C8

Product catalog summary

Technical Specifications

Undercarriage: Overall width is 2350 mm, track shoes width is 500 mm, overall track length is 3236 mm. Travel speed ranges from 0 to 1.8 km/h, with a maximum gradeability of 20° and ground pressure of 8.2 N/cm².
Engine: Volvo model TAD 650 VE (EPA/COM III) with a rated power of 147 kW at 2200 rpm. Fuel tank capacity is 350 liters, and hydraulic oil tank capacity is 680 liters.
Mast: Available in lengths of 7600 mm, 10000 mm, 10440 mm, and 12440 mm. Stroke lengths range from 5600 mm to 10000 mm. Extraction force is 86 kN, and crowd force varies between 44 kN and 86 kN.
Clamps: Diameter ranges from 40 to 406 mm, with clamping force between 145 kN and 250 kN.
Rotary Head: Max torque is 20 kNm, and max speed is 223 rpm.
Dimensions and Weight: Length is 9087 mm, width is 2500 mm, height is 3130 mm, and weight of the rig is approximately 21500 kg, depending on the equipment mounted.

Jet Grouting Equipment

Includes Casagrande D21 hammer, double head with hammer, chuck, rotary head side movement, jet system, and various rod loaders with different specifications.
Additional equipment includes A2 winch with rope, cat head for A2 winch, 3 m extension for cat head, 15 m lattice extension for jet, auxiliary crane, pumps, lubricator, and travelling control from the control panel.

Applications

Equipment is used in various countries including Austria, France, Italy, Slovenia, and the U.S.A.
