E-catalog Orbital Cutting Axxair

Product catalog summary
Overview: The document outlines the specifications and features of AXXAIR's orbital cutting machines, designed for precision tube cutting with minimal vibration and distortion.
Specifications:
  • CC81: For tube diameters 0.25” to 3” (5 to 78 mm), lightweight (15 kg), precision cuts with perpendicularity less than 0.25 mm.
  • CC121ECO: Handles diameters 0.25” to 4.5” (5 to 121 mm), dual-output motors, 36 kg, upgradeable for bevelling and welding.
  • CC171: For diameters 0.625” to 6.625” (16 to 170 mm), dual-output motor, 44 kg, scalable functions.
  • CC221: Suitable for 2” to 8.625” (59 to 225 mm), dual-output motor, 51 kg, options for bevelling and welding.
  • CC321: Handles 5.5” to 12.75” (140 to 330 mm), dual-output motor, 73 kg, scalable functions.
  • CC421: For 8.625” to 16” (212 to 422 mm), dual-output motor, 186 kg, options for bevelling and welding.
  • CC521: Suitable for 12.75” to 20” (312 to 522 mm), dual-output motor, 223 kg.
  • CC721: Handles 18” to 28” (447 to 725 mm), dual-output motor, 256 kg.
  • CC1100: For 28” to 40” (711 to 1016 mm), automatic pneumatic clamping, 900 kg.
Features:
  • Precision cutting with perpendicularity less than 0.25 mm or 0.4 mm for larger models.
  • Concentric clamping with stainless steel jaws to prevent distortion.
  • Dual-output motors with multiple blade positions for enhanced performance.
  • Scalability for bevelling and orbital welding.
  • Electric and pneumatic motor versions for different stainless steel thicknesses.
Accessories and Consumables:
  • Support stands, benches, and lubrication options enhance functionality.
  • Carbide and bevelling blades for specific cutting needs.
Conclusion: AXXAIR's machines offer versatile, precise tube cutting solutions with scalability and customization for diverse industrial needs.
Technical Specifications: Various motor models with specifications, including voltages and power ratings like 120V and 230V with 1800W power.
Accessories: Includes cutting and bevelling motors, support benches, and stands with features like height adjustment.
Consumables: Blades and lubricants in various sizes and angles, suitable for specific models.
Contact Information: AXXAIR is located at 330B Route de Portes Les Valence, ZI Les Bosses, 26800 Etoile sur Rhône, with contact details for inquiries.
See more

Catalog excerpts

E-catalog Orbital Cutting Axxair-1

INNOVATIVE ORBITAL SOLUTIONS Join experience

 Open the catalog to page 1
E-catalog Orbital Cutting Axxair-2

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø5 - ø78 mm ø0,25 to ø3 '' - Ø 0,25” to 3”: very wide range of use - Cutting precision: - perpendicular cuts < 0.25 mm - seamless cutting Weight:15 kg / 33 lbs (easy handling) - Ideal for use at worksites Blade-jaws distance of 2 mm Limits vibration and distortion with thin and small-diameter tubes Concentric clamping with 3 jaws in stainless steel to eliminate tube distortion Worksite carry case M21 : Metabo 230V mono Thickness < 7mm 81M21 M11 : Metabo 120V mono Thickness < 7mm Adjustment via the speed changer 81M11 All motors are delivered in their...

 Open the catalog to page 2
E-catalog Orbital Cutting Axxair-3

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø5 - ø121 mm ø0,25 to ø4,5 '' - Basic stainless steel jaws Ø 1” to Ø 4,5” ( 24 to 121 mm ) - Included stainless steel auxiliary jaws Ø 0,25 to Ø 4,25” ( 5 to 108 mm ) - Cutting precision: perpendicular cuts < 0.25 mm - Dual-output cutting motor with 2 blade positions for uptake - Weight: 36 kg / 79 lbs (easy handling) Blade-jaw distance of 2/13.5 mm Limits vibration and tube distortion Concentric clamping with 4 jaws in stainless steel, standard, to eliminate tube distortion Penetration check feature: operator safety feature Adjustment via the speed...

 Open the catalog to page 3
E-catalog Orbital Cutting Axxair-4

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø5 - ø121 mm ø0,25 to ø4,5 '' - Basic stainless steel jaws Ø1”to Ø 4,5”( 24 to 121 mm ) - Included stainless steel auxiliary jaws Ø 0,25 to Ø 4,25” ( 5 to 108 mm ) - Cutting precision: perpendicular cuts < 0.25 mm - Scalability: May be transformed into a bevelling and orbital welding machine - Dual-output cutting motor with 2 blade positions for uptake - Weight: 37 kg / 82 lbs (easy handling) Blade-jaw distance of 2/13.5 mm. Limits vibration and tube distortion Concentric clamping with 4 jaws in stainless steel, standard, to eliminate tube distortion...

 Open the catalog to page 4
E-catalog Orbital Cutting Axxair-5

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø16 - ø170 mm ø0,625 to ø6,625 '' - Basic stainless steel jaws Ø 2,75” to Ø 6,625” (70 to 170 mm ) - Included stainless steel auxiliary jaws Ø 0,625” to Ø 4,65” ( 16 to 118 mm ) - Cutting precision: perpendicular cutting <0.25 mm - Scalability: may be transformed into a bevelling and orbital welding machine - Dual-output cutting motor with 2 blade positions for uptake - Weight: 44 kg / 97 lbs (easy handling) Blade-jaw distance of 2/13.5 mm. Limits vibration and tube distortion Concentric clamping with 4 jaws in stainless steel, standard, to eliminate...

 Open the catalog to page 5
E-catalog Orbital Cutting Axxair-6

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø59 - ø225 mm ø2 to ø8,625 '' - Basic stainless steel jaws Ø 4,55” to 8,625” ( Ø 116 to Ø 225 mm ) - Included stainless steel auxiliary jaws Ø 2” to Ø 6,65” ( Ø 59 to Ø 169 mm ) - Cutting precision: perpendicular cutting <0.25 mm - Dual-output cutting motor with 2 blade positions for uptake - Scalability: may be transformed into a bevelling and orbital welding machine - Weight: 51 kg / 112 lbs (easy handling) Optimized Blade-jaws distance Limits vibration and tube distortion Concentric clamping with 6 jaws in stainless steel, standard, to eliminate...

 Open the catalog to page 6
E-catalog Orbital Cutting Axxair-7

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø140 - ø330 mm ø5,5 to ø12,75 '' - Basic stainless steel jaws Ø8,5” to 12,75”( Ø216 to Ø 330 mm ) - Included stainless steel auxiliary jaws Ø5,5” to Ø 10” ( Ø 140 to Ø 256 mm ) - Cutting precision: perpendicular cutting < 0.25 mm - Dual-output cutting motor with 2 blade positions for uptake - Scalability: may be transformed into a bevelling and orbital welding machine • Lifting eye - Weight: 73 kg / 161 lbs (easy handling) Optimiszed blade-jaws distance Limits vibration and tube distortion Concentric clamping with 8 jaws in stainless steel, standard,...

 Open the catalog to page 7
E-catalog Orbital Cutting Axxair-8

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø212 - ø422 mm ø8.625 to ø 16'' - Basic stainless steel jaws Ø 12” to 16”( Ø 350 to Ø 420 mm ) - Included stainless steel auxiliary jaws Ø 8,625” to 12,75” ( Ø 212 to Ø 352 mm ) - Cutting precision: perpendicular cutting <0.4 mm - Dual-output cutting motor with 2 blade positions for uptake - Lifting eye - Weight: 186 kg / 410 lbs Optimiszed blade-jaws distance Limits vibration and tube distortion Concentric clamping with 8 jaws in stainless steel, standard, to eliminate tube distortion Motor 230V, mono : FS29: Thickness Inox <5mm FS25: Thickness Inox...

 Open the catalog to page 8
E-catalog Orbital Cutting Axxair-9

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø312 - ø522 mm ø12.75 to ø20 '' - Basic stainless steel jaws Ø 15,5” to 20” ( Ø 450 to Ø 522 mm ) - Included stainless steel auxiliary jaws Ø 12,75” to 15,5” ( Ø 312 to Ø 452 mm ) - Cutting precision: perpendicular cuts < 0.4 mm - Dual-output cutting motor with 2 blade positions for uptake - Lifting eye - Weight: 223 kg / 492 lbs Optimiszed blade-jaws distance Limits vibration and tube distortion Concentric clamping with 8 jaws in stainless steel, standard, to eliminate tube distortion Motor 230V, mono : FS29: Thickness Inox <5mm FS25: Thickness Inox...

 Open the catalog to page 9
E-catalog Orbital Cutting Axxair-10

ORBITAL CUTTING INNOVATIVE ORBITAL SOLUTIONS ø447 - ø725 mm ø18 to ø28 '' - Basic stainless steel jaws Ø18” to Ø 28”(Ø653 to Ø 725 mm ) -Included stainless steel auxiliary jaws Ø 12,75” to 18” ( Ø 447 to Ø 654 mm ) - Cutting precision: perpendicular cutting < 0.4 mm - Lifting eye - Weight: 256 kg / 564 lbs Optimiszed blade-jaws distance Limits vibration and tube distortion Concentric clamping with 8 jaws in stainless steel, standard, to eliminate tube distortion Motor 230V, mono : FS29: Thickness Inox <5mm FS25: Thickness Inox >5mm Motor 120V, mono : FS19: Thickness Inox <5mm FS15: Thickness...

 Open the catalog to page 10
