Overview: The STAR series exhausters/compressors are engineered for cesspool emptying and sewage transport, with additional applications in fertilizing irrigation. They are recognized for their reliability, attributed to precise design and manufacturing.

Specifications: The series includes models such as MV-MF, MAV-MAF, HV-HF, PV-PF, KV-KF, KAV-KAF, and DV-DF, each with distinct technical specifications like geometrical capacity, maximum working speed, pressure limits, and power absorption at various RPMs.

Key Features: Notable features include an overpressure valve predisposition, vacuum-pressure selector, blades inspection hole, optional heat-resistant blades, high wear resistance due to cast-iron construction, standard forced lubrication pump with optional automatic lubrication, and a rotor with steel pins for maintenance ease.

Technical Data: Models STAR 60, 72, and 84 have geometrical capacities of 10,680, 11,870, and 14,420 l/min, respectively, with operational speeds up to 600 or 1,200 RPM. They support a maximum absolute pressure of 2.5 bar and a relative pressure of 1.5 bar. Vacuum levels reach -0.95 bar without a depression valve and -0.80 bar with it.

Power and Weight: Power absorption ranges from 10 to 36 kW, depending on the model and RPM. Model weights vary from 198 to 250 kg.

Operational Details: The /M version is designed for cardan shaft operation at 540 or 1000 RPM, the /P version uses pulleys and belts for truck applications, and the /D version is also cardan shaft driven at 1000 RPM.

Continuous Operation: Standard blades allow for 8 minutes of continuous operation, while long-life blades extend this to 15 minutes.

Procedures: The hydraulic motor version (H) operates via a hydraulic motor, while the cardan shaft version (K-KA) functions at 540-1000 RPM and can drive a hydraulic pump.

Standards and Recommendations: The hydraulic pump must rotate to the left. Accessories and fittings available include hydraulic engines, swivel joints, and overpressure valves.

Technical Data Summary: STAR models have specific dimensions and weights, with detailed measurements available. Lubrication systems and manifold options are customizable upon request. Accessories include hydraulic engines, swivel joints, and various valves for system customization.
