REED RELAYS AND SWITCHES SOLID STATE RELAYS MAGNETIC SENSORS

Dear customers, dear readers, At celduc® we are very proud to be celebrating our 50th anniversary in 2014! Thanks to our expertise acquired over many years, celduc® is now considered a specialist in its field, and we collaborate with the biggest industrial groups worldwide. We are constantly improving at celduc® relais and would like to take advantage of this special occasion to introduce our new corporate visual identity and new logo. This new version of our product catalogue also gives us an opportunity to reconfirm our goals: Manufacturing innovative products of the highest quality, adapted...

From design to manufacturing celduc® relais controls the complete chain : design, development, production, testing and marketing. celduc® relais manufactures the most comprehensive range of Solid State Relays but has also developed its own production equipment to ensure the most efficient manufacturing methods. Thanks to this high-capacity and unique tooling, celduc® products can be found all over the world and have been recognized by the most renowned industrial companies. High quality products Quality is of paramount importance and maintained at all times, aided by our own specially developed...

Solid State Relays The advantages Solid State Relays (SSR) have compared to Electro Mechanical Relays (EMR) are well-known. Fully electronics, there is no moving parts inside SSR ; they have no audible noise, withstand significant vibration without operating problems, have fast response time, but most of all they have higher life-time expectancy. Used in appropriate operating conditions, SSRs have nearly unlimited life vs 100K cycles for EMRs. Thanks to their unlimited life-time SSRs don’t require any maintenance and prevent manufacturers from unforeseen machines/ production stop, which is a...

INTERFACE RELAYS - SLA / SLD - SLIM range (Miniature) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - SPA / SPD / SLA / SLD (Standard) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - XK - for DIN-Rail mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - SKA / SKB / SKL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . - SKH - integrated heatsink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . - SN8 - ultra-miniature and compact package . . . . . . . . . . . . . . . . . . . . . . - SHT - three-phase...

Interface relays SLIM atible with 100% comp anical electromech lays re The SLA / SLD solid state relays are 100% compatible with 5 mm pitch electromechanical relays. They can be soldered direct to PCBs or plugged into all din rail mountable bases. Every type of loads can be switched and those relays can withstand high current peaks that can be produced by loads such as electro valves, engines, coils, indicator, etc. The switching power is 2A/280VAC for SLA and 2.5A/60VDC or 4A/24VDC for SLD relays. Other miniature solid state relay options are available on request. Specifications SLA/SLD base...

Interface relays to control loads such as resistors, indicators, solenoids, transformers, motors, power contactor coils. These DIN-rail mounted products are available with AC and DC output options. They can also be supplied as dedicated motor control variants such as 2 and 3 phase switching and motor rotation reversal. All are fitted with LED indicators. Control voltage diode diode diode diode diode diode 1 pole AC random output 12,2x76,4x53 1 pole DC output 12,2x76,4x53 DC output - MOSFET technology Suffix D : removable terminals. Suffix R : removable spring terminals. XKLD0020 has all protections...

The SK range for PCB mounting is available in different models : SKA/SKB (AC output) or SKD/SKLD (DC output – see pages 25-26) > SKA up to 5A 230 or 400VAC with built-in voltage protection, ideal for solenoid or motor control. > SKB up to 5A 230 or 400VAC for resistive loads. Product reference Switching voltage Control voltage AC zero-cross output / normaly closed AC zero-cross output / most types of loads AC random output / most types of loads AC zero-cross output / resistive loads SKL for AC output with a ceramic substrate that can be mounted on a heatsink. The SKL is available with current...

The SKH range is a “ready to use” range with integrated heatsink. This relay is designed for PCB applications and when fitted with suitable heatsink, can control heavy loads in an ultra-miniature, physically compact package. Product Switching Current reference voltage SN842500 25A 24-280VAC Other references available : please contact us. Three-phase solid state relay in a single low profile package. This relay is designed for PCB applications in order to provide control of medium power in three-phase environments. Product Switching Current reference voltage SHT842300 3x25A 24-280VAC Other references...

Single Phase Solid State Relays All our solid state relays fitted with back to back thyristors (power products : single phase, two phase, three phase) now use TMS² technology with a very high life expectancy compared to the majority of products on the market (application note on request). Innovation Performances and Design ! > Versatile, easy and quick connections > Removable IP20 > Same screwdriver for outputs and inputs > Tightening on metal baseplate not on plastic > Removable control terminals > SSR, mains and load status. > Output voltage from 24 to 690 VAC (600V-1200V-1600V peak) > Very...

Single Phase Solid State Relays Designed for most types of loads > Zero cross with low zero-crossing level (<12V) > Voltage protection on input (transil) with very high immunity according to IEC/EN61000-4-4 > IP20 protection > Control current < 13mA for all the voltage range at any operating temperature > Control status LED Product reference SO842074 SO842974 SO843070 SO843970 SO845070 SO845970 SO848070 SO849070 SO863070 SO863970 SO865070 SO865970 SO867070 SO867970 SO868070 SO868970 SO869070 SO869970 HIGH VOLTAGE RELAY Control voltage Typical applications : Resistive loads (AC-51) > Zero cross...
