Clemco Industries Corp. • ISO 9001 Certified

Open the catalog to page 1

CLASSIC BLAST MACHINE

Open the catalog to page 2

Abrasive blasting is tough on equipment, employees, and you. For more than 75 years, for professional contractors and for industrial operations, Clemco has made abrasive blasting easier. Clemco Classic Blast Machines are rugged, reliable, and versatile. Models range in size from 0.5 cuft to 20 cuft, and come as the blast machine only or with a complete machine system. A complete system includes the blast machine, remote controls, a nozzle, couplings, blast hose, an Apollo Supplied-Air Respirator, an air filter, and spare parts — which are easy to install for quick maintenance. Popular Uses...

Open the catalog to page 3

Classic Blast Machines Blast Machine Construction 0.5 cubic foot capacity Clemco’s smaller machines are light, transportable, and industrial quality. Maximum working pressure 125 psi. • Pressure vessels built to ASME code. Most models registered in most Canadian provinces. • Concave head stores abrasive for loading. • Conical bottom ensures smooth abrasive flow and complete emptying. 0.5-cuft and 1-cuft systems include the Apollo 20 Supplied-Air Respirator. 1 cubic foot capacity Tall and slim, can be moved empty with ease from blast site to blast site. Maximum working pressure 125 psi....

Open the catalog to page 4

3-cuft and Larger Machines Have a 150-psi Working Pressure A midsize blast machine, a favorite of rental yards. 6 cubic foot capacity Clemco’s most popular blast machine. Ideal for professional blasting contractors, shipyards, railcar re-man facilities, and large-scale industrial production. 3 cubic foot capacity 8 cubic foot capacity The lower height of the Lo-Pot Blast Machine eases abrasive loading. Dual blast chambers permit continuous blasting. The 8-cuft machine can be equipped with twin outlets, allowing two operators to work without interruption. 6 cubic foot capacity Lo-Pot

Open the catalog to page 5

10 cubic foot capacity Stationary models are suitable for industrial use or applications requiring a large-volume, yet economical, blast machine. ▲ Model 3680 20 cubic foot capacity Stationary models adapt to fixed sites, or to custom truck-mounted or trailer-mounted systems.

Open the catalog to page 6

Self-cleaning exhaust muffler greatly reduces bleed-off noise. Pop-up valve umbrella (optional) relieves load pressure when hopper is in place. Fast, safe TLR Remote Controls with solid brass valves built for years of dependability. Chrome-plated, forged-brass ball valve with brass body for durability and long service life. Flexible pusher line eases valve replacement and also guarantees air flow without pressure loss caused by elbows. Semi-elliptical head for more abrasive storage. Urethane-coated pop-up valve with external sleeve for long life and fast pressurization. Large 6” x 8”...

Open the catalog to page 7

Remote Controls Abrasive Trap Diaphragm Outlet Valve (optional) Muffler (order separately) Piston Outlet Valve Inlet Valve Twinline Hose RLX Control Handle ACS Switch Single-Line ACS Hose Auto Quantum Valve TLR 300C Pressure-Release Pneumatic Systems feature an abrasive cutoff system (ACS), which enables operators to shut off the abrasive flow for clearing the blast hose and for blowing down surfaces after blasting. These remote control systems include inlet and outlet valves, an abrasive trap, and the air-operated normally closed Quantum Abrasive Metering Valve. Also available in electric...

Open the catalog to page 8

1. Piston Outlet Valve 2. Diaphragm Outlet Valve (optional) 3. Muffler (order separately) 4. RLX Control Handle 5. Twinline Hose 6. Inlet Valve 7. Petcock 8. Abrasive Trap 1. Abrasive Trap 2. Diaphragm Outlet Valve (optional) 3. Muffler (order separately) 4. Piston Outlet Valve 5. Inlet Valve 6. RLX Control Handle 7. Electric Cable 8. to 12V or 120V cable source 9. Control Panel TLR 300 Pressure-Release Pneumatic Systems operate on the return-air principle. A handle installed at the nozzle connects pneumatically to inlet and outlet valves on the blast machine. With the safety petcock on the...

Open the catalog to page 9

One of the most important components of a blast machine is its abrasive metering valve. The correct valve for your application will promote efficient blasting and reduce maintenance requirements on the machine. The Manual Quantum, Auto Quantum, and FSV Valves feed abrasive into the air stream at a 45° angle. This design eliminates turbulence, minimizes wear on fittings, and ensures smooth, consistent media flow. Media & Air Air The Manual Quantum Valve (MQV) handles all types of media: mineral, slag, and metallic. Its design allows for precise metering and easy maintenance. It fits machines...

Open the catalog to page 10

Standard Pop-up Dimensions Working Capacity Portable or Piping ACS Remote Controls Metering Valve & Model Dia. X Height Pressure in Cuft. Stationary (I.D.) Option Pneu. or Electric Valve O-ring NOTES: Remote control systems have valves that match the sizes of blast machine piping, and they come in models that vary to suit blasting applications. Pneumatic remote controls work best with blast hose lengths up to 100 ft. Electric remotes (pneumatic valves controlled electrically) are for hose lengths greater than 100 ft. TLR 300D and 300DC Remote Controls feature a diaphragm outlet valve. The...
