INNOVATIVE ORBITAL SOLUTIONS Join experience

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø6 - ø40 mm ø0,25'' - ø1,5'' - Water-cooled head - Dual-wing opening - Clamping jaws - stainless steel (1 kit per diameter) - Tungsten electrode specific to diameter - Motor with coder: allows for tungsten electrode start-up at all angles - High protection against start-up without tungsten electrode Weight: 8.8 kg / 19 lbs - All machines are delivered in their individual case Remote control keypad Driven by AXXAIR power source ( cf compatibility table ) Adjustable spring- loaded system: to account for tube "out of round" SSED-16: offset tungsten electrode...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø6 - ø65 mm ø0,25'' - ø2,5'' - Water-cooled head - Dual-wing opening - Clamping jaws - stainless steel (1 kit per diameter) - Tungsten electrode specific to diameter - Motor with coder: allows for tungsten electrode start-up at all angles - High protection against start-up without tungsten electrode Weight: 9.2 kg / 20 lbs - All machines are delivered in their individual case Remote control keypad Driven by AXXAIR power source ( cf compatibility table ) Adjustable spring- loaded system: to account for tube "out of round" SSED-16: offset tungsten electrode...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø25 - ø115 mm ø1'' - ø4,5'' - Water-cooled head - Dual-wing opening - Clamping jaws - stainless steel (1 kit per diameter) - Tungsten electrode specific to diameter - Motor with coder: allows for tungsten electrode start-up at all angles - High protection against start-up without tungsten electrode Weight: 9.9 kg / 22 lbs - All machines are delivered in their individual case Remote control keypad Driven by AXXAIR power source ( cf compatibility table ) Adjustable spring- loaded system: to account for tube "out of round" SSED-16: offset tungsten electrode...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø6 - ø40 mm ø0,25'' - ø1,5'' - Water cooled including outer body - Stainless steel collets - Spring mounted axis and spring closing lever: takes in account ovality of the tubes - Tool free fixing of the collets through a push button: no risk to loose keys.. - Upper window available as an option. - Dedicated to thin wall tubing up to 2,5 mm (3 mm in some cases) - Able to be used under 120A, 100% duty cycle - Narrow head: 41 mm total, 20,5 mm from electrode to the outside - Safety Cable integrated in the hosing to avoid pulling on the inner cables Weight...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø6 - ø65 mm ø0,25'' - ø2,5'' - Water cooled including outer body - Stainless steel collets - Spring mounted axis and spring closing lever: takes in account ovality of the tubes - Tool free fixing of the collets through a push button: no risk to loose keys.. - Upper window available as an option. - Dedicated to thin wall tubing up to 2,5 mm (3 mm in some cases) - Able to be used under 120A, 100% duty cycle - Narrow head: 41 mm total, 20,5 mm from electrode to the outside - Safety Cable integrated in the hosing to avoid pulling on the inner cables Weight...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø25 - ø115 mm ø1'' - ø4,5'' - Water cooled including outer body - Stainless steel collets - Spring mounted axis and spring closing lever: takes in account ovality of the tubes - Tool free fixing of the collets through a push button: no risk to loose keys.. - Upper window available as an option. - Dedicated to thin wall tubing up to 2,5 mm (3 mm in some cases) - Able to be used under 120A, 100% duty cycle - Narrow head: 41 mm total, 20,5 mm from electrode to the outside - Safety Cable integrated in the hosing to avoid pulling on the inner cables Weight...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS VAL-CO05 : Protection case for shipping and storage for SATF models SAFS-210 : Wire harness extension 10 M SKIB-01: gas protection kit - plugs Ø 6 to 41 mm SMN40-XX Clamping jaws Ø in mm SMN65-XX Clamping jaws Ø in mm SKIF-01: gas protection kit - membranes Ø 40 SMN115-XX Clamping jaws Ø in mm to 120 mm SAGC-121 : SATF-40 / SATF-65 / SATF-115 Handler for ND and MI models Join Experience SSED-16: offset tungsten electrode support Ø 1.6 mm offset range 4 to 7.5 mm SSED-24: offset tungsten electrode support Ø 2.4 mm offset range 4 to 7.5 mm SATFxxxND-A001...

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS Tube-Elbow configuration : - tube side : standard jaws - elbow side : adaptative jaws + protective inox shields Tube-Ferrule configuration : - tube side : standard jaws - ferrule side : special jaws Ferrule-Elbow-Ferrule configuration ( big diameter ): - elbow side : adaptative jaws + protective inox shields - ferrule side : special jaws Join Experience 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2016

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS Ferrule-Elbow-Ferrule configuration ( small diameter ): - elbow side : adaptative jaws + protective inox shields - ferrule side : special jaws Tube-Union configuration : - tube side : standard jaws - union side : special jaws Join Experience For any other special setup, please contact us. We will design the required special solution 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2016

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS Z.I. Les Bosses F-26800 ETOILE-SUR-RHONE www.axxair.com Join Experience 330B Route de Portes Les Valence - ZI Les Bosses - 26800 Etoile sur Rhône Tél: +33 475 575 070 - Fax: +33 475 575 080 commerce@axxaircom - www.axxair.com V3.8-06-2

INLINE WELDING INNOVATIVE ORBITAL SOLUTIONS ø10 - ø40 mm ø0,4'' - ø1,7'' - Water cooled welding torch - Mechanical Roll tracking: insures electrode distance without marking the tube - Symmetrical quick clamping through lever - Motor with encoder : allows for tungsten electrode startup at all angles and a wide range of diameters - Axial adjustment of the electrode - Low rotating free space around the tube: 70 mm radius from center of tube Weight: 3,8Kg / 7 lbs (without cables) - Very compact design - Two motor positions available Torch angle adjustment: welding under flange or short T angle SATO-xxxE01:...
