Overview

This document serves as a comprehensive technical catalog detailing plastic and mechanical protection components used in ceramics plant machinery. It includes multilingual descriptions (Italian, English, German, Spanish), product codes, precise dimensional data, and customization options to facilitate component selection and ordering.

1. Supports Unit

This section catalogs various support components essential for ceramic machinery, including:

• Rod Supports: Multiple types with M10 nut seats, available in short, long, squareholder, and nutholder variants (codes 2030000–2030011).
• Bladeholder Supports: 40mm bladeholder supports with adjustable inclination in short, medium, and long versions (codes 2030050–2030052), customizable on request.
• Fixing Clamps and Half-Clips: Clamps without pins, with or without lateral holes, and half-clips for M10 and M12 sizes (codes 2030012, 2030013, 2030002, 20300001).
• Knobs and Fixing Pins: Various knobs differing in diameter and length, fixing pins for prism components, and prismatic nuts (codes 2030017, 2030030, 2030031).
• Blocks for Slots: Blocks designed for slots with washer or nut seats (codes 2030047–2030104).
• UCP Connections: Tubular connections for 40mm and 60mm diameter components (codes 2030075, 2030076).
• Clips and Hooks: Clips with optional customized covers (codes 2030015, 2030016).

2. Guards Unit

This section focuses on protective components, primarily for pulleys and finger guards:

• Finger Guards: Spike-like guards for pulleys of diameters 60mm, 80mm, 170mm, 230mm, and 250mm, including standard and "B" type with locking pawls (codes 2030063–2030085).
• Integral Protections: Full pulley protections for diameters 170mm, 230mm, and 250mm, with "B" type variants (codes 2030035N–2030119).
• Support Covers: Covers for UCP supports of 30mm and 35mm diameters (codes 2030062, 2030079).
• Trailing Parts for Profiles: End closures including type "B" (codes 2030034, 2030082).
• Protection Casings: Small type protection casings (code 2030038).

3. Disk Pack and Pulleys Units

While mentioned, detailed specifications for Disk Pack and Pulleys Units are partially included:

• Disk Packs: Various disk packs for glazing machines differentiated by thread size (M49x1.5, M54x1.5), diameter, thickness, and drilled ring variants for inverter use. Accessories include spools, discs, threaded rings with flat supports, stainless steel dropbreaker stems, and gaskets for Ø49 and Ø54 (codes vary).
• Pulleys: Single and double groove pulleys ("B" type, Ø60) with optional bearings. Accessories include base supports for shafts, seat supports, and 90° clamps (codes vary).

4. Protection Cases and Sheet Undercases

Three sizes of protection cases are detailed with dimensional parameters and unique codes:

• Small (Type "Klein"): L=575mm, I=360mm, R=140mm, R1=75mm, D=70mm, S=4.0mm; Code: 2030039
• Medium (Type "Mittel"): L=700mm, I=435mm, R=180mm, R1=85mm, D=75mm, S=4.0mm; Code: 2030040
• Large (Type "Gross"): L=462mm, I=395mm, R=83.5mm, D=12mm, S=1.2mm, A=100mm, B=40mm; Code: 2030041

Sheet undercases and clinched cases with internal protection are also available in corresponding sizes with codes 2030042 to 2030046 and customizable options.

5. Motor Reducer and Motovariator Covers

Protection cases for motor reducers and motovariators are specified with dimensions and codes (20300003, 2030120, 2030121). Some models feature right/left removable semi-parts to facilitate maintenance.

6. Silicone Suction Cups

Silicone suction cups are offered in diameters Ø50, Ø60, and Ø80, with detailed dimensional data and product codes, intended for handling or gripping applications.

Critical Information and Recommendations

• All components are identified by unique product codes and multilingual descriptions to support international users.
• Customization options are widely available for dimensions, diameters, lengths, and specific features.
• Dimensional data is provided in millimeters and is essential for ensuring compatibility and proper installation.
• Material specifications are provided for certain parts, such as stainless steel dropbreaker stems.
• Accessories like clamps, supports, and gaskets complement main units and should be selected accordingly.
