Delta-NOx - Low NOx Burners
Product catalog summary
Introduction
The Delta-NOx 2001 burner by COEN is designed to provide clean combustion and powerful results, setting a new standard for packaged boilers with its lower NOx emissions, reduced energy consumption, higher turndown, and simpler design compared to conventional burners.
The Delta-NOx 2001 burner by COEN is designed to provide clean combustion and powerful results, setting a new standard for packaged boilers with its lower NOx emissions, reduced energy consumption, higher turndown, and simpler design compared to conventional burners.
Performance and Specifications
The Delta-NOx burner achieves NOx emissions between 0.06 and 0.1 lbs/mmBtu when firing natural gas, without the need for flue gas recirculation (FGR). It supports a capacity range of 20 to 380 mmBtu/hr and is compatible with a wide range of gaseous and liquid fuels. The burner features a venturi design for superior air distribution and reduced pressure drop, contributing to its energy efficiency and low operating costs.
The Delta-NOx burner achieves NOx emissions between 0.06 and 0.1 lbs/mmBtu when firing natural gas, without the need for flue gas recirculation (FGR). It supports a capacity range of 20 to 380 mmBtu/hr and is compatible with a wide range of gaseous and liquid fuels. The burner features a venturi design for superior air distribution and reduced pressure drop, contributing to its energy efficiency and low operating costs.
Application
A hazardous waste incineration facility required an efficient replacement burner for its watertube boiler. The existing burner had limited fan capacity and high CO emissions. COEN's Delta-NOx burner was installed, reusing existing components to reduce retrofit costs, and included additional components and services such as the throat assembly, control valve, and turnkey installation.
A hazardous waste incineration facility required an efficient replacement burner for its watertube boiler. The existing burner had limited fan capacity and high CO emissions. COEN's Delta-NOx burner was installed, reusing existing components to reduce retrofit costs, and included additional components and services such as the throat assembly, control valve, and turnkey installation.
Results
The installation of the Delta-NOx burner resulted in significant improvements: NOx emissions averaged 0.066 lbs/mmBtu, representing a 60% reduction; CO emissions averaged 0.033 lbs/mmBtu, an 85% reduction; steam capacity increased by 20% with the existing air fan; and fan operating horsepower was reduced by 10%, eliminating the high costs associated with FGR. The burner was set for automatic operation within one day.
The installation of the Delta-NOx burner resulted in significant improvements: NOx emissions averaged 0.066 lbs/mmBtu, representing a 60% reduction; CO emissions averaged 0.033 lbs/mmBtu, an 85% reduction; steam capacity increased by 20% with the existing air fan; and fan operating horsepower was reduced by 10%, eliminating the high costs associated with FGR. The burner was set for automatic operation within one day.
Design Features
The Delta-NOx burner is designed with no moving parts, ensuring reliability and low maintenance. It includes unique features such as "Delta-Spud" radial gas injectors and secondary axial gas spuds to reduce NOx emissions further. Optional features include an auxiliary oil atomizer and removable spuds for firing refinery gases.
The Delta-NOx burner is designed with no moving parts, ensuring reliability and low maintenance. It includes unique features such as "Delta-Spud" radial gas injectors and secondary axial gas spuds to reduce NOx emissions further. Optional features include an auxiliary oil atomizer and removable spuds for firing refinery gases.
Conclusion
COEN's Delta-NOx burner offers a reliable, low NOx solution with easy installation, low operating costs, and safe operation, making it an ideal choice for industrial watertube boiler applications.
COEN's Delta-NOx burner offers a reliable, low NOx solution with easy installation, low operating costs, and safe operation, making it an ideal choice for industrial watertube boiler applications.
See more
Catalog excerpts
When you need a simple and reliable low NO > x burner designed to optimize system efficiency and emissions performance, you are ready for COENs Delta-NO > x burner. Our industry-leading engineers crafted this simple yet rugged burner to have no moving parts, allowing its venturi shape to provide uniform air distribution while lowering the airside pressure drop. The resulting decrease in fan horsepower is just the beginningof this low cost, low NO > x solution.COENҒs Delta-NO > x burner achieves between 0.06 and 0.1 lbs/mmBtu NOx, firing natural gas without the maintenance and expense of flue...
