AVL M.O.V.E 2 One platform. Global RDE compliance.

M.O.V.E 2 04 M.O.V.E. System Overview 06 Euro 7 Recommended System Solutions 10 China 7 Recommended System Solutions 14 System Control, Test Description, Test Result 15 AVL History in Tailpipe Emissions Measurement We are driven by a passion to examine the science, mechanics and philosophy of movement. To help create a world that is climate-neutral and one that makes safe, comfortable, green mobility a reality for everyone. Prof. Helmut O. List Chairman and CEO, AVL List GmbH

AVLat a Glance • Founded in 1948 • Global sales and service network •11% of turnover invested in inhouse R&D • 2,300 granted patents in force • ISO-certified quality management system Testing China 7 Euro 7 Sysgtem Overview

FUTURE-SAFE Enables quick adaptation to evolving regulations, safeguarding investments and reducing upgrade costs. COST EFFICIENT AND SCALABLE AVL M.O.V.E 2 reuse devices, upgrade selectively, and automate workflows for regulation-compliant, multi-vehicle RDE testing—without full system replacements. ROBUST, VERSATILE INSTALLATION Ensures safe, quick, and adaptable installations across diverse vehicle platforms, enhancing testing efficiency. COMPREHENSIVE PROCESS AUTOMATION Fully automated RDE testing minimizes manual intervention, reduces errors, and streamlines compliance management. GAS ADVANCED...

Sysgtem Overview SYSTEM CONTROL ADVANCED Integrated control, automation, and datalogging in one rugged, MIL-standard device—offering direct access to OBD and vehicle CAN for seamless, automated testing. POWER Centralized power and communication via the EBOX reduces installation effort and supports various battery types. The new AMEX+ delivers robust, portable energy with integrated Li-Ion technology. CONCERTO MDT Powerful data evaluation and reporting aligned with global RDE regulations. Automates submission document creation and sets the industry standard as the trusted reference tool. QUALITY...

Euro 7 Light Duty EURO 7 introduces tighter emission controls for lightduty vehicles, including stricter particle number limits that now count particles as small as 10 nm, and a Real Driving Emission (RDE) limit for THC and NOx (Diesel) or NMHC (Patrol). Furthermore, Onboard Monitoring (OBM) of NOx and NH3 using OBD sensors is required. AVL M.O.V.E 2 rises to the challenge. Designed as a modular and extendable system, it adapts effortlessly to different testing needs. At its core is the System Control Advanced, orchestrating a seamless experience – from installation to operation – thanks to flexible...

Integration POWER System Control Advanced CONCERTO MDT Quality Station PLUtron / FuelTron With PN Advanced, measuring both 10 nm and 23 nm particles happens in parallel, eliminating the need for multiple instruments. GAS Advanced ensures accurate results at lowest concentrations. The built in NDIR does not have any interference of N2O on CO for correct readings. The FID iS+ brings robust THC and NMHC measurement directly onboard the vehicle, combining mobility with precision. For NOx OBD sensor validation, the NH3 PEMS offers a smart, cost-effective solution – tackling the challenge of NH3 interference...

Euro 7 Heavy Duty Euro 7 HD RDE introduces stricter limits, including new components like PN10 nm, NH3, N2O, CH4, and NMOG, while reducing existing thresholds by around 50% and removing conformity factors. This raises the demand for highly accurate PEMS devices to ensure compliance. Onboard Monitoring (OBM) of NOx, NH3, and PM via OBD sensors adds another layer of complexity, requiring precise and reliable measurement under real-world condition. AVL M.O.V.E 2’s comprehensive system approach, built around the System Control Advanced, includes multi-component and especially for the low measurement...

Integration POWER System Control Advanced CONCERTO MDT Quality Station The FID iS+ uses a heated 2C-FID. It is a robust and compact solution for THC/ MNHC measurement based on the reference principle. It is required for the determination of NMOG in case of a higher bio-fuel content. Additionally, Concerto MDT, AVL’s validated data evaluation tool, supports one-click reporting aligned with global regulations, making it ideal for the increased documentation and audit-readiness demanded by Euro 7. The PN 2, based on a full flow Condensation Particle Counter (CPC) provides highest s ensitivity for...

China 7 Light Duty China 7 aims for tighter emission controls for light duty vehicles, including stricter particle number limits that now count particles as small as 10 nm and monitoring of NH3. In addition, the ambient conditions, including maximum altitude are extended for RDE testing. Further limits might follow in near future. AVL M.O.V.E 2 is a versatile and modular system. For cost effectiveness, existing systems can be re-used and extended with e. g. NH3 or a module measuring up to 20 gaseous components in parallel. PN PEMS in the field can be upgraded to support 10 nm in addition to 23...

Integration POWER System Control Advanced CONCERTO MDT Quality Station PLUtron / FuelTron The PN Advanced is capable of measuring both, 23 nm and 10 nm particles in parallel, eliminating the need for multiple instruments. System Control Advanced ensures guided, automated workflows for RDE, minimizing operator errors and ensuring compliance. The GAS Advanced is especially optimized for the Low NOx range to ensure highest accuracy and low-est drift. The NH3 PEMS is a compact and accurate extension for measuring NH3. Additionally, Concerto MDT, AVL’s validated data evaluation tool, supports one-click...

Heavy Duty China 7 HD RDE introduces a bunch of new limits includ-ing PM 10 nm (instead of 23 nm), NH3, N2O and CH4 in addition to the existing limits for standard components. Furthermore, the conformity factors are reduced which goes hand in hand with a limit reduction. This means that beside of measuring all the components a high accuracy of the PEMS devices is the key. AVL M.O.V.E 2's comprehensive system approach, built around the System Control Advanced, includes multi-component and especially for the low measurement range optimized analyzers & sensors to ensure accurate measurements across...
