AVL UltraFine Particle Monitor™

Product catalog summary

Introduction
The AVL UltraFine Particle Monitor™ (UFPM) is designed for measuring ultrafine particle (UFP) concentrations in ambient air, compliant with EN 16976 standards. It addresses the growing need for accurate air quality monitoring due to the health impacts of UFPs.

Specifications and Features

Measurement Method: Utilizes Condensation Particle Counting (CPC) to detect particles down to nanometer scale.
Counting Efficiencies: d50 at 10 ± 1 nm and d90 at < 20 nm.
Measurement Range: 0 to 100,000 #/cm³ with an accuracy of ± 5%.
Response Time: ≤ 1 second.
Design: Robust optical components, unique wick design, and automated drift detection ensure high precision and reliability.
Integration: Supports various interface protocols and features remote error handling.

Performance and Reliability
The UFPM is built to withstand harsh conditions, originally designed for the automotive industry. It features low butanol consumption and a fully closed working fluid system to minimize environmental exposure. The device autonomously restarts after power failures or butanol depletion.

Calibration and Data Quality
The UFPM maintains calibration accuracy within a narrow ±3% band, with over 3700 calibrations showing long-term stability. This ensures consistent data quality and reliability.

Applications

Urban Air Quality Monitoring: Effective in detecting diurnal cycles in particle concentrations related to commuter traffic.
Remote Observatories: Proven performance at high-altitude sites like the Sonnblick Observatory, even under extreme conditions.

AVL UFP Sampling System
This system ensures representative ambient air sampling, crucial for precise air quality monitoring. It includes a PM10 sampling head, PM2.5 cyclonic separator, and a Nafion® dryer to maintain sample humidity below 40%.

Company Overview
AVL List GmbH, founded in 1948, is a global leader in particle measurement technology with over 1600 CPC units installed worldwide. The company invests significantly in R&D and holds numerous patents, ensuring high-quality and innovative solutions for air quality monitoring.

Catalog excerpts

AVL UltraFine Particle Monitor™ for Ambient Air Quality Count on decades of experience in high-quality particle measurement

Open the catalog to page 1

The AVL UltraFine Particle Monitor™ measures the ultrafine particle number concentration in ambient air, compliant with EN 16976. Given the growing evidence of the health impacts of ultrafine particles (UFPs), global guidelines advocate for the expansion of air quality monitoring networks to include UFP measurements. Quantifying these particles and understanding their sources is challenging, making robust and accurate measurement tools essential. Developed based on decades of experience in particle emission measurement, the AVL UltraFine Particle Monitor™ (UFPM) enables continuous measurement...

Open the catalog to page 2

Calibration Excellence Meets Superior Design The k-factor data across more than 3700 calibrations includes initial factory calibrations, as well as annual and post service recalibrations. The data exhibits remarkable long-term stability within a narrow ±3% band around unity. The lack of drift indicates that the sensor, signal processing, and mechanical design retain exceptional calibration accuracy over time. Tight clustering further confirms the robustness and precision of the thermal and electronic system architecture. Condensation Particle Counting (CPC) CPC detects aerosol particles down...

Open the catalog to page 3

The AVL UltraFine Particle Monitor is an EN 16976-compliant, ACTRIS-compatible instrument that supports air quality networks with reliable performance, fast response, and minimal maintenance. Whether in urban traffic corridors or remote mountaintop observatories, it consistently delivers traceable, high-quality ultrafine particle (UFP) data. Diurnal cycles in particle number concentrations with distinct morning and evening peaks indicated commuter traffic. Instrument Model AVL Ultrafine Particle Monitor Evaluating Unit WCCAP, Leipzig, Germany Performance Evaluation Results: Performance Characteristics...

Open the catalog to page 4

Collecting representative ambient air samples is challenging due to fluctuating humidity, changing wind conditions, and potential diffusion losses. The AVL UFP Sampling System ensures representative ambient air sampling in compliance with EN 16976, essential for precise air quality monitoring. The system allows for tailored installation by connecting main components with flexible tubing rather than rigid connectors and offers the following features. 1. The 360-degree PM10 sampling head removes biological material and large particles above 10 pm. 2. The PM2.5 cyclonic separator restricts the sample...

Open the catalog to page 5

For a greener, safer, better world of mobility. AVL List GmbH Hans-List-Platz 1 8020 Graz Austria Phone +43 316 787-0 E-Mail [email protected] www.avl.com/ufpm PA4105E, Classification Public
