Catalogue Overview

This document is a multilingual catalogue (Spanish, English, French) presenting components for hydraulic cylinders manufactured by CICROSA HIDRAULICA. It focuses on various types of forks and related components used in hydraulic cylinder assemblies.

Section 1: Threaded Forks (Model FF)

This section details the specifications for threaded forks, designated as Model FF. Key parameters include dimensions labeled F, A, B, diameter Ød, lengths L and L1, number N, and dimension C. The weight of each component is also provided. These forks are designed for threaded connections in hydraulic cylinders.

Section 2: Weldable Forks (Model FS)

Here, weldable forks (Model FS) are described. The specifications include dimensions A, B, diameter Ød, lengths L and L1, number N, and dimension C, along with the weight. These forks are intended to be welded onto hydraulic cylinder assemblies, providing a secure attachment point.

Section 3: Fork Joint Hinges (ISO 8133 Standard)

This section covers female fork joints compliant with ISO 8133 standards. It includes detailed dimensional data such as CM, CK, CE, CL, ChF, KK, LE, ER, B, IR, and S, as well as dowel or stud thread specifications. The weight of each component is listed. Additionally, pins used for these fork joint hinges are specified with dimensions D, L, D1, L1, A, and B, and their respective weights. These components are critical for joint articulation in hydraulic cylinders.

Key Information and Best Practices

• All components are dimensioned precisely to ensure compatibility and interchangeability within hydraulic cylinder assemblies.
• Weights are provided to assist in design calculations and handling considerations.
• Compliance with ISO 8133 ensures standardization and quality for fork joint hinges.
• Selection between threaded, weldable, and standard fork joints depends on the application requirements and assembly methods.

The catalogue serves as a technical reference for engineers and technicians involved in the design, manufacturing, and maintenance of hydraulic cylinders, facilitating the selection of appropriate fork components based on mechanical and dimensional criteria.
