ZF Friedrichshafen AG Electronic Systems Cherrystraße 91275 Auerbach Germany Phone +49 9643 18-0 Fax +49 9643 18-1720 www.zf.com Product solutions on the basis of our switches Little helpers that make a big difference Safety must work Safety for the driver begins with operations that can be mastered intuitively, e.g. for adjusting the seat or for automatic transmission. It includes solutions for monitoring seatbelts as well as the tailgates or doors and stretches to steering column locks, gear shift gates or immobilizers, brake assistant systems, brake light switch, position indicators and much more. A selection of our applications for switches and switch assemblies: Switch with wiring harness for rear lock cylinder Control module for additional heating or flap positions in ventilation systems Micro switches for automotive applications Touch control module, shift lock for automatic transmissions Component carrier for side door latch with wet and dry-area connector Component carrier with insert moulded stamping grid for the three-dimensional configuration of micro switches on the trunk lock cylinder Three-dimensional stamping grid as component carrier in the side door latch 1 9 Driveline and Chassis Technology Drucknummer Component carrier for side door latch with sensors

Switch to safety – micro switches for vehicles The sub-suppliers in the automobile field are increasingly expected to integrate components into complex systems – a task that can only be accomplished in close co-operation with the vehicle manufacturers on development. Fuel consumption, emissions, weight and available space are to be reduced further, while simultaneously improving travelling comfort, safety and the dynamics of driving. In order to achieve this aim, innovative solutions and new products are necessary. The ZF Friedrichshafen AG takes responsibility for this and, with the microswitches,...

Snap Switches www.zf.com/pkw Technical specifications Technical specifications Series DJ Subsubminiature Subsubminiature Description Sealed switch, which is suitable for actuation at angles of up to 40 °C. Easy installation and smallest dimensions. Sealed switch with smallest dimensions. Models available up to 105 °C operating temperature. High contact stability. Max. Rating 2A 12 VDC 2A 12 VDC SPDT SPST SPDT SPST 15.2 x 6.4 x 8.15 (0.598 x 0.25 x 0.321) 14.7 x 5.4 x 6.8 (0.57 x 0.21 x 0.27) Button Series DK Button Straight Lever Simulated Roller Actuators Subminiature Description Sealed switch...

Snap Switches Sliding Contact Switches Technical specifications Technical specifications Series Series Check list for switch requirements Type Centre off Subsubminiature Subsubminiature Sealed switch at smallest dimensions. Suitable for actuation at angles of up to 40°. High contact stability by double redundant contact system. Description Switch in miniature construction with neutral middle setting and large actuation angle (±40°) to the left and right. Description Sealed sliding contact switch with smallest dimensions. Actuation vertically or with auxiliary actuator. Max. Rating 0,1A 12 VDC...
