BSDF 110

Product catalog summary

Technical Specifications
The document provides technical specifications for the BERG Screw Compressor with inverter and direct drive, model KOMPBERG® BSDF 110. Key specifications include:

Nominal Power: 110 kW
Speed: 2980 min^-1
Voltage: 400/480 V (upon request)
Frequency: 50/60 Hz (upon request)
Protection: IP55
Isolation Class: F
Oil Capacity: 60 liters
Cooling Air Required: 17500 m³/h
Ambient Temperature: Min. +5°C / Max. +40°C
Sound Level: 83 dB(A)
Dimensions: 2670 x 1330 x 1980 mm
Weight: 2500 kg

Construction and Design
The compressor features a direct drive without a gearbox, a carbon steel base frame, and a sound enclosure made of sheet metal profiles with removable doors. It is powder-coated in RAL 5002 for the doors.

Performance
The compressor's capacity (FAD) at gauged pressure according to ISO 1217 Annex C is:

9.6 - 19.2 m³/min (339 - 678 cfm) at 7.5 bar
8.4 - 16.9 m³/min (296.6 - 596.8 cfm) at 10 bar
7 - 14.1 m³/min (247.2 - 497.9 cfm) at 13 bar

Additional Features
The compressor includes a variable speed drive (VSD) from YASKAWA/Danfoss and PLC and HMI controllers from SIEMENS. It also has a cooling air outlet and inlet, and a compressed air outlet connection of G2.

Manufacturer Information
BERG Kompressoren GmbH, Medienstraße 35, 47807 Krefeld, Germany. For more information, visit www.berg-kompressoren.de.

Catalog excerpts

Technische Daten / technical data sheetBERG Kompressor Schraubenkompressor mit Inverter, Direktantrieb BERG Screw Compresor with inverter, direct drive, 1:1 Typ / type KOMPBERG® BSDF 110 Pulverbeschichtungsfarbe: RAL 7047 (Rahmen), RAL 5002 (Turen) MedienstraGe 35 47807 Krefeld, Germany

Open the catalog to page 1

THIS DOCUMENTS PROPRIETARY INFORMATION WITH ALL RIGHTS AND TITLES RESERVED AND MAY NOT BE REPRODUCED IN WHOLE OR IN PART WITHOUT WRITTEN CONSENT OF BERG Kompressoren GmbH. 5 Druckluftausehluss G2 Compressed air outlet G2 Elektroschrauk, Microprozessorsteuerung Electronic box , controller Kühllufteinlass Cooling air inlet Masse Earthing Stromversorgung Power feed Kühlluftaustritt Cooling air outlet Schraubenkompressor / oil lubricated screw compressor • 1:1 Direktantrieb ohne Getriebe / direct driven without gearbox • Motorleistung / main motor power: 110 kW • mit Grundrahmen aus Stahlträgern,...

Open the catalog to page 2

BSDF 110

BSDF 110
