- Galvanometer Optical Scanner
Galvanometer Optical Scanner
Galvanometer Optical Scanner
This document provides comprehensive technical specifications and application examples for various models of Galvanometer Optical Scanners, including GVM-0930S, GVM-0930L, GVM-1445S, GVM-1445L, GVM-2260, GVM-2280, and GVM-2510. These scanners are utilized in applications such as laser marking, microscopy, image capturing, and high-speed printing.
The scanners are characterized by fast response, low inertia, high torque, high linearity, and positioning accuracy. They also exhibit superior temperature characteristics with minimal effects from humidity.
Each model has distinct mechanical and electrical specifications, including maximum scan angle, rotor inertia, coil resistance, and torque constant. Detailed tables for each model are provided.
Models are chosen based on scanning angle, mirror inclusion, cable length, and shaft form. Custom options are available for specific needs.
Mirrors are selected based on substrate material, coating, and assembly. Reflectance data and assembly drawings are included.
Details on connector pin sequences and dedicated connection cables are provided for each model.
Handling precautions and notes on specifications emphasize the importance of using the correct driver and mirror combinations.
The document serves as a comprehensive guide for selecting and using Galvanometer Optical Scanners, providing all necessary technical details and application guidance.
This section provides detailed specifications and guidelines for the Galvanometer Optical Scanner and its components, including mirrors and servo drivers. It covers mirror assembly, coating options, scanner types, and control systems.
Reflectance data for mirrors at a 45° incident angle is outlined, with graphs showing reflectance percentages across different wavelengths. Mirror models, laser beam diameters, substrates, and recommended coatings are specified. Coating options include Gold (Au) for CO₂ lasers, Silver (Ag) for visible ray lasers, and Dielectric Multilayer Coating for YAG lasers.
Details on mirror assembly drawings and mounting angles are provided. Mechanical angles for different laser diameters are specified, with advice to contact sales representatives for angles exceeding ±10°.
The GVD Series servo drivers offer P Control and PI Control systems. P Control is suitable for high-speed settling, while PI Control ensures high position repeatability. Specifications for different models (GVD0, GVD1, GVD2) include power voltage, operating current, input impedance, and protection features.
Specifications for galvanometer optical scanners and drivers include power voltage, maximum operating current, peak current, input/output signals, and ambient temperature range. External layout drawings with dimensions are also provided.
Proper handling and installation are emphasized to prevent damage or malfunction. Cautions for wiring, handling precision parts, and environmental conditions are included. A warranty section outlines terms for product repair within one year of delivery.
Definitions for terms like non-linearity, offset drift, thermal drift, and step response time are provided, explaining their significance in scanner performance.
Defects caused by misuse or mishandling, or those occurring more than one year after delivery, are the customer's responsibility for repair charges. Repairs are conducted at the company's location, with the customer covering shipping costs. The company is not liable for transit damages, and products should be packed with adequate cushioning.
Information is subject to change without notice. For updates, contact sales representatives or authorized distributors.
- Semiconductor Equipment: Includes lithography machines, wafer inspection systems, and more.
- Medical and Clinical Equipment: Features denture processing machines, virus protection masks, and robotic exoskeletons.
- Beauty and Cosmetic Equipment: Offers handpieces for nail art.
- Measuring and Analyzing Equipment: Includes LiDAR, electron microscopes, and surface roughness testers.
- Factory Automation and Robots: Provides laser marking machines, motors for robots, and more.
For further details, visit the website or contact through the provided links.
Catalog excerpts
Galvanometer Optical Scanner Galvanometer Optical Scanner ● GVM-0930S ● GVM-2260
Open the catalog to page 1
■ Galvanometer Optical Scanner (also called as galvo scanner / galvano motor / galvanometer mirror scanner) is the motor with high precision position sensor which detects position to adjust the scan angle of the mirror reflecting laser beam. It has a variety of applications in combination with laser beam, such as laser marker, confocal microscopes, and LiDAR. ■ Features ■ Examples of Application • Fast response / Low inertia / High torque • Laser marking • High linearity and positioning accuracy • Laser microscope • Superior temperature characteristics and minimal • Image capturing humidity effect...
Open the catalog to page 2
Scanner Type Registered Custom Number Scanning Angle (Mechanical Angle) 0:±10° Bumpers set for ±10° scanning 1 :±15° Bumpers set for ±15° scanning C : Custom Bumpers set for customized angle Cable Length 0 : GVM-0930, GVM-1445 / Connectors are placed on board 1 : 500mm 2 : 1000mm 3 : 2000mm 4 :3000mm C : Custom / Customized cable Iength Form of the Top Shaft With or Without Mirror 0 : Without mirror M : With mirror Mirror Angle Against Cable 0°(It is also 0 when without mirror) +45° + 45° to connector Custom Customized Shaft 0 : Straight (GVM-2260, GVM-2280 and GVM-2510 are all 0) 1 : With Mirror...
Open the catalog to page 3
■ This drawing indicates the combination of GM7 mirror assembly * The values of the specification are based on the combination of Citizen Chiba Precision Servo Driver and Mirror. * All angles shown are in mechanical angles. * We can provide the data including step response time by preferred combination of the mirror size and the scanner. Please contact our sales representatives for more details. (Some combinations may not be available. )
Open the catalog to page 4
■ This drawing indicates the combination of GM7 mirror assembly Spot Center Galvanometer Optical Scanner Scanner Reflective Surface SHIELD SHIELD − MOTOR WINDING ＋ MOTOR WINDING Spot Center Dedicated connection cable is required. ( Please see page10 for more details ) Reflective Surface ● Dedicated connection cable is required. ( Please see page10 for more details ) ■ Specifications Items Maximum Scan Angle (Mechanical Angle) Rotor Inertia Coil Resistance Torque Constant Peak Current Maximum Coil Temperature Weight Repeatability Offset Drift Gain Drift Step Response Time Input Signal Coil Inductance...
Open the catalog to page 5
■ This drawing indicates the combination of GM0 mirror assembly Spot Center Galvanometer Optical Scanner Scanner Reflective Surface connection cable is required. ( Please see page10 for more details ) Maximum Scan Angle (Mechanical Angle) Rotor Inertia 8.2 Reflective Surface ● Dedicated connection cable is required. ( Please see page10 for more details ) Spot Center A B PD COM AGC RETURN AGC IN SHIELD SHIELD SHIELD − MOTOR WINDING ＋ MOTOR WINDING Coil Resistance Coil Inductane Torque Constant Peak Current Maximum Coil Temperature Weight Repeatability Non-Linearity （± 10 °） Gain Drift 0.1 (Maximum)...
Open the catalog to page 6
Galvanometer Optical Scanner * The values of the specification are based on the combination of Citizen Chiba Precision Servo Driver and Mirror. * All angles shown are mechanical angles. * We can provide the data including step response time by preferred combination of the mirror size and the scanner. Please contact our sales representatives for details. (Some combinations may not be available. )
Open the catalog to page 7
Galvanometer Optical Scanner Scanner （Unit：mm） ①Sensor Connector ②Motor Connector Made by HIROSE ELECTRIC CO.,LTD. ■ This drawing indicates the combination of GM2 mirror assembly Reflective Surface Spot Center Reflective Surface Spot Center Maximum Scan Angle (Mechanical Angle) Rotor Inertia Coil Resistance Torque Constant Maximum Coil Temperature Weight Non-Linearity （± 10 °） Gain Drift Step Response Time Input Signal Offset Drift Output Signal Coil Inductance Peak Current Common Mode Differential Mode *Please see the caution below * The values of the specification are based on the combination...
Open the catalog to page 8
Galvanometer Optical Scanner * The values of the specification are based on the combination of Citizen Chiba Precision Servo Driver and Mirror. * All angles shown are mechanical angles. * We can provide the data including step response time by preferred combination of the mirror size and the scanner. Please contact our sales representatives for details. (Some combinations may not be available).
Open the catalog to page 9
Galvanometer Optical Scanner ■ GVM-2510 ■ Mirror + Scanner ■ This drawing indicates the combination of GM5 mirror assembly X-Axis Y-Axis * The values of the specification are based on the combination of Citizen Chiba Precision Servo Driver and Mirror. * All angles shown are mechanical angles. * We can provide the data including step response time by preferred combination of the mirror size and the scanner. Please contact our sales representatives for details. (Some combinations may not be available )
Open the catalog to page 10
Galvanometer Optical Scanner ■Sensor Connector
Open the catalog to page 11
■ Mirror Selection Mirror Substrate : Si (Silicon) • Recommended O Available *□ If combining GVM-1445L with rp10 mirror, the mirror holder will be fixed to the Registered Custom Number No Number: Standard Product *It is only used for customized products Laser Beam Diameter Substrate of Coating 0 : Au (Gold) coating (10.6 ^m) 1 : Ag (Silver) coating (1064 nm or 532 nm) 2 : Dielectric mutilayer coating (1064 nm) C : Custom I Customized coating Mirror Substrate 0 : Si Si Silicon C : Custom I Customized Substrate : <p3mm C : Custom I Customized mirror Mirror Shape X : X or first mirror Y : Y or second...
Open the catalog to page 12
Galvanometer Optical Scanner Mirror ■ Mirror Substrate / Recommended Coating Mirror Model Laser Beam Diameter Recommended Coating Mirror Substrate Au (Gold)/ Ag (Silver) Coating Au (Gold)/ Ag (Silver) Coating Dielectric Multilayer Coating (For YAG 1064nm) Au (Gold)/ Ag (Silver) Coating Dielectric Multilayer Coating (For YAG 1064nm) Au (Gold) Coating Dielectric Multilayer Coating (For YAG 1064nm) Au (Gold) Coating Dielectric Multilayer Coating (For YAG 1064nm) You can select the coating depending on the laser beam wavelength. ・ Au (Gold) Coating : Mainly for CO₂ laser (wavelength 10.6μm) ・ Ag...
