2011-2012 EDITION Din rail power supplies Short form

A wide range of power supplies All the power you need in your hand The current production of Cabur DIN RAIL power supplies is the result of significant investments in research and development which create innovative circuitry topologies thanks to the use of the most advanced technologies and components. Our power supplies are engineered and manufactured to achieve high efficiency and low power dissipation, as this is the key to compact dimensions, high power performances and high reliability at the same time, as required by demanding industrial applications. The range helps you select the product...

Home automation Specially designed for low profile panels • Compact dimensions • Save time and installation costs • Suitable for all voltage networks Convenience The performance of an industrial product at a convenient price • Cost effective price/ performance ratio • Compact dimensions, high reliability • Suitable for civil automation and general installations Efficiency Increase reliability and save energy • High efficiency reduces the temperature and power dissipation • Extremely compact dimensions • High current peak provides sure downstream overcurrent protections selectivity • Suitable...

Single phase switching power supplies with output power up to 70W for civil and industrial automation applications. The housings have the standard dimensions for installation in DIN modular panels, and are optimized for the deployment in the field of building automation. The high performance and compact size make them an excellent solution for low-depth electrical panels. The high efficiency and low dissipated power save energy and increase the life of the components. Recommended uses • Industrial Automation Applications • Applications in Civil and home appliance automation • General applications...

High Efficiency Designed to save energy and reduce working temperature DIN-rail single phase switching power supplies, specifically designed for applications in industrial automation panels and process control panels. They can deliver +60% to +80% of the nominal current for a sustained period keeping the output voltage constant; the alarm contact is controlled by a voltage threshold, and it switches when the voltage drops under 90% of the rated output value. Thanks to these features and to the numerous international certifications, this series of power supplies allows engineers to meet all the...

Integrated smart alarm contact Activated when output voltage decreases below 90% of rated value Extremely compact dimensions They are among the smallest on the market, optimising the use of space in the panel without compromising performance DIN-rail 3-phase switching power supplies specifically designed for applications in industrial automation control panels. They can deliver over +50% of the nominal current for a sustained period keeping a stable output voltage. The alarm contact is controlled by a voltage threshold and it switches when the voltage drops below 90% of the rated value. Thanks...

DIN rail switching power supplies with universal input 185 ... 550 Vac single phase and two-phase applications in industrial automation and process control. The input circuit technology makes them immune to surges caused by failures in the threephase networks with neutral wire, increasing application reliability. Compared to single-phase power supplies, this series has a higher reliability in industrial environments. The input circuit uses components with an operating voltage of 900 V, more resistant to voltage peaks present in industrial networks, than the components used in single phase power...

Single phase DIN rail power supplies for general applications in automation and installation. With particulary high quality / price ratio, these products are ideal and convenient for applications where loads do not require high peak currents. They can deliver over +40% of nominal current for a sustained period, keeping the output voltage stable and ensuring continuity of supply to the system. With these features, this range of power supplies enables designers to meet the requirements of the Machinery Directive, EN 60204-1, allowing the protection devices connected to the output to trigger quickly,...

Code Notes Series Battery pac k Code Input (AC) Output (DC) Notes Series Power supply wit h battery char ger 150W XCSC150C XCSC150B 120–230 V 120–230 V 24 V / 5 A 12 V / 8 A Supplies load and charges a battery Remote alarm signals Disconnects the battery before deep discharge Supplies load and charges a battery Remote alarm signals Disconnects the battery before deep discharge Code Input (AC) Output (DC) Notes Series Battery char ger accessory 150W XCSUPS1 XCSUPS2 26…28 V 12…15 V 24 V / 15 A 12 V / 15 A Allows a power supply to charge a battery Remote alarm signals Disconnects the battery before...

10 | Cabur Power Supplies Code Input (AC) Output (DC) Overload limit Notes Series Code Input (AC) Output (DC) Overload limit Notes Series Code Input (AC) Output (DC) Overload limit Notes Series DOMOTIC POWER DOMOTIC POWER Domotic Power 15W XCSD15C XCSD15B 120–230 V 120–230 V 24 V / 0.6 A 12 V / 1.2 A 1.05 A 2.1 A 30W XCSD30C XCSD30E XCSD30F 120–230 V 120–230 V 120–230 V 24 V / 1.2 A 5…15 V / 3…1.5 A ±12…±15 V / 2x0.6 A 2.2 A 7.0...5.0 A 2x0.9 A Adjustable output range Adjustable output range 50W 70W XCSD50B XCSD70C 120–230 V 120–230 V 12…15 V / 3.5…3 A 24 V / 3 A 7.0...6.0 A 4.0 A Adjustable...

Quality, reliability, high technology, know-how, efficient use are all aspects and features of a product of primary importance. For the safety and piece of mind of its Customers, Cabur designs and creates its Electronic Products with great care, using selected materials and components, in perfect harmony with the Quality choices made by the company in the last few decades. That’s why we can guarantee our electronic products for five years. Cabur’s electronic products warranty Cabur guarantees its electronic products against manufacturing defects and faults as well as defects due to their parts...
