The BVA Advantage BVA Hydraulics was launched in 2003 and is centrally located in the United States in Kansas City, Missouri. BVA is one of the Shinn Fu of America Companies including; Hein-Werner, Omega Lift, Pro-Lift, Blackhawk, Porto-Power, Bone Creeper, Omega Lighting and Save Phace. Shinn Fu was founded in Taiwan in 1971 and began doing business in the United States in 1978. Shinn Fu has over 2,000 Employees worldwide with its headquarters in Taipei, Taiwan. Confidence Built on Quality ISO 9001 BVA products are manufactured through an International Quality Assurance System, ISO 9001 which...

Hand Pumps H General Purpose Cylinder Combinations HF Flat Body Cylinder Combinations HC Hollow Hole Cylinder Combinations Flow Control ^ Valves 66 Shop Presses Maintenance Kits/Rail Cylinders 85 BVA Cross Reference Chart Hydraulic Formula Reference Safety Instructions Maintaining Your Equipment bVa ;Pages 90-94 © Copyright 2019 SFA Companies All rights reserved. Any copying or other use of the material in this catalog (text, illustrations, drawings, photos) without prior express written consent is prohibited. Information in this catalog is subject to change without prior notice.

Cylinder Matrix Chart H DC 30 06 T 12 3 Cylinder Cylinder Cylinder Type Options Capacity 1 - Cylinder Type H Hydraulic Cylinder 2 - Cylinder Options 3 - Cylinder Capacity 4 5 Cylinder Suffix Stroke Code 4 - Cylinder Stroke C S/A - Hollow Hole G S/A - Load Return High Tonnage PD Precision Double Acting UC S/A - Aluminum Hollow Hole UDC D/A - Aluminum Hollow Hole 16 Tons 20 Tons 25 Tons 30 Tons 50 Tons 55 Tons 60 Tons 75 Tons 75 Tons 100 Tons 150 Tons 160 Tons 200 Tons 250 Tons 300 Tons 400 Tons 500 Tons 600 Tons 700 Tons 800 Tons 1,000 Tons 1,500 Tons BVA Factory Designation US Made Cylinder No...

Cylinder Series Cylinder Type Max Capacity Range (tons) Page Number / Reference Image Single Acting Cylinders Aluminum Single Acting Cylinders Double Acting Cylinders HUD Aluminum Double Acting Cylinders High Tonnage Single Acting Cylinders Tonnage HDG High Double Acting Cylinders HL Flat Body Cylinders HULN Aluminum Lock Nut Cylinders Profile HLNF Low Lock Nut Cylinders Cylinder Accessories Hollow Hole Cylinders Acting HDC Double Hollow Hole Cylinders HUC Aluminum Hollow Hole Cylinders Double Acting HUDC Aluminum Hollow Hole Cylinders HP Pull Cylinders Threaded Cylinders Double Acting HPD Precision...

Single Acting Cylinders H Series - General Purpose, Spring Return Larger Tonnages For tonnages that exceed 100, please refer to our HG Section pg 18 H0509 Single Acting Cylinder H1506 in the collapsed position with CB15 cylinder base for safety. Single Acting Cylinder H5513 in the collapsed position ready to lift a load Safety Practices Good industry practice recommends not exceeding 80% of maximum rated capacities of all our products. • Collar threads and base mounting holes for fixturing • Hard chrome plated piston rod protects against corrosion and damage • Polyurethane U-Cup seals provide...

See pages 8-9 for detailed specifications. Cylinders * H0203 load return. ** H0500 comes with CRZ14F coupler. f Cylinder is equipped with carrying handle. Optional Tilt-Saddles Saddles tilt to a 5% maximum to adjust to the load. Match up these saddles with the following cylinders:

Single Acting Cylinders H Series - Spring Return ** H0203 comes with CRZ14F coupler. ‘ Cylinder is equipped with carrying handle.

"* H0500 comes with CRZ14F coupler. * Cylinder is equipped with carrying handle.

Aluminum Single Acting Cylinders HU Series - General Purpose, Spring Return, Lightweight Lightweight aluminum alloy construction Up to 60% lighter than comparable tonnage steel cylinders Convenient carry handle on 50, 75 and 100 ton models Hard anodized aluminum rod provides extra protection against corrosion and wear Integral steel protective plate Maximum working pressure: 10,000 psi / 700 bar C€ Aluminum vs. Steel Cylinders Aluminum cylinders provide a great alternative to the traditional steel cylinder in many applications. Being up to 60% lighter in weight, Aluminum cylinders are highly...

Cylinder Stroke CaPaci‘y (in)(tons) Cylinder Internal Oil Model Effective Pressure at C it Number Area Capacity capa3City (in2) (psi) ( ) Collapsed Extended Cylinder Outside Height Height Bore Dia. Dia. Base to Inlet Port G

Double Acting Cylinders HD Series - General Purpose • Rod wiper seals out dirt and contamination • High strength steel construction from gun drilled solid bar • High flow 3/8″ NPTF female couplers • One piece high grade alloy bearing for side load protection and long life • Ideal for pushing and pulling • Maximum working pressure: 10,000 psi / 700 bar • Threaded cylinders, removable saddle, thicker cylinder walls • Retract under hydraulic power for faster operation Safety Practices Good industry practice recommends not exceeding 80% of maximum rated capacities of all our products. Install a clevis...

With a variety of tonnage and sizes, you can apply our cylinders to a large variety of a pplica tions. Custom tonnages and stroke lengths are available upon request. Quick Selection Guide Cylinder See pages (pg.14-15) for detailed specifications. Visit our DO’S and DON’TS section to review the best methods of operation. Aluminum cylinders make a great lightweight alternative being up to 60% lighter than comparable steel models.

HYDRAU LICS' BUILT TO LAST Double Acting CylindersHD Series - General Purpose Cylinder AccessoriesRelated Product: Gauges and Safety Instructions Visit our DO’S and DON’TS section to review the best methods of operation. ^92 Stroke Model Maximum Cylinder Cylinder Capacity Effective Area (tons)(in) Number Push Pull Push Pull

Cylinders Model * 55-100 ton cylinders are equipped with carrying handles.

Aluminum Double Acting Cylinders HUD Series - General Purpose, Lightweight Aluminum vs. Steel Cylinders Aluminum cylinders provide a great alternative to the traditional steel cylinder in multiple applications. Being up to 60% lighter in weight, Aluminum cylinders are highly portable and reduce user fatigue and strain. However, due to the finite properties of Aluminum vs. Steel, these cylinders should NOT be used in high cycle applications. The BVA Aluminum cylinders are designed for a maximum safety rating of 5,000 cycles. Under normal lifting applications this should provide a long service...
