Catalog excerpts
sound measurement
Open the catalog to page 12 Progress driven by research experience We have a highly qualified team of professionals, made up of specialist engineers from the fields of acoustics, mechanics, electronics, computing and electromagnetic compatibility. CESVA participates on a variety of national and international committees for the creation and revision of regulations and standards. This has enabled us to become a pioneer in the sector. innovation “Single measurement range”, “simultaneous measurement of all functions”, “Bluetooth technology in insulation measurements” and “sound level meters with measurement protocols”...
Open the catalog to page 2AC006 (cable included) EPE accelerometer for the measurement of vibration in buildings (ISO 2631-2). Sensitivity: 1000 mV/g. Frequency range (± 10%): 0.2 Hz to 2600 Hz. AC001 (cable included) IEPE Accelerometer for the verification, analysis and measurement of machinery vibration. Sensitivity: 100 mV/g. Frequency range (± 10%): 0.3 Hz to 14 kHz. Features • Class 1 IEC 61672 and ANSI. • Real-time spectrum analyser with one-third octave bands: 10 Hz to 20 kHz (EF310 module); and octave bands: 31.5 Hz to 16 kHz. • Simultaneous measurement of 84 parameters with a single measurement range: 23 to...
Open the catalog to page 34 Features • Class 1 integrating sound level meter, in line with IEC 61672 and ANSI. • Real-time octave band spectrum analyser 31.5 Hz–16 kHz. • Simultaneous measurement of 54 parameters with a single measurement range: 23 to 140 dB peak, with A, C and Z frequency weightings. • Detachable preamplifier for use with extension cables and outdoor kit. • Capture Studio software included. Applications • Building acoustics. Measurement of sound insulation in octave bands (quality control), acoustic comfort and room evaluation (NC/NR curves). • Evaluation of noise exposure in the workplace while...
Open the catalog to page 45 Features • Class 1 integrating sound level meter, in line with IEC and ANSI. • Simultaneous measurement with a single measurement range: 23 to 140 dB peak and A or C frequency weightings. • Detachable preamplifier for use with extension cables and outdoor kit. • Memory for recording the time history of the measurement. Programmable Leq acquisition time. • Real-time PC communication software for downloading data, producing reports, displaying data, calculating Leq and measurement interval percentile calculations. Applications • Technical inspection of vehicles: measurement of vehicle...
Open the catalog to page 56 Features • Dosimeter DC112/DC112d complies with IEC 61252 standard and Directive 2003/10/EC. • Dosimeter DC112a/DC112k complies with ANSI S1.25 and OSHA, MSHA, DoD, ACGIH, NIOSH, etc. • Octave band evaluation of Personal Protective Equipment (PPE). • Stores time history in memory. • Evaluates noise exposure where measurement times are less than exposure times (projected parameters). • Battery or USB power supply. • Capture Studio software included. • Lower cost DC112d/DC112k model available without octave band analysis. Applications • Evaluation of workplace noise exposure as well as...
Open the catalog to page 67 Features • Vibrometer which meets the ISO 8041 standard and Directive 2002/44/EC. • Single measurement scale, independent of the application. • Simultaneous measurement of all parameters –with suitable weighting– for each application (HA, WB and building), displayed on a single screen. • Projected parameters: vibration evaluation where measurement time is less than exposure time. • Capture Studio software included. Applications • Evaluation of workplace vibration exposure: • Hand-Arm system (HA) 2002/44/EC and ISO 5349-2 • Whole body system (WB) 2002/44/EC and ISO 2631-1 • Evaluation of...
Open the catalog to page 78 Features • Meets Annex A of ISO 140-6 and 140-7. • Robust, light-weight and easy to handle. • Consists of 5 hammers with electronic impact control. • Manual or remote controlled operation via a PC (cable or Bluetooth® wireless). • Remote control software included. • Remote control MD005 (optional). • Overheating protection. • Includes transportation box with wheels. • Assembly BA005: internal battery and charger (optional). Features • Complies with ISO 140, ISO 3382-1/-2 and ISO 354. • Omnidirectional radiation diagram. • 123 dB Sound Power. • White, pink and filtered pink noise generator...
Open the catalog to page 89 BEFORE: Imports drawings, selects measurement points and verifies contour conditions. DURING: Automatically manages devices using Bluetooth® with a step-by-step guide to measurement. Indicates the position of equipment, starting/stopping of noise sources, and gives real-time reception and verification of the measurements taken by sound level meters. AFTER: Direct interaction with CIS in order to receive the final report on site. With this software, a number of CESVA sound level meter analysers can be converted into a wireless multichannel measurement system. The system is fully...
Open the catalog to page 910 Consists of an outdoor control cabinet AR054 which contains: • SC310 sound level meter to carry out sound measurements. • UC001 control and communications unit for the management of recorded data, recording of audio (mp3) and station position information. • GPS GS 353. • MR300 3.5G modem to upload data to a server. • BA123 power supply and battery to power the system in the event of a power failure. All data is processed and uploaded to the SERDAT data server. Features • The TA024 maintains the legal metrology of the SC310 sound level meter. • Simultaneously measures the functions...
Open the catalog to page 1011 CSE (Capture Studio Editor) software enables data captured by Dosimeters and Spectrum Analysers (CESVA SC310, SC-30, SC160, DC112 and VC431 vibrometer) to be edited. An intuitive and user-friendly tool for the extraction or deletion of any undesired time section. Permits the re-calculation of global and spectrum values for the desired section, as well as statistical information (maximums, minimums, percentiles). The mobile communications system for CESVA equipment is based on the GSM/GPRS standard and allows communication between different CESVA instruments (sound level meters and...
