Introduction
Atmospheric air naturally contains impurities such as dust, hydrocarbons, and humidity. When compressed, these impurities can form abrasive and corrosive emulsions that damage distribution lines, pneumatic devices, and products, leading to air leakages, increased maintenance costs, production decreases, and loss of product quality.

Line Filters Overview
Ceccato Aria Compressa S.p.A. offers line filters designed to remove these impurities, ensuring efficient and reliable operation of compressed air systems. The filters are available in various series, each tailored for specific applications and levels of air purity.

Filter Series and Specifications

• Coalescence Filter (FM0): Filtration of 0.1 µm with residual oil of 0.1 mg/m³. Suitable as a pre-filter for dryers and de-oiling devices.
• Activated Carbon Filter (FCA): Removes oil and hydrocarbon smells with a residual oil of 0.005 mg/m³. Used in industries like pharmaceuticals and foodstuffs.
• Pre-Filter (FPRO): Filtration of 3 µm, ideal for protecting lines with high contamination of liquids and dust.
• High Efficiency Coalescence Filter (FMM): Filtration of 0.01 µm with residual oil of 0.01 mg/m³. Suitable as a post-filter for dryers and pre-filter for FCA series.
• Dust Filter (FPRE): Filtration of 1 µm, used in systems with high fine dust quantities.

Technical Features
The filters are equipped with various components such as pressure gauges, connection kits, and discharge systems to enhance functionality and safety. They are designed to operate within specific temperature ranges and pressures, with correction factors provided for flow rate adjustments based on working pressure.

Applications
The filters are suitable for a wide range of applications, including instrument systems, pharmaceutical and food industries, pneumatic transports, and general service air for tools and sandblasting.

Conclusion
Ceccato Aria Compressa S.p.A.'s line filters provide a comprehensive solution for maintaining high-quality compressed air, essential for modern automated plants and sophisticated devices.
