3,000-6,500 lb Capacity LP Gas Cushion Tire
14Pages

LP Gas Cushion Tire Lift Trucks Capacity: 3,000-6,500 lb

2C3000-2C6500 Series 2 4 Dependable Performance Engineered for maximum performance in a wide range of industries, the 3,000-6,500 lb capacity internal combustion cushion tire lift trucks provide quality solutions and come fully equipped with an extensive list of standard features. Cat® lift trucks set the standard for the ultimate lifting experience. Exceptional comfort, hardworking products you can depend on and industry-leading customer service make these lift trucks the only choice for your material handling needs. These rugged, compact lift trucks come with fuel-injected purePOWER®...

Fuel Type Base Capacity At 24 in Load Center (lb) 2C3000 LP Gas 3,000 2.1L 2C3500 LP Gas 3,500 2.1L 2CC4000 LP Gas 4,000 2.1L 2C4000 LP Gas 4,000 2.5L 2C5000 LP Gas 5,000 2.5L 2C5500 LP Gas 5,500 2.5L 2C6000 LP Gas 6,000 2.5L 2C6500 LP Gas 6,500 2.5L Model Engine Displacement 3

QUALITY Commanding Presence In control and delivering results. Your Cat lift truck will help keep the operator comfortable and productive. Comfortable Operation Operators of varying sizes can work long shifts comfortably in the standard full-suspension seat. An optional swivel seat and rear grab handle with horn button is available for high-shuttle applications. Adjustable seating for increased comfort 4 4 Exceptional Floor Space The open floor area, thick rubber floor mat and through-the-floor pedal design improve overall operator comfort. Foot direction control is an option for those...

Premium Display Panel The standard premium LED/LCD display provides productivity-enhancing tools that are helpful to the operator. Features such as an operator passcode system maintenance interval reminders ensure that the truck is running at Optimized Visibility Open overhead guards and narrow mast channels help improve operator visibility to the load and surroundings. Standard LED working lights illuminate the workarea while providing significant maintenance savings over traditional halogen or incandescent lights. A wide variety of options are available to customize the truck for operator...

RELIABILITY Step Up In Power These trucks aren’t built to sit on the sidelines. You can count on the 2C3000-2C6500 Series of internal combustion cushion tire lift trucks to deliver top performance throughout the shift. Environmentally-Friendly Engines The K21 and K25 purePOWER® engines work in the toughest conditions, while offering excellent fuel economy and low noise and vibration. The standard engine protection system (EPS) monitors performance and can help protect the system from damage. Increased fuel efficiency, lower emissions 6 6 Serviceability With up to 500 hour service intervals,...

Premium Standard Features This truck contains a number of features designed to protect your investment and lower your ownership costs, including ground speed control, Fuel Saver Mode, an underbelly screen to protect components from debris, the engine protection system and LED working lights. These features, while standard on Cat lift trucks, are often optional items or not available on competitive units. Conveniently-placed features for easy access Application options for improved cooling Application Options Options such as attachments, quad masts and specialty tires can customize the truck...

CUSTOMER SERVICE Delivering Real Material Handling Solutions A Cat lift truck purchase connects you to a variety of material handling solutions, including world-class service and support from the best dealer network in the industry. Cat Lift Trucks also offers the most comprehensive support programs in the industry. Highly-skilled service technicians, diverse parts inventory and an outstanding selection of service options, all help to reduce your total cost of ownership and keep your lift trucks performing at their best. Standing Behind Our Products We deliver peace of mind by helping your...

Parts Fast Or Parts Free* The Parts Fast Or Parts Free Guarantee ensures next-business-day delivery of all Cat lift truck parts, or they’re free, including freight. If your part doesn’t come in by the next business day, we pay for it. Parts when you need them Genuine OEM Parts When you buy from your local dealer, you can be assured that your OEM part is manufactured to meet original equipment criteria. Additionally, all Cat lift truck OEM parts come with a sixmonth, unlimited-hours warranty. Genuine Cat Lift Truck OEM parts Flexible Financing Options* Financing your next Cat lift truck is...

At rated load center Tire type Number front/ rear Lift with standard two-stage mast Maximum fork height (top of forks) Free fork height Thickness x width x length Fork spacing Out-to-out minimum / maximum Forward / backward Length to fork face Overall dimensions With standard tires, wide-axle With standard tires With standard tires, wide-stance Mast lowered Seat height Mast extended Minimum outside turning radius Load moment constant Minimum aisle - 90° stack - zero clearance w/out load 1 Travel speed loaded / empty Lift speed loaded / empty Lowering speed loaded / empty Drawbar pull Loaded...

Call-out numbers shown in the diagram correspond to the first column of the specifications chart. 14 20 11 17 2 19 18 12 13 66 65 22 62 15 13 13 63 16 21 13 23 Safety Standards These trucks meet American National Standards Institute/Industrial Truck Standards Development Foundation, ANSI/ITSDF B56.1. UL-Classified by Underwriters Laboratories, Inc., as to fire and electric shock hazard only. Types LP, LPS (optional), Industrial Trucks. Users should be aware of, and adhere to, applicable codes and regulations regarding operator training, use, operation and maintenance of powered industrial...

Quality Customer Service Reliability Experienced professionals at your local dealership and on our National Accounts Team can assist you with your lift truck purchase or lease. Your Cat lift truck dealer can provide options and additional visual and audible warning devices geared toward your specific requirements. Operator training programs are also available to boost productivity and to help reduce the potential for product damage and personal injury. LP Gas Cushion Tire Lift Trucks Capacity: 3,000-6,500 lb 1-800-CAT-LIFT | www.cat-lift.com | m.cat-lift.com Copyright © 2013 by MCFA. All...
