Overview: The document provides detailed technical specifications and product information for Bishop-Wisecarver's range of linear motion systems and components, including the DualVee® Guide Wheels, LoPro® Linear Motion System, MinVee® Linear Slide System, and others. It also includes information about HepcoMotion products distributed by Bishop-Wisecarver.

Specifications: The MinVee® Linear Slide System is highlighted with a wheel load capacity of up to 121 lbs and speeds up to 5 meters per second. The document specifies materials such as AISI 1045 carbon steel for tracks, with options for hardened and unhardened surfaces. Tolerances for track lengths, hole spacing, and mounting are provided, ensuring precision in installation.

Product Features: The MinVee® system includes features like a patented mounting shoulder for accurate positioning, double edge design for parallel Vee ways, and various coating options. The system supports a maximum speed of 5m/sec and acceleration of 49m/sec².

Technical Data: Detailed tables provide information on part numbers, number of holes, track lengths, surface conditions, hardness, and weight. Load capacities for different wheel carriage types are specified, including axial and radial working loads, and moments (pitch, yaw, roll).

Warranty and Support: Bishop-Wisecarver offers a one-year limited warranty ensuring products meet published specifications and are free from defects. Technical support is available for specific application requirements.

Ordering Information: Customers are advised to contact Bishop-Wisecarver for specific length requirements and additional ordering assistance. The document includes contact information for customer support.

Catalog excerpts

Built On ή Wheel Load Capacity up to 121 lbs.Speeds up to 5 Meters per Second

Open the catalog to page 1

PartNumberNumberof HolesLength* > 2 i ght(lbs/ft)Rockwell C > i t i onVee WaySurfaceHardnessWe > TD0-650-446 . 50Hardened,Dr . 50 TD0-1850-101018 . 50 TD0-2450-131324 . 50 TD0-3050-161630 i lledSteelRc 53 M . 171 TD0-1250-7712 . 50 TD0-3650-191936 i n i mum . 50TDO-ߔLength 8 N/ACustomer Spec i fiedHardened, Undr i lled TDS0-650-446 . 50Unhardened,Dr . 50 TDS0-1850-101018 . 50 TDS0-2450-131324 . 50 TDS0-3050-161630 i lledRc 22-25 . 171 TDS0-1250-7712 . 50 TDS0-3650-191936 . 50TDS0-ԔLength 8 N/ACustomer Spec i fiedUnhardened, Undr i lled Values are i n i nches *Notes 1 . For non-standard track...

Open the catalog to page 2

6061-T6 anod i zed alum i num carr i age w i th sta i nless steel lubr i cator hous i ng and felt lubr i cat i on padsTwo (2) concentr i c and two (2) eccentr i ngs, AISI 52100Integral stud shaft des i c DualVee i ntegral wheelsCarbon steel or polymer over-moulded wheels Double row angular contact bear i gnServ i ce i nterval = 100km (62 . 1 m i les at 23߰ C or 73 F) and 50% hum i d i ty at stated load capac i t i esTemperature range: -20а C to +120 C Load Capac i ty - Based on 100km Serv i ce L i fe > i al Work i al Work i ng LoadRad i ng LoadP i tch MomentYaw MomentRoll MomentWe Part #Wheel...

Open the catalog to page 3
