E-catalog Prefabrication welding Axxair

Product catalog summary

Overview: The document provides technical specifications and details for AXXAIR's innovative orbital welding solutions, focusing on prefab welding machines with various diameter capabilities and features.

Specifications:

Models include SP121, SP171, SP221, and SP321, each designed for different diameter ranges from ø12 mm to ø330 mm.
Basic stainless steel jaws and auxiliary jaws are included for each model, with electric rotation autoline available at 120V and 230V.
Cooling options include air-cooled (max. current 100 A at 100%) and water-cooled (max. current 200 A at 100%).
Machines are scalable and can be transformed into cutting and orbital bevelling machines.
Weight varies by model, ranging from 45 kg to 81 kg.

Features:

Axial and radial adjustments for precise positioning.
Driven by AXXAIR power source with a mechanical profile guide ensuring constant arc voltage.

Accessories and Consumables:

Support feet, pneumatic clamping, simple/bearing stands, and various torch kits are available.
Consumables include different diameter options for torches and wire feeders.

Options:

Gas protection kits, inclined torch kits, and external wire feeders are offered as additional options.

Contact Information: AXXAIR's contact details are provided for further inquiries.

Catalog excerpts

E-catalog Prefabrication welding Axxair-1

INNOVATIVE ORBITAL SOLUTIONS Join experience

Open the catalog to page 1

E-catalog Prefabrication welding Axxair-2

PREFAB WELDING INNOVATIVE ORBITAL SOLUTIONS ø12 - ø121 mm ø0,45 to ø4,5 '' - Basic stainless steel jaws Ø 1” to 4,5” ( Ø 24 to Ø 121 mm ) - Included stainless steel auxiliary jaws Ø 0,45” to 4,25” (Ø12 to Ø108mm) - Electric rotation autoline 120 V - 230V - Wide diameter range - Air-cooled: max. current 100 A at 100% - Water-cooled: max. current 200 A at 100% - Scalability: may be transformed into a cutting and orbital bevelling machine Weight: 45 kg / 99 lbs Axial adjustment for precise positioning Radial adjustment for precise positioning Driven by AXXAIR power source Mechanical profile guide:...

Open the catalog to page 2

E-catalog Prefabrication welding Axxair-3

PREFAB WELDING INNOVATIVE ORBITAL SOLUTIONS ø16 - ø170 mm ø0,625 to ø6,625 '' - Basic stainless steel jaws Ø 2,75” to 6,625”(Ø70 to Ø 168 mm ) - Included stainless steel auxiliary jaws Ø 0,625” to 4,65” ( Ø 16 to Ø 118 mm ) - Electric rotation autoline 120 V - 230V - Wide diameter range - Air-cooled: max. current 100 A at 100% - Water-cooled: max. current 200 A at 100% - Scalability: may be transformed into a cutting and orbital bevelling machine Weight: 52 kg / 115 lbs Axial adjustment for precise positioning Radial adjustment for precise positioning Driven by AXXAIR power source Mechanical...

Open the catalog to page 3

E-catalog Prefabrication welding Axxair-4

PREFAB WELDING INNOVATIVE ORBITAL SOLUTIONS ø59 - ø225 mm ø2 to ø8,625 '' - Basic stainless steel jaws Ø 4,5” to 8,625 ( Ø 116 to Ø 219 mm ) - Included stainless steel auxiliary jaws Ø 2” to 6,65” ( Ø 59 to Ø 169 mm ) - Electric rotation autoline 120 V - 230V - Wide diameter range - Water-cooled: max. current 200 A at 100% - Scalability: may be transformed into a cutting and orbital welding machine Weight: 59 kg 130 lbs Axial adjustment for precise positioning Radial adjustment for precise positioning Driven by AXXAIR power source Mechanical profile guide: constant arc voltage CCSA21 : Pneumatic...

Open the catalog to page 4

E-catalog Prefabrication welding Axxair-5

PREFAB WELDING INNOVATIVE ORBITAL SOLUTIONS ø140 - ø330 mm ø5,5 to ø12,75'' - Basic stainless steel jaws Ø 8,5” to 12,75” (Ø 216 to Ø 323 mm ) - Included stainless steel auxiliary jaws Ø 5,5” to 10” ( Ø 140 to Ø 256 mm ) - Electric rotation autoline 120 V - 230V - Wide diameter range - Water-cooled: max. current 200 A at 100% - Scalability: may be transformed into a cutting and orbital welding machine Weight: 81 kg / 179 lbs Axial adjustment for precise positioning Radial adjustment for precise positioning Driven by AXXAIR power source Mechanical profile guide: constant arc voltage Join Experience...

Open the catalog to page 5

E-catalog Prefabrication welding Axxair-6

Accessories INNOVATIVE ORBITAL SOLUTIONS SKIB-01: gas protection kit - plugs Ø6 to 41 mm SKIF-01: gas protection kit membranes Ø40 to 120 mm Join Experience SOAF: AVC/OSC for SP with wire feeder and water torch 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-0

Open the catalog to page 6

E-catalog Prefabrication welding Axxair-7

Accessories INNOVATIVE ORBITAL SOLUTIONS SKTD-01: spares kit for straight torch Ø1.6 mm SKTD-02: spares kit for straight torch Ø2.4 mm CCBSB-001: bench with height adjustment - 1.5 m CCBSB-002: additional 1.5 m bench SADF2: external wire feeder SADFP-02: wire guide SADDD-15 : Dual flow meter Join Experience 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06

Open the catalog to page 7

E-catalog Prefabrication welding Axxair-8

INNOVATIVE ORBITAL SOLUTIONS Join Experience 330B Route de Portes Les Valence - Zl Les Bosses - 26800 Etoile sur Rhone commerce@axxaircom - www.axxair.com

Open the catalog to page 8
