Catalog excerpts
PRODUCTINFORMATION PRODUCTINFORMATION > CogsdillTool size="-1">
Open the catalog to page 1ENGINEERED SPECIALTY TOOLING SOLUTIONS > FOR THE WORLDWIDE MACHINE TOOL INDUSTRIES ■ Cogsdill Tool Products, Inc. of Camden, South Carolina,USA > corporate headquarters ֢֠ Cogsdill-Nuneaton Ltd. of Nuneaton, England > subsidiary of Cogsdill Tool Products TOOLMAKERS TOOLMAKERS SINCE SINCE
Open the catalog to page 2■ Roll-a-Finish > tools ,available from stock and easily adjustable for burnishing I.D.s and O.D.s. ֠ Universal > TM Burnishingtools , for burnishing shafts,faces, tapers, contours, and relatively large IDs; tool designs to suit any part size or configuration, or any turning machine. ■ Bearingizing tools , forburnishing I.D.s in parts with thin walls or irregular wall thicknesses, or in applications where porosity retention or extremely close tolerances are required. ■ CX External Roller Burnishing machines ,for burnishing shafts or cylindrical surfaces of any length. ■ for salvaging...
Open the catalog to page 3■ Burraway > and Burr-off > ή ■ Ellipti-Bur > , for deburringirregular hole surfaces generated by drilling into curved surfaces or at an angle. ֠ Flipcut > TM , for back-spotfacingand back- or front-chamfering operations; from one side, in one set-up. mechanical hole-deburringtools, available from stock in popular sizes for removing burrs from the front, back, or both sides of drilled holes in one pass. ■ Nobur Tool > , for removingsevere burrs and producing non-qualified chamfers on multi-walled parts and intersecting holes, where production requirements are low. ֠ Micro-Limit , for...
Open the catalog to page 4֠ Tools, holders, andsetting fixtures: ■ Custom tool design and manufacture ■ Various shanks, including HSK and ABS > * complete reaming and boring systems ֠ Multiple steps ■ Standard program for popular hole sizes, with fast delivery ■ Single, replaceable blade supported by guide pads for stability and alignment ■ Carbide, PCD diamond, or coated blades ■ Carbide, PCD diamond, or cermet guide pads > *License/Komet 3 size="-1">
Open the catalog to page 5■ AR Series automaticrecessing tools, for machining internal or external grooves and recesses on virtually any type of machine ■ Generating heads , for performing multiple operations faster, moreeconomically, with better quality, and at one spindle location ■ Precision chamfering tools, for generatingcontrolled chamfers on both sides of drilled or reamed holes, and for back- chamfering and deburring operations ■ Nobur > automaticrecessing tools, for deep bore recessing and producing multiple grooves > 4 size="-1">
Open the catalog to page 6■ Single-slide facing,boring, and contouring heads , for multipleoperations in one set-up ■ Valve-seat pocket tools , with rigid cuttersupport and in-bore piloting for very accurate, high- quality, chatter-free finishes deep in bore cavities ■ Complete tooling systems for performingboring, facing, taper boring, contour boring, deep-cavity boring, grooving, back- spotfacing, and chamfering operations on horizontal boring machines with programmable inner quills ■ Double-slide boring and contouring tools ,for balanced cutting action at higher cutting speeds > 5 size="-1">
Open the catalog to page 7TOOLMAKERS TOOLMAKERS SINCE SINCE COGSDILL TOOL PRODUCTS, INC. > Mailing Address P.O. Box 7007Camden, SC USA 29021-7007 Ph. (803) 438-4000 Fax (803) 438-5263 www.cogsdill.com cogsdill@cogsdill.com > Shipping Address 1001 Guion Drive Lugoff, SC 29078COGSDILL-NUNEATON LTD.Tenlons Road Nuneaton, England CV10 7HR Ph. +44 (0) 2476 383792 Fax +44 (0) 2476 344433 www.cogsdill.co.uk > COGSDILL TOOL PRODUCTS, INC. Brochure 024 U.S. 7-07 COPYRIGHT 2007COGSDILL TOOL PRODUCTS, INC. size="-4">
