untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:11.00pt "Arial", sans-serif; } .font1 { font:26.00pt "Arial", sans-serif; } Products BOLL & KIRCH Filterbau GmbH

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:10.00pt "Arial", sans-serif; } .font2 { font:12.00pt "Arial", sans-serif; } .font3 { font:47.00pt "Arial", sans-serif; } Automatic filters Design and Opration In all BOLL automatic filters, wedge wire or wire mesh candies are cleaned automatically by backflushing with-out interrupting operation. This can be actuated either by differential pressure or is time controlled. Automatic filters are used for applications with continuous contamination and for which...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } Automatic filters Design and Opration 6.18 The main field of application for this BOLL automatic filter is water filtration. The internai components are therefore always made of stainless steel. The fully automatic back-flushing of the filter element is very efficient. Axial- and cross-flow backflushing is generated with filter candles open at...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } On the BOLL automatic filter TYPE 6.18.2, rotating flushing arms are located above and below the filter element. The re-designed filter candles are backflushed alternately from above and below within one cleaning cycle , without interrupting of filtration and by using the internal medium. The hydrodynamic element, positioned internal of the filter candle, increases the flow velocity in addition and thus optimises the effectiveness...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } .font4 { font:14.00pt "Arial", sans-serif; } .font5 { font:21.00pt "Arial", sans-serif; } The BOLL automatic filter TYPE 6.72 was specially devel-oped for smaller flow rates of fuels, lubricating oils and coolants. Its special design allows filtration grades up to 6 jm. A bypass filter with change-over valve can be inte-grated to use TYPE 6.72...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } Duplex filters Design and Opration Nominal diameters DN 25 - DN 80 DN 100 - DN 250 Switch-over change-over cock change-over cock Material variations Filter housing cast iron, nodular cast iron cast iron, nodular cast iron, cast iron rubber lined Pressure stages PN 16 / PN 25* PN 10 Grades of filtration 10 jim - 5 mm 10 jm - 5 mm * dpendent on...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:6.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:13.00pt "Arial", sans-serif; } .font5 { font:14.00pt "Arial", sans-serif; } .font6 { font:15.00pt "Arial", sans-serif; } .font7 { font:8.00pt "Arial Black", sans-serif; } Application Duplex filters comprise two filter hous-ings. One chamber of the filter is on duty whilst the other clean half is on stand-by. When the contamination...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } Simplex filters Design and Opration Filter types 1.12.2 Nominal diameters DN 25 - DN 80 DN 20 - DN 300 Inline connections yes yes Material variations Filter housing nodular cast iron, cast stainless steel (DN 25 und 50) cast iron, nodular cast iron, nodular cast iron rubber lined Pressure stages PN 32 / PN 40* PN 10 Grades of filtration 10 um...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } .font4 { font:14.00pt "Arial", sans-serif; } .font5 { font:15.00pt "Arial", sans-serif; } Application Simplex filters are the basic model of filter technology. They perform filtration tasks just as reliably as duplex filters or automatic filters. All filter elements with different filter materials can be installed. BOLL simplex filters are...

untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } .font3 { font:12.00pt "Arial", sans-serif; } Filter lments Design and Op驩ration The filter lment is the core item of every filter. It essen-tially consists of a supporting body and a filter media. Vari-ous designs provide differing sized filtration surfaces. The required degree of filtration and cleaning can be achieved for every medium with the ideal combination of core components. Type...
