Service interruption solutions

Product catalog summary

Overview
The document discusses the RCM Residual Current Monitoring system by CIRCUTOR, focusing on its role in preventing service interruptions and enhancing energy efficiency. The system aims to prevent financial losses, improve competitiveness, and ensure safety by monitoring and controlling leakage currents.

Key Features

Service Interruption Prevention: The RGU-10/CBS-4 system prevents unexpected stops due to electric supply interruptions, reducing financial losses and maintaining competitiveness.
False Tripping Elimination: It eliminates unwanted tripping caused by false leakage current readings, often due to harmonic currents or transients.
Fire Risk Mitigation: The system detects and controls leakage currents to prevent fire risks.
Maintenance Cost Reduction: By preventing system malfunctions, it allows for corrective actions, reducing maintenance costs.
Safety Assurance: Guarantees system stability and safety for individuals.

System Specifications

Leakage Control: The RGU-10/CBS-4 is an ultra-immunized type A earth leakage protection system, available for installation on one or four lines.
Monitoring and Alerts: The system provides real-time leakage information via a display and communications channel, allowing for preventive actions.
Communication Protocols: Supports Modbus/RTU (RS-485) and Modbus/TCP (Ethernet) for remote control and management.
Prealarm Relay: Features a prealarm relay to set maximum leakage values and alert systems.

Conclusion
The RCM system by CIRCUTOR offers a comprehensive solution for preventing service interruptions, reducing costs, and ensuring safety through advanced leakage monitoring and control.

Catalog excerpts

Service interruption solutions RCM Residual Current Monitoring system Avoid service interruptions that generate high costs Technology for energy efficiency

Open the catalog to page 1

Avoid service interruptions that generate high costs Unexpected but avoidable stops or interruptions, related to an interruption in the electric supply, result in high financial losses. CIRCUTOR's RGU-10/CBS-4 is an RCM (leakage control) and ultra immunised type A earth leakage protection system, that offers the following advantages. Leakage control system and earth leakage protection relay installed on 1 line Leakage control system and earth leakage protection relay installed on 4 lines What does Circutor's RCM system offer? Prevents financial losses, improves competitiveness A loss of production,...

Open the catalog to page 2

How is the electric installation's safety and stability achieved? → By providing information before disconnecting the system Traditional earth leakage protection systems cause the unexpected disconnection of the system. However, CIRCUTOR's RCM system permanently monitors the installation's level of leakage, providing information through its display or communications channel, in order to implement preventive actions that guarantee the safety and stability of the system, preventing high financial losses and with only minimum investment, with very short amortization periods. Leakage level control...

Open the catalog to page 3

Solutions for service interruptions RCM Leakage control system Designed by: Communications Dept. - CIRCUTOR, SA Avoid service interruptions that generate high costs CIRCUTOR, SA - Vial Sant Jordi, s/n 08232 Viladecavalls (Barcelona) Spain Tel. (+34) 93 745 29 00 - Fax: (+34) 93 745 29 14 [email protected] CIRCUTOR, SA reserves the right to change any information contained in this catalogue.
