Automatic Air Impact Markers
24Pages

Model 78 Mite-E-Mark Double acting air impact marker 4 Model 78 How to Order 4 Model 78 Dimensions 5Model 88: 3 Ton single acting air impact marker 6 Model 88 How to Order 6 Model 88 Dimensions 7Model 98: 8 Ton single acting air impact marker 8 Model 98 How to Order 8 Model 98 Dimensions 9Model 288: 3 Ton double acting air impact marker 10 Model 288 How to Order 10 Model 288 Dimensions 11Model 298: 8 Ton double acting air impact marker 12 Model 298 How to Order 12 Model 298 Dimensions 13Model 75S and 85S Robotic mount air impact marker > TM 14Slide-A-Mark double acting air impact markers...

Model 78 : This air operated marking tool offers 18 times the force of an air cylinder with the same bore. Compact construction allows this marker to be installed in limited space. x 2 basic styles include Standard or Submersible models Submersible models are specially coated in a non-corrosive material for additional protection. x Foot or Rear mounting styles x The Keyed rod is to maintain character orientation, and the non-keyed rod allows the characters to rotate and is a smaller unit x 4 Different rod styles to hold the stamps offer multi-character square AӔ pockets, and single...

Model 78 Dimensions Typical Application for Model 78 5 >

Model 88 3-TON : The Columbia model 88 impact marking cylinder is a rugged air cylinder with a built in stamp holder at the rod end. The 88 delivers a powerful impact blow of up to 3-tons at 80psi. The shock absorbing patented bumpers at both ends of the stroke to prevent damage to the marker when bottoming out on the forward stroke and reducing the shock on return stroke. The model 88 is a dependable marker at a very low investment cost. The rod has a spring return action while an efficient pressure venting system allows an instantaneous return stroke. Model 88 air impact markers have a...

x OAS style rod is similar to OA style rod, with wider 3/8 pocket x Custom mounting plates available upon request Ԗ Please note that mounting plates can not be removed after purchase x Proper backup required for parts being marked > Shift & Operator Identification

Model 98 8-TON : The Columbia model 98 heavy duty impact marking cylinder is similar to the model 88 marker. However, the 98 delivers a much greater impact force (up to 8-TONS at 80psi) the 98 also has patented shock absorbing patented bumpers at both ends of the stroke to prevent damage to the marker when bottoming out on the forward stroke and reducing the shock on return stroke. The rod has a spring return action while an efficient pressure venting system allows an instantaneous return stroke. Model 98 air impact markers have a keyed non-rotating rod and 2.5 of stroke. x 3 Mounting...

x Custom mounting plates available upon request Please note that mounting plates can not be removed after purchase x OAS style rod is similar to OA style rod, with wider 3/4֔ pocket x Proper backup required for parts being marked >

Model 288 3-TON : The patented design of the 288 gives a marking pressure of three tons or 6,000 lbs which results from using 2.25 stroke with 80 psi air pressure. x 3 basic styles include Standard, Extreme Industrial, or Submersible. Standard models are great for rugged industrial marking. Extreme Industrial models are specially coated in a non-corrosive material for additional protection. Submersible units are both coated and are keyless and offer reliable marking in leak test applications. x 3 Mounting styles include standard angle bracket, reverse angle bracket and straight sub-plate....

StrokeOptionsDim A Dim B 2 ݔ 2.25 4.03 4 3.75 5.53 6Ԕ 5.75 7.53 x x Custom mounting plates available upon request Please note that mounting plates can not be removed after purchase OAS style rod is similar to OA style rod, with wider 3/8֔ pocket x Proper backup required for parts being marked >

Model 298 8-TON : The patented design of the 298 gives a marking pressure of eight tons or 16,000 lbs which results from using 2.25 stroke with 80 psi air pressure. x 3 basic styles include Standard, Extreme Industrial, or Submersible. Standard models are great for rugged industrial marking. Extreme Industrial models are specially coated in a non-corrosive material for additional protection. Submersible units are both coated and are keyless and offer reliable marking in leak test applications. x 3 Mounting styles include standard angle bracket, reverse angle bracket and straight sub-plate....

StrokeOptionsDim A Dim B x Custom mounting plates available upon request Please note that mounting plates can not be removed after purchase > 2 ֽ 2.25 4.88 4Ԕ 3.75 6.38 x OAS style rod is similar to OA style rod, but has 3/4 wide pocket > 6Ԕ 5.75 8.38 x Proper backup required for parts being marked >

Model 75S and 85S : Compact lightweight design, these single action air hammers are pressure activated. Mount onto robotic arm and present to part, or vice-a-versa. The force required for actuation is equivalent to the air pressure being used. . x Two basic styles of this air hammer look identical. The internal difference offers two power ranges. The maximum marking pressure for the model 75S is 1500 at 80 psi, and the maximum marking pressure of the model 85S is 2500 at 80 psi. x Four bolt holes are located at the back of the marker for easy installation. (4) 5/16 tap x .62 deep equally...

The SLIDE-A-MARK operates as follows: SLIDE-A-MARK 6 ton to 10 ton: The Columbia SLIDE-A-MARK series heavy duty marking cylinders offer a patented soft-impact marking action and low noise level, making it ideal for mounting into existing automation. The SLIDE-A-MARK eliminates costly approach slides for reaching into parts or fixturing which contain clearance issues. 1)marker approaches work piece (part) x The telescoping action of the Slide-A-Mark series makes this marker ideal for the use of stamp holders for extended marking legends, and numbering heads. CMT SelectӔ series of numbering...

Model 451 4-TON : This model is the smallest of Slide-A-Mark series. The solid cast iron construction contributes to the quiet marking capabilities of this system. The Slide-A-Mark feature acts as a self clamping device, and allows for minimal fixturing. Radial rod orientation becomes infinite by loosening the front collar clamp on the rod. x 3 Standard rod styles to hold the stamps offer multi-character OA or OAS63, and single character OB x 2 different approach strokes: 2 ֽ and 4 Խ x Integrated position sensors offer the added benefit to integrators x This marker comes standard in the...
