microflex

microflex
6Pages

Catalog excerpts

Bruker Daltonics microflex Performance for Screening Applications on the Bench think forward MALDI-TOF MS

Entry-Level to HighPerformance Time-of-Flight Mass Spectrometry Whether it is biomarker discovery, oligonucleotide analysis or even the innovative fast and reliable identification of microorganisms: The microflexTM is the perfect instrument to answer questions in clinical proteomics, functional genomics and microbiology. The microflex is designed to be a compact and affordable benchtop MALDI-TOF system that is convenient for up-to-date life science laboratories. Performance Taking advantage from Bruker Daltonics‘ long expertise in the design of cuttingedge mass spectrometers, the unique...

Open the catalog to page 2

Oligonucleotide QC 6176.10 [M+H]+ 6173.1 6174.1 6175.0 6176.0 6177.0 Microorganism Identification Strain-specific IDs in minutes Disclose bacteria’s identity by its own unique protein composition with the MALDI Biotyper. During microflex MALDI-TOF analysis, proteins and peptides are arranged in a spectrum with increasing mass – revealing a characteristic peak pattern, even for reliable differentiation of strains: The individual fingerprint. Ease of operation Single bacterial colonies or other biological material can be applied to a MALDI sample target after a simple sample preparation...

Open the catalog to page 3

Biomarker Analysis Biomarker profiling Proteome profiling microflex supports the discovery of biomarker patterns and the identification of individual biomarkers in clinical proteomics applications. Superior system performance enables detection of biomarkers throughout the typical mass range for peptides and proteins. A complete solution for Clinical Proteomics microflex is integrated into the CLINPROT TM suite for peptide and protein biomarker discovery, providing automated magnetic bead based sample preparation and software tools for data analysis, visualization and statistical model...

Open the catalog to page 4

Enabling Design microScout MALDI targets in 1/4 microtiter plate size. Design Fast acquisition and superior sensitivity due to AnchorChip technology. AnchorChip technology The MALDI (matrix-assisited laser desorption/ionization) process is a vital step for reliable analysis. The patented AnchorChipTM technology accompanies the superior instrument design being the ideal sample carrier to provide homogeneous, exactly-positioned samples for robust and rapid automated data collection, as well as a sensitivity boost by up to two orders of magnitude. The modular design of the instrument offers...

Open the catalog to page 5

Technical Specifications MALDI source microScout Ion Source with state-of-the-art pulsed ion extraction Target area exactly ¹⁄4 of industry standard microtiter plates Various 96-spot target types available for specific applications Compatible with Bruker Daltonics‘ sample preparation robotics Nitrogen laser with variable repetition rate Patented AnchorChip MALDI target technology for fast automation, increased sequence coverage and 10–100 fold sensitivity increase over stainless steel target holder Compass software suite flexControlTM module for quick and easy instrument control Fuzzy-logic...

Open the catalog to page 6
