Catalog
Catalog
The catalog introduces new features for selecting spray nozzles, leveraging BEX's 40 years of experience in design and development, with a focus on fast delivery and competitive pricing.
Includes enhanced engineering data for nozzle selection, featuring color-coded K-Ball Flat-V Spray Balls and Plastic Zip-Tips for easy identification.
Highlights include the All Teflon TWK Rotating Nozzle, 150 & 300 Full Cone Spray Nozzle, Mini Eductors, and Split Eyelets.
Key elements include assembly configuration, spray pattern, flow rate, connection size, physical dimensions, and material options like Brass, Stainless Steel, Hastelloy, and Titanium.
Defined by spray pattern, flow rate, atomization, and spray angle, with detailed descriptions and theoretical coverage for different angles.
Offers various connection styles, including NPT and BSPT threads, quick disconnect styles like BEX Zip-Tip, and clip-on K-Ball series.
Spray impact is calculated using specific formulas, with tables for theoretical coverage at various distances.
Regular monitoring and maintenance are recommended to prevent issues like corrosion, erosion, clogging, and mechanical damage.
Issues can arise from incorrect selection, corrosion, temperature, erosion, clogging, caking, mechanical damage, incorrect assembly, and low flow rates.
Provides conversion factors for volume and pressure, including key conversions like 1 N/m2 = 1.02 Kg/cm2 and 1 foot head (water) = 0.433 psi.
Details specifications for F-Series flat "V" spray nozzles, including capacity at various pressures, spray angles, and construction materials.
Nozzles are suitable for applications such as parts cleaning, metal washing, foam control, and vehicle washing.
Provides detailed specifications and performance data for various spray nozzles, including solid stream and flat spray nozzles, as well as air blow-off nozzles.
Lists multiple models with respective pipe sizes, orifice diameters, and dimensions, providing capacity data in GPM at various pressures and spray angles.
Nozzles produce different spray patterns, such as solid stream and flat fan-shaped sprays, with angles ranging from 0° to 110° at 40 psi.
Nozzles are machined from bar stock and available in materials like brass, steel, 303 stainless steel, and 316 stainless steel.
Typical applications include metal washing, agitation, mixing, PCB washing, semiconductor manufacturing, pressure washing, and more.
Adjustable joints for accurate spray pattern orientation, with references to additional accessories.
Tables provide detailed GPM capacities at various psi levels for each nozzle model, along with spray angles.
Provides detailed specifications and characteristics of various spray nozzles, focusing on the DF and FL series.
- Spray Angles: Ranges from 15° to 140°.
- Orifice Diameters: Specified in inches.
- Pressure Capacities: Provided in GPM at various pressures.
- Constructed from materials like 316 stainless steel, 303 stainless steel, brass, PVC, CPVC, Teflon®, and polypropylene.
- DF series features thin-disc flat spray nozzles for low-profile applications.
- FL series offers a wide, flat fan-shaped spray with low impact.
- Includes rinsing, cooling, dishwashing, fertilizer spraying, metal wash, gravel washing, and vehicle washing.
- For complete coverage, a 10-15% overlap is recommended.
Provides detailed specifications and applications for various types of spray nozzles, including full cone, hollow cone, and plastic nozzles.
Lists multiple models categorized by spray angle, pipe size, and maximum free passage.
Designed to produce full cone or hollow cone spray patterns.
Constructed from materials like brass, 303 stainless steel, 316 stainless steel, PVC, CPVC, and polypropylene.
Suitable for industrial applications like chemical processing, cooling sprays, heat exchanger cooling, coke quenching, and dust suppression.
Tables provide detailed flow capacities (GPM) at different pressures for each nozzle model.
Provides detailed specifications and characteristics of various spray nozzles used in metal treatment and other applications.
- Specifications: Available in various pipe sizes with capacities measured in GPM at different pressures.
- Applications: Suitable for water cooling, roof cooling, air cooling, and air washing.
- Spray Characteristics: Designed for phosphating applications.
- Spray Characteristics: Anti-clog design with large flow rates and small droplet sizes.
- Spray Characteristics: Produce evenly distributed hollow-cone sprays.
- Spray Characteristics: Provide a fine hollow-cone spray using liquid pressure for atomizing.
- Various nozzle models available with different capacities and spray angles.
Provides detailed specifications and characteristics of various spray nozzles, including their construction, applications, and performance metrics at different pressures.
- Orifice Diameter: Lists various models with specific orifice diameters.
- Wide, Flat Fan-Shaped Spray: The ZFL series offers a wide, flat fan-shaped spray with low impact.
- Rinsing and Cooling: Suitable for applications requiring low impact and wide angle sprays.
- Capacity at Various Pressures: Provides detailed tables showing the capacity (GPM) of each nozzle model at different pressures.
Nozzles are machined from bar stock and are of one-piece or two-piece construction.
Provides detailed specifications and applications for various types of spray nozzles, including hollow cone, phosphating, and flat "V" spray nozzles.
- The standard included angle of the spray cone is 70° at 10 psi for hollow cone nozzles.
- Hollow cone nozzles are used for air and gas washing, aerating, rinsing, humidifying, industrial washers, cooling tunnels, roof cooling, degreasing, dust suppression, and metal treatment.
- Capacity tables are provided for various models, showing GPM at different pressures and corresponding spray angles.
- Molded plastic spray nozzles are available in glass-reinforced polypropylene or PVDF.
Provides detailed specifications and performance data for various nozzle models used in industrial applications.
Lists multiple nozzle models with their respective flow rates at different pressures and steam capacities.
Instructions for selecting the right eductor for steam sparging are provided.
Nozzles are available in materials such as 316 stainless steel, alloy 20, brass, and Teflon®.
Suitable for various applications, including chemical processing, cooling sprays, tank washing, and machine clean-in-place (C.I.P.).
Tables provide detailed flow rates for different nozzle models at various pressures.
Some nozzles offer true 360° spray coverage, self-lubricating and self-cleaning mechanisms.
Suggests using BEX Twisters® for enhanced performance.
Provides detailed technical specifications and performance data for various spray set-ups used in applications such as dust control, pesticide application, humidification, cooling, coating, and handling low viscosity fluids.
Each spray set-up consists of an air cap and a liquid cap that determine the spray pattern, capacity, and coverage performance.
Explains how liquid atomization is controlled by varying air pressure without changing liquid pressure.
Includes performance charts for different spray set-ups, detailing liquid capacity in GPH and air capacity in SCFM at various air pressures.
Users are advised to select the appropriate spray set-up based on the application requirements.
This document is a catalog for BEX spray nozzles, detailing various types of nozzles and related products.
- Nozzle Types: Lists different types of nozzles such as threaded nozzles, flat spray, full cone spray, quick-disconnect nozzles, and more.
- BEX offers a wide range of spray nozzles with thousands of models available from stock.
Catalog excerpts
SPRAY NOZZLES In this new catalog, you’ll find many new features that have been added to assist you in selecting the proper nozzle for your application. For over 40 years we have designed and developed spray nozzles in response to user’s concerns, with the understanding and willingness to provide answers to their needs. From BEX you will get the industry’s fastest delivery. MORE CONTENT: EXPANDED ENGINEERING SECTION: More engineering data to help you select the right nozzle for your specific application. COLOR-CODED K-BALL FLAT-V SPRAY BALLS AND PLASTIC ZIP-TIPS®: Now color-coded for easier product...
Open the catalog to page 2
Table of Contents This catalog lists the most popular models of BEX spray nozzles and accessories. Many others are available, often in special materials. PLEASE NOTE THAT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. DESIGN AND ENGINEERING INFORMATION Nozzle selection Technical information Conversion factors Preventing Nozzle Problems Common Causes of Nozzle Problems THREADED NOZZLES Includes: Flat Spray Hollow Cone Full Cone OTHER TYPES OF NOZZLES Includes: Industry specific nozzles Rotating nozzles Accessories Much more AIR ATOMIZING Includes: Various spray set-ups Connection types Extensions...
Open the catalog to page 3
S elec tion Guide This section describes some of the questions to be considered when selecting spray nozzles. In addition, answers for uncomplicated situations are provided where possible. In some applications, because of the large number of variables involved, accurate answers are not always possible except through actual testing or simulation. Our technical staff, however, may be able to lend assistance in their areas of expertise. Please feel free to give us a call. WHAT S P RAY NOZZLE CONS TRUCTION D O I REQUIRE? The basic elements of spray nozzle construction are assembly configuration,...
Open the catalog to page 4
WHAT TYP E OF CONNECTION D O I REQUIRE? BEX spray nozzles are available in many different connection styles. The most common connection types depend on the industry where the nozzles are being used. Generally, however, the most common connection is the standard tapered, or NPT, pipe thread. The outside diameters of NPT threads are Other common connections include the quick disconnect style, or BEX Zip-Tip®, which is a bayonette style of connection whereby a tip is inserted into a threaded body, and the BEX clip-on K-Ball® series, which is a style of nozzle which connects to a pipe by means of...
Open the catalog to page 5
WHAT FACTORS WILL AFFECT MY SPRAY CHARACTERISTICS? When the conditions controlling spray nozzle performance change, the spray characteristics may change. This section lists conditions which may vary, and how those conditions may affect the spray characteristics. PRESSURE: The flow rate of a liquid is proportional to the square root of the pressure difference between the pressure liquid and external (usually atmospheric) conditions, thus higher pressure generally results in finer spray atomization, greater spray impact, and greater spraying distance. VISCOSITY: Spraying liquids with higher viscosity...
Open the catalog to page 6
Theoretical coverage (W) at various distances (D) from the nozzle INCLUDED SPRAY ANGLE Spray coverages shown in Table 1 are based on straight sided spray patterns. At low pressures the sides may curve in, as shown at the right, because of the acceleration due to gravity. To find the width of a spray (W) at any distance (D), multiply the W/D ratio by the distance. OTHER TRADEMARKS FOUND IN THIS CATALOGUE: BEX® is a registered trademark of BEX K-Ball® is a registered trademark of BEX Twister® is a registered trademark of BEX ZIP-TIP® is a registered trademark of BEX Hastelloy® is a registered trademark...
Open the catalog to page 7
P r eventing Nozzle P r oblem s Monitor Nozzle Performance Flow rate Flow rate can be measured by connecting a flowmeter in series with the nozzle, or collecting the output from the nozzle in a container of known volume over a measured period of time. If the flow rate is higher than the nozzle specifications then it is possible that the orifice has partially corroded or eroded away. If the flow rate is lower than specified then the nozzle could be clogged or caked. Such problems are often accompanied by a change in spray pattern or distribution. Pressure A decrease in your system pressure could...
Open the catalog to page 8
Com m on Caus es of Nozzle P r oblem s Corrosion The nozzle degrades due to chemical reactions between the nozzle material and the chemicals in the process. Temperature If nozzles are subjected to temperatures greater than recommended then physical damage can occur. Erosion/Wear As fluid passes through the orifice and internal passages of the nozzle the critical surfaces can become worn, thereby creating a poor spray. Clogging Many chemical compounds and particles larger than the maximum free passage of the nozzle will clog the nozzle. Caking Many chemicals will slowly build up on the nozzle...
Open the catalog to page 9
US EFUL CONVERS ION FACTORS : Volume Feet Head (Water) 1 foot head (water) = .433 psi Flow rate 1 U.S. gallon per minute = 0.1337 ft3/min = 3.785 l/min 1 ft3/sec = .02832 m3/sec = 28.32 l/sec VOLUMETRIC UNITS – EQUIVALENTS Cubic Centimeter Fluid Ounce Fluid Ounce Cubic Foot Cubic Meter Volumetric Unit Cubic Centimeter Cubic Foot Cubic Meter LINEAR UNITS – EQUIVALENTS Linear Unit Millimeter Centimeter LIQUID PRESSURE – EQUIVALENTS Lb/In2 (psi) Liquid Pressure Inch kPa Mercury (kilopascal) Inch Mercury
Open the catalog to page 10
Flat “V” spray nozzles F-Series spray nozzles produce a flat, Suitable for a variety of washing and spraying fan-shaped spray pattern, with spray angles DIMENSIONS PIPE SIZE (NPT) • Parts Cleaning Spray angles generally increase with pressure, as • Metal Washing shown in the capacity table. • Foam Control • Gravel Washing FLAT SPRAY available from 5° to 110° measured at 40 psi. Spray density tapers off toward the outside of • Vehicle Washing these sprays, to permit overlapping of spray • Fertilizer Spraying patterns while maintaining uniform spray density. See page 17 for 0° solid stream spray...
