Flap discs

Product catalog summary

Overview: The document provides specifications and details for various types of flap discs used in grinding and finishing operations. These discs are suitable for different materials and applications, including stainless steel, aluminum, metal sheets, marble, stone, glass, and non-ferrous metals.

Specifications: The flap discs are available in sizes of 115 x 22.23 mm and 180 x 22.23 mm, with different grit levels (40, 60, 80, 120) and types (T-27, T-29). The maximum RPM for 115 mm discs is 13,300, while for 180 mm discs, it is 8,500.

Types of Flap Discs:

Premium Z/A Abrasive: Combines zirconia alumina abrasive with surface conditioning material for blending and finishing in one operation. Suitable for stainless steel welds, aluminum, and metal sheets.
XL Flap Discs: Contain 50% more abrasive material, offering flexibility and efficiency in blending on concave surfaces. Ideal for high-alloyed steel, stainless steel, and heat-treated steel.
S/C Flap Discs: Silicon carbide coated, designed for marble, stone, glass, and non-ferrous metals. Provides blending and finishing in one operation, suitable for professional stone working.

Disc Types:

T-27: Best for grinding flat surfaces, efficient at angles of 0° to 15°.
T-29: Conical shape for contour and edge grinding, optimal at angles of 15° to 25°.

Key Benefits:

Reduces changing time, saving time and money.
More flexible than standard flap discs.
Provides excellent solutions for specific material applications.
