 3350 Series High Voltage Reed Relays Product Data Sheet "X'COMUS Relays Part Number: 3390 Series High Voltage Reed Relays Product Data Sheet SPECIFICATIONS SPECIFICATIONS Contact Form Switching Voltage Package Style Normally Open / 1A Contact Form Switching Voltage Package Style CONTACT PARAMETERS CONTACT PARAMETERS Switching Voltage Dielectric Strength Switching Capacity Switching Current Carrying Current Contact Resistance DC/peakAC VDC W A A mn Switching Voltage Dielectric Strength Switching Capacity Switching Current Carrying Current Contact Resistance...

Open the catalog to page 2
