C4
1 / 8 PagesView full catalog
C4
Product catalog summary
Technical Specifications Overview
Transport Dimensions: The overall width of the undercarriage is 1800 mm, with track shoes width of 300 mm and an overall track length of 2234 mm. The travel speed ranges from 0 to 1.8 km/h, with a maximum gradeability of 20° and ground pressure of 7 N/cm².
Engine: The equipment is powered by a Cummins QSB 4.5-TAA engine, compliant with EPA/COM III standards, delivering 82 kW at 2200 rpm. The fuel tank capacity is 170 liters, and the hydraulic oil tank capacity is 350 liters.
Mast Specifications: Two mast options are available: 2800 mm and 3350 mm strokes of the rotary head, with extraction forces of 45 kN and 30 kN, respectively. The crowd force is 27 kN and 30 kN.
Clamps: The clamps have a diameter range of 40 to 254 mm and a clamping force of 145 kN.
Rotary Head: The H800 rotary head offers a maximum torque of 8200 Nm and a maximum speed of 330 rpm.
Dimensions and Weight: The equipment measures 5570 mm in length, 1800 mm in width, and 2532 mm in height, with an approximate weight of 8000 kg, depending on the mounted equipment.
Jet Grouting Equipment: Includes Casagrande hammer D21, hydraulic chuck P114, and various pumps and extensions for jet grouting applications.
Optional Features: Various optional features are available to enhance the equipment's capabilities.
