E-catalogue power source

Product catalog summary

Overview: The document provides technical specifications and features of AXXAIR's innovative orbital welding power sources, specifically models SASL-161, SASL-160, SASL-200, and SASL-300. These models are designed for various voltage requirements and include integrated cooling systems, memory card support, and touch screen controls.

Specifications:

SASL-161: Operates on 115V AC single-phase, with a maximum current of 120A and a power factor of 60% at 120A. It is lightweight, ideal for on-site work, and includes a welding data acquisition system.
SASL-160: Operates on 230V AC single-phase, with a maximum current of 165A and a power factor of 100% at 100A. It is also designed for on-site work and includes similar features as the SASL-161.
SASL-200: Supports 110V-230V, with a maximum current of 210A and a power factor of 100% at 160A. It includes an integrated cooler with a 1400W cooling capacity and a safety system for flow rate and pressure.
SASL-300: Operates on 400V three-phase, with a maximum current of 300A and a power factor of 100% at 210A. It features an integrated cooler and supports up to four shafts for various functions.

Features:

All models come with a 5.7" multi-language color touch screen for easy control and parameter calculation.
Each power source is supplied with a memory card capable of storing 200 programs with 20 levels each.
Integrated printers are included for documentation purposes.

Accessories and Consumables: The document lists various accessories and consumables compatible with the power sources, including memory cards, card readers, coolant, printer spools, and trolleys for mobility.

Compatibility: A compatibility table is provided to match power sources with heads and accessories, ensuring optimal performance and integration.

Catalog excerpts

INNOVATIVE ORBITAL SOLUTIONS POWER SOURCES Join experience

Open the catalog to page 1

POWER SOURCES INNOVATIVE ORBITAL SOLUTIONS 220V - 115V SASL161 : 115V AC single-phase + earth, 50/60Hz , Imax=20A, Max. current 120 A, Power factor: 120A-60%,100A -100% SASL 160 : 230V AC single-phase + earth, 50/60Hz , Imax=26A, Max. current 165 A, Power factor: 100 A, 100% - Ideal for on-site work - welding data acquisition system •Supplied with a memory card with 200 programs, 20 levels each Weight: - SASL-16xTRA: 15 kg / 33 lbs - SASL-16xTF : 25 kg / 55 lbs SD Flash card with 200 programs per card 5.7" multi-language, colour touch screen Integrated printer SALCF-020: memory card reade SIMP-02:...

Open the catalog to page 2

POWER SOURCES INNOVATIVE ORBITAL SOLUTIONS 210A - Autoline - Orbital welding autoline, PFC compatible110V -230V, 50/60hz, iMax =25A (220V), 30A(110V) - Integrated cooler: 1400 W cooling capacity with 1L/min - Cooling safety system: flow rate, pressure - Max. current 210 A - Power factor: 160 A, 100% - Assistance for programs creation : welding passes presentation with autoComputing multipasses - Supplied with a memory card with 200 programs, 20 levels each 5.7" colour touch screen remote control. Secure, multi-lingual access Easy-to-use touch screen features parameter calculation SAGC-300: power...

Open the catalog to page 3

POWER SOURCES INNOVATIVE ORBITAL SOLUTIONS 300A - 400V - Orbital welding power source, 400V +/15% 3 phases + earth, 50/60Hz ,Imax = 24A - Integrated cooler: 1400 W cooling capacity with 1L/min - Cooling safety system: flow rate, pressure - Max. current 300 A - Power factor: 210 A, 100% - Assistance for programs creation : welding passes presentation with autoComputing multipasses - Supplied with a memory card with 200 programs, 20 levels each 5.7" colour touch screen remote control. Secure, multi-lingual access Drives up to 4 shafts, depending on the version: wire feed, AVC, OSC and wire Integrated...

Open the catalog to page 4

Accessories INNOVATIVE ORBITAL SOLUTIONS SACW-Co06: cooling fluid SAGC-300 : trolley for SASL-300/200 SACF-020: flash card with software SALCF-020: Flash card reader SADF2 : External Wire feeder SIMP-02: printer paper for SASL SADDD-15 : Dual flow meter Join Experience 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2016

Open the catalog to page 5

Join Experience 330B Route de Portes Les Valence - Zl Les Bosses - 26800 Etoile sur Rhone commerce@axxaircom - www.axxair.com
