Fortress Steel Hoarding
32Pages

STEEL HOARDING SYSTEMS BLOK MESH

2 Blok N Mesh Steel Hoarding Panels & Barriers www.bloknmesh.com Email:sales@bloknmesh.com SERVICE NETWORK FULL RANGE OF STEEL HOARDING AVAILABLE FROM OUR DEPOTS Depots Nationwide NATIONWIDE. Extensive Stocks Hire and Sale Hi-Ab Offload Tel: 0870 950 57 88 Blok N Mesh UK Ltd reserve the right to alter specifications without prior notice.

Fortress Steel Hoarding Blockade Gates & Accessories Blockade Support Systems Exclusive Products Advertising Hoardings Installation & Signage 3 Extensive Range of Hoarding Panels, Barriers & Accessories Blockade Steel Hoarding FOR MORE DETAILS OR TO ARRANGE A SITE VISIT CALL 0870 950 57 88 STEEL HOARDING SYSTEMS

4 Blok N Mesh Steel Hoarding Panels & Barriers

FULL RANGE OF STEEL HOARDING AVAILABLE FROM OUR DEPOTS NATIONWIDE. FORTRESSTM has been manufactured to be stronger, tougher and more costeffective than traditional methods of hoarding. FORTRESSTM steel hoarding has a simple design with only three basic components. The clever design means FORTRESSTM can be rapidly installed and moved from site to site, whilst minimising the need for replacement parts on each re-use. TM FORTRESS STEEL HOARDING 5 FORTRESSTM is our premier steel hoarding system designed to provide superb corporate image, high security and excellent value through multiple...

6 FORTRESSTM CLAMP FORTRESSTM clamp assemblies are made from 3mm steel plate and securely lock each panel and post together. Three clamps are required for each post. FORTRESSTM POST FORTRESSTM posts are 3m long and designed to be concreted into the ground, giving the system strength and rigidity. Specialised on-ground posts can be manufactured when ground conditions demand it. Blok N Mesh Steel Hoarding Panels & Barriers FOR MORE DETAILS CALL 0870 950 57 88 TM FORTRESS POST AND CLAMP

Panels are manufactured using specially formulated steel sheets. Each component is initially galvanised and then polyester powder-coated to prevent corrosion and ensure minimal maintenance over the product's lifespan. 7 PANEL OPTIONS Panel Panel Custom Galvanised Length Height Coloured Finish Finish 2.5m 2.44m FORTRESS PANEL TM Fortress Steel Hoarding Bespoke sizes can be manufactured to order.

006.psp tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:29.00pt "Arial", sans-serif; } 8-4 Blok N Mesh Steel Hoarding Panels & Barriers PEDESTRIADOORS FORTRESS pedestrian access door units ■ are 2.5m wide, with a 1.0m access door fixed centrally within the unit. Fortress door units come complete with sliding latch and protective padlock housing Specialised emergency exit doors are also available. Galvanised Finish Bespoke sizes can be...

006.psp tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:29.00pt "Arial", sans-serif; } ► Fortress Steel Hoarding VEHICLEGATES FORTRESS standard vehicle gates are 5.0m wide, and can be supplied in either half-mesh, full mesh or fully clad design. ^ GATE OPTIONS Gate Width Installed Gate Height Custom Coloured Finish Galvanised Finish 5.0m 2.44m A full bespoke service is available, with vehicle gates being manufactured up to 7.0m wide. ► 9

Blok N Mesh Steel Hoarding Panels & Barriers COST-EFFECTIVE BlockadeTM steel hoarding panels offer the flexibility of temporary fencing, with the security and improved image of hoarding. The robust sectional design enables quick installation, dismantling and relocation on site. These features ensure that BlockadeTM is a cost-effective alternative to timber hoarding. PRIVATE & SECURE BlockadeTM steel hoarding panels provide privacy and security on projects where a safe, discreet environment is required. CORPORATE IMAGE BlockadeTM steel hoarding panels can be supplied in your corporate...

FOR MORE DETAILS OR TO ARRANGE A SITE VISIT CALL 0870 950 57 88 Blok N Mesh UK Limited manufacture two grades of BlockadeTM Panels. Standard Panel For general purpose requirements. New Exclusive ANTI-DENTTM Panel ANTI-DENTTM panels are made using 0.9mm thick sheet, which is designed to withstand surface strikes and the most demanding site conditions. ANTI-DENTTM panels are hard wearing, maintenance-free and built for multiple re-use. Look for the ANTI-DENTTM logo, for your guarantee of quality. Blok N Mesh ANTI-DENTTM Hoarding Panels are undoubtedly the strongest available in the UK. TM...

12 Blok N Mesh Steel Hoarding Panels & Barriers TM BLOCKADE PANEL PANEL OPTIONS Panel Height Panel Standard Anti-DentTM Custom Galvanised Options Length Panel Panel Coloured Finish Finish 2.0m or 2.4m 2.1m BlockadeTM panels combine the ease of use of temporary fencing, with the robust site security of solid hoarding. Bespoke sizes can be manufactured to order. Available in both 2.0m and 2.4m high panel options. FULL RANGE OF STEEL HOARDING AVAILABLE FROM OUR DEPOTS NATIONWIDE.

PEDESTRIAN GATES 13 BlockadeTM pedestrian gates allow safe designated access points within the hoarding line. GATE OPTIONS Gate Height Gate Standard Anti-DentTM Custom Galvanised Options Width Panel Panel Coloured Finish Finish 2.0m or 2.4m 1.2m Blockade Gates & Accessories Bespoke sizes can be manufactured to order.

14 Blok N Mesh Steel Hoarding Panels & Barriers VEHICLE GATES FOR MORE DETAILS OR TO ARRANGE A SITE VISIT CALL 0870 950 57 88 Standard BlockadeTM vehicle gates are 4.5m wide and are available with full-clad or half-mesh gate leaves. Bespoke sizes can be manufactured to order. GATE OPTIONS Gate Height Gate Standard Anti-DentTM Custom Galvanised Options Width Panel Panel Coloured Finish Finish 2.0m or 2.4m 4.5m

15 Bespoke sizes can be manufactured to order. Coloured in-fills, ground skirts and cappings can be used to increase privacy and enhance corporate branding. Mesh extensions improve security by increasing the overall height of the hoarding. ACCESSORIES Blockade Gates & Accessories
