Strut profiles
9Pages

With more than 100 strut profiles for all types of loadings, Bosch Rexroth AG offers the widest product range for different requirements: ► Square and rectangular profiles ► Light profiles with optimized cross-sections ► Round profiles and profiles with smooth lateral surfaces Connectors with high load-bearing capacities combined with ultra robust slots and large central bores make profile connections possible which can handle high static and dynamic loads. Bosch Rexroth AG offers you 6 different profile ranges. All profiles within a profile range have the same slot dimensions and spacing so as to ensure that everything always fits together perfectly during construction. As they are very sturdy, the profiles with a 10 mm slot are suitable for building structures ranging from tables to heavy machine frames. They are available in four profile series with a slot spacing of 40 mm, 45 mm, 50 mm, or 60 mm. The profiles with 8 mm and 6 mm slots are used in the construction of lightweight equipment, partition walls, stands, or showcases. Profile length in profile packaging units (^p) The stated length of the profile packaging units relates to the guaranteed usable length. During anodizing as part of the manufacturing process bare areas which are approx. 30 mm long are left at each end of the profile (= contact areas), so the profiles are generally supplied incorporating an excess length of 100 mm. Note: The length dimension “L” in the table equals the usable length, whereas the actual length is approx. 100 mm longer. Strut profiles - slot sizes and modular dimensions

Strut profiles – slot sizes and modular dimensions 6 mm slot, 20 mm modular dimension 8 mm slot, 30 mm modular dimension 10 mm slot, 40 mm modular dimension 10 mm slot, 45 mm modular dimension 10 mm slot, 50 mm modular dimension 10 mm slot, 60 mm modular dimension

Profile finishing Profile finishing is required whenever interlocking connectors are used. For example, holes must be drilled for bolt connectors or threads must be cut in the central hole. This requires finishes with standard dimensions. However, individual customer requirements can only be fulfilled by providing customized profile finishing wherever desired. Rexroth enables even these complex requirements to be met as standard. This is because we offer three options for ordering the right profile finishing: Standard profile finishing with fixed material numbers For certain profiles, you...

eShop and MTpro – software tools for designers, planners, and purchasers Quick & Easy is supported by Rexroth’s eShop and the MTpro profile configurator. We offer: ff Customer-friendly configuration ff Generation of 3D CAD models for designers ff Drawings at the press of a button ff Integration of frames/profiles in layouts ff Easy ordering at the click of a mouse Quick & Easy – four steps for simple ordering The type of profile finishing is defined in an order key; all finishes for a profile can be summarized in one order key. 13 1. Select profile cross-section and length all profile slots...

Profile finishing Rexroth offers you numerous connection options for putting strut profiles together. The wide variety of connector types is due to the differing demands made of the applications: ► Right-angled ► Variable-angle ► Internal ► Torsion-resistant ► Vibration-resistant ► With or without profile finishing If you require a finished profile, it can be provided for you in an installation-ready form. When you select the corresponding material number the profile is provided in cut, burr-free form, or alternatively fully finished with drilled holes or threads. This eliminates risk for...
