Industrial PC power suppT r \ BEP-510 120 Watt vJJ © Designed for fanless industrial computers © 100 Watt continuous fanless power! © Operating temperature up to +70 °C © Efficiency up to 84 % © Very robust design and construction © High reliability due to quality components © No minimum load required! © For applications with DC input is the related model BEP-510C available Technical data Input voltage Input frequency Input current Inrush current Efficiency Hold up time Power-Good-Signal Protection Earth leakage current Safety / EMC Temperature Derating MTBF Max. operating altitude Humidity Dimensions (W x D x H) Weight (net) 90...264 VAC, active PFC 47...63 Hz 2 A (115 VAC) / 1 A (230 VAC) 30 A (115 VAC) / 70 A (230 VAC) >80 % (at max load and 115 VAC) >41 ms at 115 VAC and max load Switch on delay 100.550 ms, Switch off delay 1 ms Short circuit protection: at each output, switch off Overload protection: 110.160 %, switch off Overvoltage protection: switch off, +3.3 V (3.6.. .4.3 V), +5 V (5.6.. .6.5 V), +12 V (13.2.15 V) Overtemperature protection: switch off <3.5 mA CE, UL 60950-1, TOV: EN 60950-1 Operating: -10.+70 °C / Storage -20.+80 °C See diagram 202 000 h at +50 °C without fan according to MIL-HDBK-217F 2000 m Operating: 10.85 % RH, non-condensing / Storage: 10.90 % RH, non-condensing 83.8 x 165 x 40 mm ±0.4 mm 0.6 kg Output power at +3.3 V, +5 V, +12 V and -12 V is 93 W (without fan). 100 Wpower can be supplied without fan, and 120 W full power using a 20 CFM fan. As a power component this PSU is for assembly purposes only and must not be operated in unassembled condition. The final assembly has to comply with the valid EMC and safety standards. BICKER.de elektronik Bicker Elektronik GmbH | 86609 Donauworth | Germany Tel. +49 906 70595-0 | [email protected] | www.bicker.de

Industrial PC power supplies Optional Accessories   detailed information please visit our website www.bicker.de and refer to the article number. For PSZ-1019 | EMC-Filter For BEP-510, incl. mounting screws IEC connector filter incl. cable and ferrite 2-pole, length 620 mm, AWG18, ends open X1-061 | AC input cable 3-pole, length 600 mm, AWG18, ends open, M3 ring terminal Rated load (Watt) Operating temperature (°C) Supplementary data for derating from +50…+70 °C Load at +3.3 V / +5 V fanless (50 W) Load at +3.3 V / +5 V with 20 CFM fan (70 W) Output current per channel Bicker Elektronik GmbH...

Industrial PC power supplies Drawing BEP-510 AC input #6-32 screw with max. 2.5 mm thread length Specification is subject to change without notice. Errors excepted. Status as at: 21.02.2017 BLACK RED RED RED NC BLACK BLACK BLACK GREEN BLACK BLUE ORANGE RED BLACK BLACK YELLOW RED BLACK BLACK YELLOW ORANGE YELLOW YELLOW PURPLE GREY BLACK RED BLACK RED BLACK ORANGE ORANGE YELLOW BLACK BLACK RED ORANGE BLACK RED BLACK A1 YELLOW ORANGE BLACK RED BLACK A1 YELLOW Bicker Elektronik GmbH | 86609 Donauwörth | Germany Tel.   +49 906 70595-0 | [email protected] |  w
