Product Summary 2006

Product catalog summary

Product Overview: The document provides a comprehensive summary of BEKA's instrumentation products designed for safe and hazardous process areas. It includes intrinsically safe, Type nL, and general-purpose models certified by ATEX, FM, and IECEx.

Key Features:

Intrinsically safe models for gas and dust hazardous areas with certifications like ATEX, FM, and IECEx.
Loop powered instruments with minimal voltage drop and optional backlighting, alarms, and calibration features.
Field and panel mounting options with IP66 and IP65 protection ratings.
High contrast displays with options for analogue and digital readouts.

Product Categories:

Loop Powered Digital Indicators: Available in field and panel mounting models with various display sizes and certifications for hazardous areas.
Serial Text and Fieldbus Displays: Support for Modbus protocol, high contrast graphic displays, and multiple variable displays.
Flow Batch Controllers and Rate Totalisers: Designed for dispensing and flow measurement with pulse and 4/20mA inputs, offering optional alarms and backlighting.
Battery Powered Clocks: Intrinsically safe with long battery life, accurate timekeeping, and daylight saving adjustments.
Set Point Stations and Temperature Transmitters: Loop powered with large digital displays for temperature measurement.
Counters, Timers, Tachometers, and Clocks: Dual input models for speed and position display, with optional outputs.
LED Cluster Lamps, Sounders, and Beacons: Intrinsically safe and general-purpose models with various color options and sound outputs.

Certifications and Compliance: Products are compliant with international safety standards, including ATEX, FM, and IECEx, ensuring suitability for use in hazardous environments.

Applications: The instruments are suitable for machine and process control applications in both safe and hazardous areas, offering reliable performance and safety compliance.

Catalog excerpts

visit our website www.beka.co.uk >

Open the catalog to page 1

FIELD MOUNTING INSTRUMENTSNOW HAVE OPTIONAL ATEX & IECExDUST CERTIFICATION MountingDisplay DisplayCertificationheightEurope ATEXUSA FMInternational IECEx Intrinsically safe Ɩ for use in gas and dust hazardous areas BA304D Field3 > 1/2 digits25mm Group II IS/I,II,III/ 1 /ABCDEFGEx ia IIC T5 BA324D Field4 > 1/2 digits20mmCategory 1 GD*NI/I,II,III/2/ABCDEFGDIP A21 TA 80˚C IP66*EEx ia IIC T5 BA307C Panel3 > 1/2 digit13mmGroup IIIS/I/ 1 /ABCDEx ia IIC T5 BA308C Panel3 > 1/2 digit25mmCategory 1 G NI/I/2/ABCD BA327C Panel4 > 1/2 digit10mmEEx ia IIC T5 BA328C Panel4 > 1/2 digit20mm BA326C Panel4 > 1/2...

Open the catalog to page 2

BA484D Field mounting,IP66 enclosure,ATEX Group II Category 1 GD* EEx ia IIC T5 BA488C Panel mounting,IP66 front,ATEX Group II Category 1 G EEx ia IIC T5 General purpose BA684D Field mounting,IP66 enclosure,RS485 or RS232 interface BA688C Panel mounting,IP66 front,RS485 or RS232 interface > *ATEX dust certification is an option Intrinsically safe models - for use in all gas and dust hazardous areas BA484DF Field mounting IP66 ATEX Group II Category 1 GD* EEx ia IIC T4enclosure FM IS/I,II,III/ 1 /ABCDEFG & NI/I,II,III/2/ABCDEFG IECEx Ex ia IIC T4 DIP A21 TA 125˚C IP66* BA488CF Panel mounting IP66...

Open the catalog to page 3

Sounder Beacon ◆ 32 different sounds ◆ Red,amber,green,blue &white models ◆ 3 stage alarm ◆ Two double flashes per second ◆ Up to 105dB(A) output ◆ Operates alone or withsounder Sounder Beacon ◆ PFEER compliant ◆ 32 different sounds ◆ 5 joule output ◆ IP65 enclosure ◆ Alarm accept functionsilences sounder for pre-set time. ◆ Up to113dB(A) output ◆ Red,amber,yellow,green,blue or clear lens ◆ IP56 enclosure ◆ Will operate alone or withBA386 beacon ◆ PFEER compliant ◆ IP67 enclosure ◆ IP67 enclosure Intrinsically safe sounders for use in all gas hazardous areas Flameproof - ATEX Group II Category...

Open the catalog to page 6
