Axcend FocusArray™ Expand Detection. Elevate Results. FocusArray™ redefines capillary LC detection with three orders of magnitude linearity and full UV absorbance coverage in a reduced footprint. The FocusArray full-spectrum detector unlocks new levels of sensitivity, linearity, and data quality for capillary HPLC workflows. Purpose-built for the Axcend Focus LC®, this DAD delivers a full UV absorbance spectrum from 190–700 nm with unprecedented precision—giving you greater confidence in every analysis. Combining industry-leading optics with advanced capillary design, FocusArray enables superior trace detection and robust quantification, all in a compact, easy-to-integrate package. Superior Sensitivity for Trace-Level Analysis With an 12 nL flow cell volume and 1.2 mm path length, FocusArray offers outstanding sensitivity—empowering you to detect trace components without sacrificing accuracy. Exceptional Linearity Across the Full UV Range FocusArray achieves three orders of magnitude linearity, ensuring reliable quantitation even across samples with widely varying concentrations. Confidently characterize target analytes and minor impurities in a single run. Seamless Integration for Real-Time Insight FocusArray works hand-in-hand with the Focus LC, controlled from a single software interface. Monitor reactions, QC processes, and separations in real-time without added com

Dimensions (WxDxH) Full UV-Visible Wavelength Range (190-700 nm) Capture maximum absorbance points with precision across a broad spectral window. Compact, Capillary-Optimized Flow Cell 12 nL volume and 1.2 mm pathlength minimize dispersion and maximize sensitivity, designed specifically for low-flow separations. Fast, Reliable Data Acquisition High-speed data collection up to 100 Hz enables sharper peak profiles and more robust peak integration with minimal baseline drift. Quick-Access Maintenance Deuterium lamp replacement is simple and fast through a front-panel access door, reducing downtime...
