Introduction
Hydrovane, a leader in rotary vane compression technology, has been a market leader for over 50 years, producing over 750,000 compressors globally. As part of the CompAir group, Hydrovane is known for its quality and reliability, with manufacturing based in the UK and adhering to ISO9001/2000 standards.

How It Works
The rotary vane compressor operates by drawing air through an intake valve, circulating oil for cooling and lubrication, and compressing air by decreasing volume. The system includes an air-blast oil cooler, primary oil separator, and a final separator element to ensure high-quality air output.

Key Benefits
Hydrovane compressors offer reliability, quality air, efficiency, longevity, quiet operation, and a comprehensive warranty program. The design ensures minimal stress and energy costs, with no bearings or metal parts needing replacement.

Product Range and Specifications

HV01-04 (1-4kW): Suitable for various applications, featuring low noise, vibration-free operation, and available in single-phase versions.
HV04-45 (4-45kW): Designed for larger industrial demands, featuring low noise levels, direct drive, and easy serviceability.
HV55-75 (55-75kW): Enclosed units with advanced microprocessor control, offering high-quality air and efficient operation.
Regulated Speed Models (HV07-75RS): Designed for energy savings, these models adjust speed to meet air requirements, offering significant energy savings and reduced noise levels.

Hypac Range
The Hypac range includes both membrane and refrigerant dryer technologies, offering ultra-dry and clean air solutions for various industrial applications. These systems are designed for easy installation and maintenance, providing a compact and efficient solution for compressed air needs.

Conclusion
Hydrovane compressors are engineered to provide reliable, efficient, and high-quality compressed air solutions for a wide range of industrial applications, backed by a strong warranty and support program.

Typical Applications
The compressors are used in various applications including coordinate measuring, dentistry, electronics, laboratories, laser cutting, machine tools, optical, packaging, spraying, printing, robotics, and OEM applications.

Specifications
The compressors operate with Free Air Delivered (FAD) according to ISO 1217 standards, and noise levels are measured in accordance with ISO 3744, with a tolerance of ±3dB(A). They can operate at ambient temperatures up to 40°C.

Performance and Models
Various models such as HV01RM, HV02RM, HV04RM, and others are detailed with their dimensions, weights, motor power, speed, oil capacity, and noise levels. The maximum FAD is specified in m3/min at different pressures (8 bar, 10 bar).

Warranty Programme
The Hydrovane ‘Advance’ warranty offers a 10-year or 48,000-hour warranty on compressors from 4kW to 75kW, with a lifetime guarantee on the blades. Key benefits include no premiums, planned maintenance schedules, and known revenue costs. Customer requirements include purchasing from an authorized distributor, approved installation, and regular servicing with genuine parts.

Aftermarket Support
Hydrovane emphasizes regular maintenance for long, reliable compressor life. They offer servicing kits containing all necessary parts for maintenance, and specially formulated lubricants under the Fluid Force brand for various applications. Training is provided for service engineers to ensure proper maintenance and repair procedures.

Contact Information
CompAir UK Ltd is located at Claybrook Drive, Washford Industrial Estate, Redditch, Worcs B98 0DS, UK. Contact details include phone and fax numbers, and the website www.hydrovane.co.uk for further inquiries.

Catalog excerpts

industry revolves around >

Open the catalog to page 1

The key to Hydrovanes exceptional performance is the simplicity of the rotary vane principle: Directly driven at low speed with minimal stresses, provides a totally dependable air supply delivers clean dry compressed air > Consistent pulse free supply with automatic regulation minimises energy costs > Intake modulation with Reduced Energy Venting System (REVS) just runs and runs and runs > No bearings or metal parts to be replaced offers extensive choice of locations > Integral design combined with slow speed known costs for total peace of mind. > 10 year ґbuilt in Advance warranty programme...

Open the catalog to page 3

Available as a factory built package or kit for local assembly Horizontal receiver (75 litre for 1 and 2kW, 200 litre for 4kW)ՕHydrovane direct drive horizontal compressor Aftercooler for primary water separation ՕMembrane dryer technology CF series filtration ՕAutomatic stop start Fully connected and ready to run. > AERD With receiver, refrigerant dryer and filtration > The total package of compressor dryer, filtration and receiver ՕHydrovane vertical compressor Receiver 250 litres (4 - 7kW), 272 litres (11 - 22kW) ՕWater trap Refrigerant dryer (pressure dew point 3հC) In-line filter (1 micron)...

Open the catalog to page 9

The Hydrovane Advanceђ warranty is a unique compressor care programme formulated tooffer the compressor owner complete warranty cover on Hydrovane compressors from 4kW to 75kW*. In addition there is a lifetime guarantee on the blades. > Total package warranty for 10 years or 48,000 hours - Complete peace of mind**ՕFree of charge - No premiums to payPlanned maintenance schedules - Maximum productionՕKnown revenue costs - No unexpected repair billsSimple to join with minimum administration - No fuss, no complication. > ՕPurchase a new Hydrovane compressor from an authorised Hydrovane distributorHave...

Open the catalog to page 11

CompAir UK Ltd Claybrook Drive, WashfordIndustrial Estate, Redditch, Worcs B98 0DS, UK T. +44 (0) 1527 525522 F. +44 (0) 1527 521140 E. [email protected] www.hydrovane.co.uk > թCompAir UK Ltd 2008 GB04.08 size="-2">

Open the catalog to page 12

www.hydrovane.co.uk industry revolves around > Hydrovane sales and service is available in countries throughout the world.For full details and enquiries please see www.hydrovane.co.uk Claybrook Drive, Washford Industrial Estate, Redditch, Worcs B98 0DS, UKT.+44 (0) 1527 525522 F.+44 (0) 1527 521140 98700-532E - 03/2007 CompAir UK Ltd 2007 size="-4">

Open the catalog to page 13
