Solid Carbide Milling Tools Leaflet - Metric
40Pages

Carbide grade: MT7 Sub-micron grade with Titanium Aluminium Nitride multi-layer coating (ISO K10-K20).To be run at medium to high cutting speeds. General purpose for all materials. Thread is generated in one pass.Spiral flutes allow smooth cutting action. Shorter machining time due to multi, 3 to 6, flutes. 2.2 mm and up cutting diameter. Threads up to shoulder in blind holes. Longer tool life due to special multi-layer coating. Same tool can be used for a variety of materials. Excellent surface finish. Low cutting pressure allows thin wall machining. Same tool used for R.H. and L.H....

E = ExternalC=3D=4E=5F=604=4 mm B = With Internal Coolant Cutting DiameterNo. ofFlutes ThreadProfileThe ApproximateCutting LengthShank DiameterThread Pitch > Z = Internal coolant through the flutes ISOWUNBSPTNPTNPTFNPSNPSF MillThread > 06 = 6 mm08 = 8 mm 10 = 10 mm 12 = 12 mm 14 = 14 mm 16 = 16 mm 20 = 20 mm

Carbide grade: MT7 Sub-Micron grade with Titanium Aluminum Nitride multi-layer coating (ISO K10 - K20).To be run at medium to high cutting speeds. General purpose for all materials. Due to the unique tool design, accurate geometries and high quality grade, the following are achieved: Threading from M1.2 x 0.25 (bore diameter 0.95).Working in high cutting speed.Short machining time. Low cutting forces thanks to the short profile. No broken taps.Threading up to shoulder in blind holes. Machining of hardened materials up to 40 HRc. >

Mini Mill Thread Cutting Diameter031 = 3.10 mmNo. of FlutesC = 3D = 4E = 5ThreadPitch Thread ProfileISOUNUNJMJ MTSH=HARDCUT Shank Diameter06 = 6mm08 = 8mm The ApproximateCutting Length >

Carbide grade: MT8 Sub Micron grade with Aluminium Titanium Nitride (AlTiN) multi-layer coating (ISO K10-K20).Extremely high heat resistant and smooth cutting operation, for high performance, and normalmachining conditions. General purpose for all materials. Enables machining in deep holes.Coolant through the flutes is very effective for deepholes.Spiral flutes allow smooth cutting action. Shorter machining time due to multi, 3 to 5, flutes. Longer tool life due to special multi-layer coating. THREADING: Same tool can produce a wide range of threads andpitches.Same tool can produce both...

G = End Millsfor GrooveMilling No. of FlutesC = 3D = 4E = 5 TI = Thread MillsPartial Profile60˚ R=Groove Radius05 = 0.5mm06 = 0.6mmW=Groove Width08 = 0.8mm10 = 1.0mm Shank Diameter06 = 6mm08 = 8mm10 = 10mm The ApproximateCutting Length 8 = 8mm10 = 10mm 40 = 40mm A60=Thread ProfilePartial Profile 60˚ Cutting Diameter05 = 5mm10 = 10mm >

Carbide grade: MT8 Sub Micron grade with Aluminium Titanium Nitride (AlTiN) multi-layer coating (ISO K10-K20).Extremely high heat resistant and smooth cutting operation, for high performance, and normalmachining conditions. General purpose for all materials.Optimal for milling,deburring and back chamferingDouble side cutting Spiral flute allows smooth cutting action >

No. of FlutesC = 3 ProfileAngleA90 = 90˚ A60 = 60˚ MiniChamfer Cutting Diameter015 = 1.5mm The ApproximateCutting Length Shank Diameter03 = 3mm05 = 5mm >

Copyright CARMEX Precision Tools Ltd. 2008 > Carmex MT Solid Carbide Metric 02/2008 >
