Product catalog summary

Overview: The document provides comprehensive specifications and descriptions of precision measuring and control instruments, focusing on digital and monoblock calipers, depth measuring calipers, and dial indicators. All instruments adhere to DIN standards, ensuring precision and reliability.

Digital Calipers: Made from hardened stainless steel, these calipers feature a liquid crystal display for easy reading, mm/inch conversion, zero setting, and RS232 output for PC connectivity. They are IP65 rated for water and oil resistance and include a locking screw and serial number. Various models offer different ranges and jaw sizes.

Monoblock Calipers: Constructed from hardened stainless steel with a satin-chromed precision scale, these calipers are durable and easy to use, featuring a slider locking button and suitability for depth measurements, compliant with DIN 862 standards.

Depth Measuring Calipers: Designed for precise depth measurements, these calipers have a satin-chromed readout scale and a slider locking screw with micrometric adjustment. Available in digital and monoblock versions, some models also measure internal grooves.

Dial Indicators: Shockproof and waterproof, these indicators prevent shock transmission to internal mechanisms, feature rotating bezels with tolerance markers, and comply with DIN 878 standards.

Test Indicators and Bore Gauges: Test indicators are shockproof with ruby-mounted gear movements for precision. Bore gauges measure ovality and taper of bores, with hardened steel contact points.

Key Specifications: The document lists specific code readings, measurement ranges, jaw sizes, and additional features like weight and rod size for depth calipers, summarized in tables for easy reference.

Measuring Instruments: Includes digital indicators with Sylvac electronics, test indicators, and micrometers, all manufactured to DIN standards, featuring IP65 protection and various functionalities.

Stands and Holders: Dial indicator stands with granite or stainless steel bases offer micrometric adjustments for stability and precision. Magnetic holders provide secure anchorage on rounded surfaces.

Surface Plates and Gauges: Granite surface plates offer high precision and corrosion resistance, manufactured to DIN 876 standards. Digital height gauges feature mm/inch conversion and micrometric adjustments.

Precision Tools: High precision squares and V-blocks, and cast iron spirit levels manufactured to DIN standards, ensure accuracy and durability.

Hardness Testers: Digital and bench hardness testers measure various scales, offering direct conversion and print capabilities.

Specifications: Maximum dimensions for controlled items are 135x170 H. Hardness measurements are specified in HRC, HRB, and HRA scales, with load capacities of 60 kg, 100 kg, and 150 kg.

Standard Accessories: Include diamond and ball penetrators, flat anvils, setting hardness specimens, and a protection cover.

Digital Roughness Tester: A portable tester for horizontal and vertical measurements, adhering to ISO standards, measuring various roughness parameters.

Digital Profiltester: Used for surface roughness and profile testing, conforming to ISO, DIN, and CNOMO standards, includes a display unit and calibration standard.

Calibration Laboratory and Service: The SIT calibration laboratory in Italy provides high-quality calibration services and certificates for mechanical and electronic instruments.

Company Specialization: The company produces fixed calipers, limit plug and ring gauges, precision measuring pins, and other precision tools, offering Go-No Go gauges and setting ring gauges.

Contact Information: Located at VIA PALAZZOLO, 41 - 25037 PONTOGLIO (BS) ITALY, with contact details for inquiries.

Catalog excerpts

B A ITEM. 91 CODE READING (mm) RANGE (mm) A (mm) B (mm) C (mm) D (mm) 01 0,01 150 (*) 5 50 23 02 0,01 200 (*) 5 50 23 CODE READING (mm) RANGE (mm) A (mm) B (mm) >

Open the catalog to page 4

Monoblock caliper in hardened stainless steel. Satin-chromed readout scale. Etched, precision graduation, easy to read and long-lasting. Raised slider for easy movement. Suitable for meauring internal grooves using internal points. Double scale: one for internal measurements and one for external measurements. Slider locking screw with lapped contact surfaces. Slide stop at beam end. Serial number. Manufactured as per DIN 862 . Supplied in case. Digital caliper in hardened stainless steel. 5 figure liquid crystal display and minus sign. State-of-the-art electronics. mm/inch conversion. Set to...
