Your expert for IHR EXPERTEinsulation FÜR vibration and SCHWINGUNGSISOLIERUNG machine installation und Maschinenaufstelltechnik technology

GOOD VIBRATIONS AT BILZ VIBRATION TECHNOLOGY AG, WE ARE EXPERTS IN VIBRATION INSULATION FOR INDUSTRY AND RESEARCH. THERE IS BARELY ANY VIBRATION ENGINEERING PROBLEM THAT WE CANNOT SOLVE. Move to the current company headquarters at Boblinger StraBe 25 in Leonberg Change to public limited company Company Creation of a world- is established wide distribution network with its first branches in France, Austria, Switzerland, Taiwan, Korea and the USA ✓ Machinery / plant construction ✓ Industrial measuring technology ✓ Pharma / medical technology

OUR FAMILY BUSINESS WAS BUILT ON THESE THREE PILLARS UNRIVALLED PRODUCT RANGE Our product range covers nearly all applications in industry and research: from simple insulation pads for vibration insulation through levelling elements for vibration-insulated machine installation to vibration-insulated laboratory tables. No matter whether you need a forging hammer to be decoupled with insulation composite pads or you are in the semiconductor industry and want your highly sensitive machines to be air-mounted – there is barely any vibration problem that we cannot solve for you. WE'LL FIND THE SOLUTION...

FOCUSED ON PARTNERSHIP NO MATTER WHETHER YOU ARE A LARGE INTERNATIONAL CORPORATION OR A REGIONAL COMPANY: WE AT BILZ VIBRATION TECHNOLOGY AG ARE THE RIGHT PARTNER FOR YOU. PARTNERSHIP FORMS THE BASIS OF OUR CORPORATE CULTURE AND OUR VALUES. WHAT DO WE WANT? FOR YOU TO BE COMPLETELY SATISFIED. All our actions are driven by the need to see our customers satisfied. To achieve this, we treat our customers and business partners with respect and in a spirit of partnership. We understand their requirements, provide competent advice and work out the optimum solution together. Highest product quality,...

CONTENT About the company 2-5 Precision levelling wedges 22-33 Active vibration Company headquarters and sales partners 67

INSULATION PADSTHE PROVEN ECONOMIC SOLUTION FOR VIBRATION INSULATION IN MANY INDUSTRY SECTORS Manufactured from a precisely defined combination of nitrile rubber and cork particles, embedded in a composite of cotton fibres, the physical and mechanical properties of this high-quality composite material satisfy all of the current requirements for various industrial applications, depending on the type of pad. Very good insulation properties ensure optimum spring deflection and level consistency under both static and dynamic loads. • Effective structure-borne noise insulation • Ageing resistance:...

FOUR POSSIBLE OPTIONS FOR THE USE OF INSULATION PADS FOR MACHINE INSTALLATION Free-standing machine foundations using BiLz insulation pads with Low demands on alignment. The uneven floor is compensated for with pads, etc. The arrangement of the pads is usually a pattern of points, not over the full surface. Numerals and size of the required insulation pads is given by the weight of the machine and the existing support surface. Stable connection to the machine bed using bolt-on installation fittings that remain in place when the machine is Lifted. Specifically for machines with high dynamic forces...

InsuLation pads ARTICLE NUMBERS AND STANDARD SIZES 500 mm ■ ■■III ■ ■■III I Available square standard formats | Special and intermediate formats are manufactured individually on request

0 Available round standard formats Printing and paper industry Bookbinding/printing machine, folder # Scissors, packaging line Measuring machines, scales, microscopes #

Insulation pads DYNAMIC NATURAL FREQUENCY Type Loads Thickness FrictionN/cm2 mm coeff. B6 50-350 15 0,6 Extremely heavy-duty insulation pad with the highest level of constancy. For very heavy and longbed machines. DYNAMIC NATURAL FREQUENCY 120 Natural frequency [Hz] Insulation pad with high level consistency, specifically for machines with low intrinsic rigidity such as processing centres, lathes and grinding machines, etc. vertical horizontal Type Loads Thickness FrictionN/cm2 mm coeff. B0 50–200 15 0,6 DYNAMIC NATURAL FREQUENCY 100 Natural frequency [Hz] Universally applicable insulation pad...

DYNAMIC NATURAL FREQUENCY Type Loads Thickness FrictionN/cm2 mm coeff. B5 50-160 25 0,8 Profiled insulation pad to compensate for uneven floors. Designed specifically for machines with only a small contact surface and high dynamics, e.g. presses, punches, shears etc. vertical horizontal DYNAMIC NATURAL FREQUENCY Type Loads Thickness FrictionN/cm2 mm coeff. B32 20-80 25 0,8 Soft insulation pad without profile with excellent insulation effect, designed specifically for machines with low dynamics such as medium presses, punches etc. vertical horizontal DYNAMIC NATURAL FREQUENCY Type Loads Thickness...

InsuLation pads | Pad sets PAD TYPE B30W DYNAMIC NATURAL FREQUENCY Very soft, profiled insulation pad for static applications with optimum insulating effect due to low-frequency absorption, e.g. for measuring and testing machines, scales, microscopes. B30W also available profiled on one side: B30W-1 Type Loads Thickness Friction-N/cm2 mm coeff. DYNAMIC NATURAL FREQUENCY Profiled insulation pad for highest insulation values, can be layered up to 6 times, tuning up to approx. 25 Hz (up to approx. 8 Hz if insulation pad set), best as pad set for foundation insulation. ANTI-SLIP PADS Bilz anti-slip...

By multiple layering of 2-6 Bilz insulation pads to form pad sets, reduced natural frequencies can be achieved and thus the insulating effect can be significantly increased compared to single-layer insulation pads. These pad sets are ideal for large machines and swing foundations. Even after years of dynamic stress, the vibration-damping and insulation properties of the insulation pad sets remain unchanged. Special sizes Item no. 01-0475 Please specify the desired size when ordering. NATURAL FREQUENCY The permissible weight load of a pad set is between 5 and 40N/cm2 depending on the application....
