New Hypoid Brushless DC Hollow-Shaft Gearmotors The new type 42B-25H2 and 42B-30H3 hypoid gearmotors combine our all new high-performance 42B brushless DC motor with our two hypoid gearheads. The gearmotors’ high torque and efficient design makes them an ideal drive solution for access gates, industrial conveyor systems, and packaging or food processing equipment. Type 25H2 and 30H3 Hypoid Gearheads • More energy-efficient than similar worm-gear models IP-66 protection against water ingress and dust ollow shaft eliminates expensive shaft H couplings, and mounting hardware Unvented gearhousing mounts in any orientation Permanently lubricated with high-performance lubricant Hardened steel gears for long life and maximum performance 4 2B4 brushless DC motor provides high starting torque, variable speed, and predictable performance. 8-pole design, 120 degree commutation Typical Applications Class “F” insulation; rated ambient temperature: +40°C Built-in, 256ppr magnetic encoder with commutation track otor terminated via two built-in watertight M connectors (power and signals) Ideal for applications that require higher torque and lower power consumption than gearheads utilizing worm gears can provide: conveyors, pumps, packaging and other industrial automation equipment. Gear Ratio Product Type Model Number www.bodine-electric.com | info@bodine-electric.com | 19225 Kapp Drive, Peosta, IA 52068-9547

Open the catalog to page 1

42B4-30H3 BLDC Hypoid Gearmotor Dimensions (inches) Hollow shaft bore diameter: 1.25” ref. Gearmotor weight: 32 lbs. 42B4-25H2 BLDC Hypoid Gearmotor 4.93 Max square 1.71 2.105±.015 45° 4xM8x1.25-6H .94 deep equally spaced on ø3.35 B.C. this side only Hollow shaft bore diameter: 1.00” ref. Gearmotor weight: 28 lbs. Hypoid Gearmotor Accessories Bodine’s optional hypoid gearmotor accessories include shaft kits for both the 25H2 and 30H3 gearheads, shaft cover kits (non-extension side), base/foot mount brackets for both gearheads. Shaft cover kits Model 0952 for type 25H2 gearhead Model 0953...

Open the catalog to page 2
