Conductivity Sensor LFS 806
Conductivity Sensor LFS 806
The document introduces two models of conductivity sensors, LFS 806 D0 and LFS 806 T0, which utilize a new inductive measurement principle. Both models offer customizable measuring ranges and accuracy to meet user requirements, with a rapid response time of less than one second.
- Range: 0 to 80 mS/cm
- Accuracy: 0.1 mS/cm
- Response Time: Less than 1 second
- Resolution: 0.01 mS/cm
- Ambient Temperature Limit: Storage: -10°C to +60°C, Operation: -4°C to +60°C
- Power Supply: 24 VDC, 2 W
- Dimensions: 200x127x80 mm
- Weight: Approximately 1500 g
- Type of Sensor/Measuring Principle: Inductive
- Protection Class: IP 65
- Interface: CAN-Bus
- Range: 0 to 80 mS/cm
- Accuracy: Less than 0.1 mS/cm
- Response Time: Less than 1 second
- Resolution: 0.01 mS/cm
- Ambient Temperature Limit: Storage: -10°C to +60°C, Operation: -4°C to +60°C
- Power Supply: 24 VDC, 2 W
- Dimensions: Submersible compound: 65x120x50 mm, DAM: 180x100x125 mm
- Weight: Approximately 1500 g
- Type of Sensor/Measuring Principle: Inductive
- Protection Class: IP 65
- Interface: CAN-Bus
The document notes that the specifications are subject to change without notice and provides contact information for Bran+Luebbe GmbH.
Catalog excerpts
1.0 E 0804 - 2.3.3.1 Printed in Germany Subject to change without notice Conductivity Sensor LFS 806 D0 The conductivity sensor uses a new inductive measurement principle which enables the sensor to measure to an accuracy of 5 ìS/cm totally independently of the structure and the material of the tubing system. The sensor can be modified to the user's wishes regarding measuring range and accuracy. The response time is less than one second. Conductivity Sensor LFS 806 T0 This conductivity sensor uses a new inductive measurement principle and can be modified to the customer requirements regarding...
