JM-SVP/3 series
12Pages

Third Generation Servo Drive Series The Chen Hsong Group

Our products are developed through relentless pursuit of perfection and continuous innovation. The SVP/3 series of servo-driven injection moulding machines combines Chen Hsong's long tradition in optimised machine design with new concepts and modules, resulting in an offering that sets new standards in performance and ease-of-use. New ergonomic features, an enlarged power pack and structurally-strengthened platens yield large improvements in stability and precision, while further opitmisations in hydraulics reduce energy wastages due to pressure drops. The SVP/3 series cumulates from more...

Product images are for reference only and subject to change without notice

JETM ASTER Third Generation Servo Drive Series High-precision potentiom- eters for clamping, injection quality ensured Auto-adjust menchanical

External power outlets for Larger water manifold: EUROMAP 12 robotic 2 core pull standard, 2 Hydraulic gear mould easy connection of auxiliary 6/6 (268-328t) interface reserved for easy later adjustment Product images are for reference only and subject to change without notice

JETM ASTER Third Generation Servo Drive Series Principle of Clamping unit Main components of clamping unit Toggle speed diagram Cross Head Tail Platen Large Shaft EB Long Toggle ED Movable Platen EE Ejection Unit EE] plate^3^ ^ Tie Bar Nut ^ Mould 5-point toggle clamping system Mould open Mould close Well structure design, even loading distribution Large distance between tie bars, widely apply to different molding parti Fast mold open/close, short cycle time Large clamping deep cavity product hence durable clamp

Show case

JETM ASTER Third Generation Servo Drive Series

Ultimate Energy Saving Saves up to 80% of electricity compared to traditiional fixed pump systems* Ultimate Response The response speed is more than double of a variable displacement pump Ultimate Precision and Repeatability Up to 0.5% repeatability even under extremely low speed and prolonged holding conditions Long Operational Life Low oil temperature conserve cooling water and reduces the need for hydraulic oil thus extends the useable lives of hydraulic parts High Energy Saving Servo Pump All Electric Variable Pump Long Operational Life Cost Effective Servo Pump Long Holding Pressure...

Third Generation Servo Drive Series JETMASTER Third Generation Servo Drive Series Remark: The technical parameters above are for reference only and discrepancies may arise in different circumstances. The company keeps upgrading the products and reserves the right to change the product specifications and parameters without prior notice. The final interpretatation to the above specifications and parameters belongs to the company.

Mould Platen
