Shortform Catalogue
12Pages

A trading name of the Elektron Components Ltd

PX0990, PX0991, PX0992 Sealing caps to maintain IP68 rating of unmated connectors PX0990 Heavy duty sealing cap for use with PX0911 and PXA911 PX0991 Heavy duty sealing cap for use with PX0921 and PXA921 PX0992 Heavy duty sealing cap for use with PX0931and PX0941 BULGIN COMPONENTS • Email: sales@bulgin.co.uk • Fax: +44 (0)1708 376544 www.bulgin.co.uk PX0941 Flange Mount Connector 2, 3, 4, 5, 7 & 10 pole Mates with PX0911 & PXA911 Plug or Socket 32A, 600V (7 pole 430V) 6.2mm dia mounting holes PXA921 In-Line Flex Cable Connector Mates with PX0911 & PXA911 2, 3, 4, 5, 7 & 10 pole Plug or...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk Tel:+44 (0)1708 343800 SEALING CAPS Sealing caps to maintain IP68 rating of unmated connectors PX0811 fits Flex Mounting Connector, PX0810 fits all other body styles PX0803 - shown with insert Panel Mounting Connector Mates with PX0800 Right angle cable entry Suitable for Pin, Socket inserts SOLDER/CRIMP INSERTS For solder or crimp contacts 5A, 380V ac 3 or 8 pin Fits all body styles SCREW TERMINAL INSERTS 2, 3, 4 and 6 poles 3-10A, 250V ac Fits all body styles Leading earth pin on 3, 4 and 6 pole inserts PX0801 - shown with insert In-Line Flex...

PX0885 BULGIN COMPONENTS • Email: sales@bulgin.co.uk • Fax: +44 (0)1708 376544 www.bulgin.co.uk BUCCANEER SEALING CAPS Sealing caps to maintain IP68 rating when connectors are not in use PX0835 for cable connectors PX0840 and PX0841 PX0733 for front panel mount connectors PX0842 and PX0843 PX0711 for rear panel mount connectors PX0848, PX0849 and PX0845 PCB ADAPTOR LEADS Standard A and B type USB connectors to 5 way, 2.54mm, crimp adaptor leads 5 way headers, 2.54mm pitch, horizontal or vertical mounting For use with PX0842 & PX0848 types PX0841/AB Double ended sealed cable assembly IP68...

Panel Mount Touchproof Category PC2 Fuse Sizes 6.3 x 32mm (FX0415/S) and 6.3 x 25mm (FX0416/S) Screw Cap/Screwdriver Release 13A, 250V 16A, 250V UL FX0415/S, FX0416/S BULGIN COMPONENTS • Email: sales@bulgin.co.uk Tel:+44 (0)1708 343800 FX0415, FX0416 Bulgin’s extensive range of fuseholders are designed to give the degree of protection demanded in today’s sophisticated electronic equipment. Carrying world-wide safety approvals from UL, VDE, CSA, SEMKO and IMQ, all types are manufactured from high grade flame retardant nylon and polyester materials. Designed primarily for 5 x 20mm and 6.3 x...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk • Fax: +44 (0)1708 376544 www.bulgin.co.uk A full range of quality mains rated connectors conforming to IEC and EN 60320 specifications carrying UL, CSA, VDE and other approvals. With electrical ratings up to 20A, 250V (UL) these connectors offer solutions to most mains powered applications. The combinations of mounting styles and terminations include: flange fixing, snap to panel and PCB mounting together with 2.8/solder tabs, 4.8 and 6.3 faston tabs, screw terminal and PC spill versions. Completing the range are insulating boots, retaining...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk Tel:+44 (0)1708 343800 EMI FILTER OPTIONS BZV01/Z0000/10 BZV03/Z0000/02 BZV03/Z0000/07 BZV04/Z0000/04 BZV09/Z0000/04 BZH01/Z0000/01 BZH01/Z0000/10 BZH09/Z0000/01 BZH11/Z0000/10 BZH11/Z0000/00 BZM27/Z0000/57B BVB01/Z0000/01 BVB01/Z0000/11 With over 26,000 combinations Bulgin’s Polysnap mains power inlet modules offer a very adaptable and flexible solution to panel design. Polysnap allow combinations of mains inlets and outlets, filtered inlets, switches, fuseholders, voltage selectors, indicators and circuit breakers mounted in either horizontal...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk • Fax: +44 (0)1708 376544 www.bulgin.co.uk Housed in tough ABS boxes and panels these IEC EN60320 Distribution Units have combinations of four, five or six outlets together with neon indicator, fuse and switch options. The three sizes are available in various combinations and, other than the compact version, all have shuttered outlets. The larger enclosed versions are also available with EMI filtering. Designed to reduce conducted mains borne EMI, this extensive range provides many solutions to EMI problems. To meet individual design...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk Tel:+44 (0)1708 343800 SWITCHES MPI001 MPI002 Illuminated Versions Manufactured from Stainless Steel, Bulgin’s extensive range of vandal resistant security switches are designed with a high resistance to wear and tear, corrosion and harsh use in potentially hostile environments such as access control applications. The front and rear panel mounted versions have three profiles – prominent, domed and low profile – with a choice of switching and IP66 & 68 front panel sealing that, combined together, meet the ergonomic, electrical and environmental...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk • Fax: +44 (0)1708 376544 www.bulgin.co.uk This long established series of connectors still find many uses where small, but lower current connections are needed. The range consists of circular and rectangular styles with 3, 4, 6 and 8 poles, in a choice of configurations, with current ratings up to 6 Amps. The 8 pole round has become the standard connector for the disco and lighting industry and is available in cable and chassis mounting versions. PX0551 Flex Mount Male Circular Connector 8 Poles Mates with PX0552, PX0552/PC, PX0956/S and...

BULGIN COMPONENTS • Email: sales@bulgin.co.uk Tel:+44 (0)1708 343800 BX0035 BX0027 BX0034 BX0036 BX0037 BX0033 BX0001/1 BX0026 BX0011/1 BX0016 BX0023 Battery size AA (R6) 1, 2 or 3 Cells Panel Mount Bayonet/Screwdriver release Battery size AA (R6) 4 Cells Flanged Panel Mount Drawer function Battery size C (R14) 1, 2 or 3 Cells Panel Mount Screw Cap/Hand release Battery size D (R20) 1, 2 or 3 Cells Flanged Panel Mount Bayonet/Screwdriver release Battery size PP3 (6R61) 1 Cell Flanged Panel Mount Drawer function Battery size PP3 (6R61) 2 Cells Flanged Panel Mount Drawer function Battery size...
