Wireless Smart Datalogger 4 analog inputs recorder with power supply generation for + 12/24Vdc @100mA transducers Technical Information Power Supply Measurements Acquired Possible Input Signals (up to 4) Wireless Smart Datalogger Four analog inputs datalogger designed for voltage measurement (0-5Vdc, 0-10Vdc, 0-25Vdc) or current (0-25mA) selectable using jumpers, capable of powering external transducers with a 12Vdc or 24Vdc power supply (up to 100mA). Measurements acquired are expressed in percentage of full scale. The radio module based on WINE protocol provides an excellent radio range and a very low battery consumption. With a backup memory onboard may store the last 64.000 samples per channel even if the wireless link is down. Through the configuration software the sampling interval may be set and two thresholds per channel can be activated. May be interfaced with the following store, processing and transmission modules: • MWDG-GSM • WDG-GSM • MWDG-4DI-GSM If necessary radio range may be extended using up to 32 WR11 (repeater/radio router) between the datalogger and the data acquisition module. The features shown may be subject to change without notice.
