Catalog excerpts
1) Safety and working condition3) Size, torque and power 7) Safety labels and operators manuals9) Yoke-shaft connections 29) Input connection shields CF - 30) Unit of measurements - 31) Branchesand agencies 2) Codes and dimension 28) Lubrication 17) SA, LN ratchet torque limiters18) LB shear bolt torque limiters19) LR automatic torque limiters16) GE shock absorbers14) Torque limiters and overrunning clutches10) Yokes for single cardan joints - 11) Yokes for 80Ұ CV joints12) Yokes for 50 CV joints - 13) Yokes for 70а CV joints type 652-662-6728) Safety shields6) Length5) Telescoping...
Open the catalog to page 24 BONDIOLI & PAVESI SpANo part of this manual may be reproducedwithout specific permission from Bondioli & Pavesi. All data and codes contained in this catalog replace and supersede any information given by previous publications. Consequently data provided in previous publications may no longer be valid. Bondioli & Pavesi reserves the right to change specifications without prior notice or obligation >
Open the catalog to page 3THE ABOVE INFORMATIONCONCERNS YOUR SAFETY. > All rotating parts must be guarded.The tractor master shield, the driveline guards, and the implementinput connection shields form an interactive guarding system.Proper use and maintenance of the drivelineand shielding is of primary importance foroperator safety.A high percentage of driveline accidents occur when safety shielding is missing or does not function properly. Bondioli & Pavesi recommends the use of proper shields and guards for the driveline, tractor, and implement. Damaged or missingcomponents must be replaced with original equipment...
Open the catalog to page 10Use the implement only with the original driveline,which is compatible in length, power capacity, torque limiters, overrunning clutches, and shielding. The driveline and safety devices are designed specifically for the implement, and should be used exclusively for this purpose. Do not exceed the speed and power limits given by the operators manual. Drivelines, torque limiters, and overrunning clutches in this catalog are designed to be used at speeds that do not exceed 1000 min > -1 .Do not overload the implement or suddenly engage the PTO clutch. Any torque limiter or clutch should be...
Open the catalog to page 11SINGLE CARDAN J0INTSWhen operating, ensure that angles α > 1 = α > 2 are smalland as equal as possible. The joint angles may vary widely during turns, but must never exceed 35 under power or 45а while rotating. Disengage the PTO when the joint angles become excessive or too unequal. See Driveline applicationsӔ for more information.CONSTANT VELOCITY JOINTSConstant velocity joint can allow large joint angles -up to 50 or 80а depending upon the type. These joint angles should only be allowed for brief periods, for example during turning. For drivelines with a constant velocity joint on...
Open the catalog to page 13The tractor printed on the shield indicates the tractorend of the driveline. Any torque limiter or overrunning clutch must be installed on the implement end of the driveline.Ensure that the driveline is securely attached to thetractor and the implement before operating. Check that all bolts or nuts are properly torqued.Friction clutches may become hot during use. Keep the area around the friction clutch clear of any material which could catch fire and avoid prolonged slipping.Never use the shield restraint chains to support thedriveline for storage. Always use the support on the...
Open the catalog to page 14Always wear adequate safety equipment whenperforming any maintenance or repair work.Replace worn or damaged components with the original Bondioli & Pavesi spare parts. Do not alter or tamper with any driveline component. Contact an authorized Bondioli & Pavesi dealer concerning any operations not described in the instruction manual. 1.6 >
Open the catalog to page 15A50 in positions13-14-15 of the shaft code. For primary shafts, any torque limiteror overrunning clutch must be fitted on the implement side. All rotating parts must be guarded.The three-digit codes for yokes and torquelimiters are shown in chapters 10-27 of this catalog. WR7 in positions 10-11-12 of the shaft code. If an RA2 (1 3/8" Z6) overrunning clutch is required on the implement end, enter code Safetyshields > ).Charts for the main types of drivelines and their codes are given on the following pages. Each end of the driveline is defined by three- digit codes that identify the yoke or...
Open the catalog to page 16standard cardan joint driveline. > 10 - Regular triangle profile tubes. 1R - Rilsan coated profile tubes(not available for size 1 and on request for size 43). 1C - Heat treated triangle profile tube (available on request for size 43). 40 - Splined telescoping members (exclusively for size 4 - 5 - 6 - 7 - 8).23 > 1 - 2 - 43* - 4 - 5 - 6 - 7 - 8. See chapter 3 Size, torque and powerӔ.* Use both positions 3 and 4 in the shaft code.4 > CE - CEE-EFTA countries bearing CE mark. US - USA and Canada without restraint chains. UC - USA and Canada with restraint chains. JP - Japan FX - Other countries...
Open the catalog to page 18standard cardan joint driveline > 1R - Rilsan coated triangle profile tubes23 > 4 - 6 - 8. See chapter 3 Size, torque and powerӔ.4 > CE - CEE-EFTA countries bearing CE mark. US - USA and Canada without restraint chains. UC - USA and Canada with restraint chains. JP - Japan FX - Other countries and CEE-EFTA countries not bearing CE mark.89 > Specify the three-digit code for the yoke, which will also denote the type of joint.101112 > Specify the three-digit code for the yoke, which will also denote the type of joint.Torque limiter or overrunning clutch.131415 16 > Use this position only if...
Open the catalog to page 20standard cardan joint driveline > 10 - Regular triangle profile tube. 1R - Rilsan coated triangle profile tube. 1C - Heat treated triangle profile tube.23 > 4 - 6 - 8. See chapter 3 Size, torque and powerӔ.4 > CE - CEE-EFTA countries bearing CE mark. US - USA and Canada without restraint chains. UC - USA and Canada with restraint chains. JP - Japan FX - Other countries and CEE-EFTA countries not bearing CE mark.89 > Specify the three-digit code for the yoke, which will also denote the type of joint.101112 > Specify the three-digit code for the yoke, which will also denote the type of...
