Control handle with integrated pneumatic 5/2 valve A control handle that, when integrated in Quick-Lift Systems™, meets the highest standards of ergonomics, working environment, safety and efficiency. Easy to use, thanks to outstanding reaction, regardless of load weight. Easy accessible buttons for operation of the various functions. Costs are effectively reduced through high reliability and durability. A strong and safe solution for quick and easy handling. With integrated pneumatic air valve, for pneumatic end effectors. Equipped with a unique patented swivel for integrated signal interface and which enables continuous rotation of the end effector.

TECHNICAL DATA CONTROL HANDLE WITH PNEUMATIC 5/2 VALVE Load capacity max. 300kg / 660 lbs Safety High degree of safety is achieved using our intelligent control Button functions - Emergency stop. - Upper left button for toggling between power save mode and operating mode. - Upper right button, for activating auto balance mode. - Lower buttons, grip and release functions. Swivel Unique integrated mechanical and electrical swivel enables continuous rotation of the Control handle. Main functions - Handle mode: A smooth lifting operation is performed when the manoeuvre handle is moved up or down....
